N7353-790 4-Light Aged Antique Brass Semi-Flush Mount
Product Information
The item number for this product is N7353-790 and the
installation instructions were last updated on 10/14/2021. The
product comes with a mounting plate, ground screw, mounting screw,
acrylic pole, candelabra base bulbs, stem, swivel, bolts, plastic
washer, finial, support cable, and hook.
The product is designed to be installed in a junction box (not
included) and can hold up to four candelabra base bulbs with a
maximum wattage of 60 watts each. The fixture can also be used with
CFL or LED equivalent bulbs. The product has a ground wire that
should be connected to the junction box’s ground wire or directly
to the mounting plate using the provided green screw.
Product Usage Instructions
- Shut off power at the fuse box or circuit breaker box and
remove the old fixture including the mounting hardware. - Unpack the new fixture and lay out all the parts in a clean
area. Take care not to misplace any small parts necessary for
installation. - Adjust the arms to the proper position as shown in Fig. 4.
- Thread the stem (G) onto all thread (H) of socket assembly
(L). - Thread swivel (E) of upper assembly onto stem (G).
- Carefully place bolts (F) through holes on top of frame
assembly (J). Then tighten with plastic washer and finial (K). - Place mounting plate (A) to junction box (not included) using
mounting screws (B). The side of mounting plate marked GND must
face out. - The support cable is provided to support weight of fixture
while wiring. Align fixture to mounting plate (A) and attach hook
(M) on end of support cable (N) into a slot located on mounting
plate (A). Carefully allow support cable (N) to support weight of
fixture while wiring. - Connect the electrical wires as shown in Fig. 3, making sure
that all wire connectors are secured. If your junction box has a
ground wire (green or bare copper), connect the fixture’s ground
wire to it. Otherwise, connect the fixture’s ground wire directly
to the mounting plate (A) using the green screw provided. - Tuck wire connections neatly into junction box.
- Place canopy (C) to mounting plate (A) and secure with screws
(D). - Install (4) four candelabra base bulbs (I) up to 60 watts each
or CFL or LED equivalent (not included) in accordance with the
fixture specification. DO NOT EXCEED THE MAXIMUM WATTAGE
RATING! - Turn on power to the junction box and test the fixture.
INSTALLATION INSTRUCTIONS
Item#N7353-790 (New. 10/14/2021) READ AND SAVE THESE INSTRUCTIONS
W AR NI N G ! SHUT P O WE R O FF AT F US E O R CI RC UI T BRE AKE R.
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
PREPARATION (Fig. 1 & Fig. 4)
1. Shut off power at the fuse box or circuit breaker box and remove the old fixture including the mounting hardware.
2. Carefully unpack your new fixture and lay out all the parts in a clean area. Take care not to misplace any small parts necessary for installation.
3. The arms have been placed to lay flat for shipping. Adjust arms to proper position. (See Fig. 4)
Fig.1
Set#A-020-119 – Mounting Plate – Ground Screw – Mounting Screw *2
ASSEMBLING THE FIXTURE (Fig. 1 & Fig. 2) 4. Thread stem (G) onto all thread (H) of socket assembly (L). 5. Thread swivel (E) of upper assembly onto stem (G). 6. Carefully place bolts (F) through holes on top of frame assembly
(J). Then tighten with plastic washer and finial (K). 7. Place mounting plate (A) to junction box (Not included) using
mounting screws (B) (Size: #8-32N*L1″). The side of mounting plate marked “GND” must face out. 8. The support cable is provided to support weight of fixture while wiring. Align fixture to mounting plate (A) and attach hook (M) on end of support cable (N) into a slot located on mounting plate (A). Carefully allow support cable (N) to support weight of fixture while wiring.
CONNECTING THE WIRES (Fig. 3) 9. Connect the electrical wires as shown in Fig. 3, making sure that
all wire connectors are secured. If your junction box has a ground wire (green or bare copper), connect the fixture’s ground wire to it. Otherwise, connect the fixture’s ground wire directly to the mounting plate (A) using the green screw provided.
10. Tuck wire connections neatly into junction box.
Acrylic pole # GP7353-1 *8 GP7353-2 *8
Fig.2Fig.2
COMPLETING THE INSTALLATION (Fig. 1) 11. Place canopy (C) to mounting plate (A) and secure with screws
(D). 12. Install (4) four candelabra base bulbs (I) up to 60 watts each or
CFL or LED equivalent (not included) in accordance with the fixture specification. –DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!).
Your installation is now complete. Return power to the junction box and test the fixture.
Fig. 3
Note: Illustration (Fig. 1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.
