JN 4110 Talia Small Semi-Flush Mount
Product Information:
- Product Name: Talia Small Semi-Flush Mount
- Item Number: JN 4110
- Bulbs: Not included
Product Usage Instructions:
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Unscrew the quick link (G) to remove the collar loop (D) from
the chain (H). - Install the mounting plate (B) to the junction box using the
mounting screws (C). - Tighten the locknut to secure the collar loop (D) to the
mounting plate (B) using pliers. - Attach the canopy (E) to the collar loop (D) and secure it with
the collar ring (F). - Connect the fixture loop (I) to the collar loop (D) using the
quick link (G). Secure the quick link (G). - Attach the chains (J) to the hooks on the fixture body (K)
using quick links (G). Secure the quick links (G). - Thread the fixture wire and ground wire through the chain (J),
ensuring there is no tension on the wires when reaching the collar
loop (D). Cut excess wires, leaving enough to reach the junction
box. - Separate the two sides of the molded wire and strip insulation
on each side by 5/8 inch. - Loosen the collar ring (F) and carefully let the canopy (E)
slip down the chain (H). - Twist all fixture wires together and slip them through the
center hole of the collar loop (D). Untwist the wires and separate
them to prepare for connection. - Wrap the fixture ground wire (bare copper) around the green
grounding screw and tighten it. - Continue the fixture ground wire and connect it to the supply
ground wire (usually green or bare copper) using the wire nut
(A). - Connect the fixture neutral wire (ribbed) to the supply neutral
wire (usually white) using the wire nut (A). - Connect the fixture hot wire (smooth with markings) to the
supply hot wire (usually black) using the wire nut (A). Make sure
not to reverse the hot and neutral connections. - Ensure all wire connections are tight and carefully tuck them
into the junction box. - Install the canopy (E) to the collar loop (D) and secure it
with the collar ring (F). - Insert light bulbs into the sockets.
- Install the glass balls starting from the bottom (layer 1) and
work your way to the top (layer 6) as shown in figures L1-L6.
Care Instructions:
Clean only with a soft dry cloth or feather duster. Do not use
abrasive or chemical agents.
ASSEMBLY INSTRUCTIONS
Diagram 1
A B C D E F
G
I J G
K Bulbs not included
Talia Small Semi-Flush Mount
Item # JN 4110
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Slip Joint Pliers
Measuring Tape
Wire Strippers Wire Cutters
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove collar loop (D) from chain (H) by unscrewing quick link (G). 3. Install mounting plate (B) to junction box and secure with mounting
screws (C). 4. Secure collar loop (D) to mounting plate (B) using pliers to tighten
locknut. 5. Install canopy (E) to collar loop (D) and secure with collar ring (F). 6. Attach fixture loop (I) to collar loop (D) using quick link (G). Secure
quick link (G). 7. Attach chains (J) to hooks on fixture body (K) using quick links (G).
Secure quick links (G). 8. Thread fixture wire and ground wire through chain (J).
NOTE: When you reach the collar loop (D), ensure there is no tension on the wires. Cut excess wires, being sure to leave enough to reach the junction box. 9. Separate two sides of molded wire, and strip insulation on each 5/8″. 10. Loosen collar ring (F) and let canopy (E) slip down chain (H) carefully. 11. Twist all fixture wires together. Slip through center hole of collar loop (D). NOTE: Untwist wires and separate to prepare for connection.
M
L IST ED
US
ASSEMBLY INSTRUCTIONS
Diagram 1
A B C D E F
G
I J G
K Bulbs not included
Talia Small Semi-Flush Mount
Item # JN 4110
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
12. Wrap fixture ground wire (bare copper) around the green grounding screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (A). NOTE: It is imperative that the fixture is grounded.
13. Connect fixture neutral wire (ribbed) to the supply neutral wire (usually white) using wire nut (A).
14. Connect fixture hot wire (smooth with markings) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
15. Make sure all wire connections are tight, then carefully tuck into the junction box.
16. Install canopy (E) to collar loop (D) and secure with collar ring (F). 17. Insert light bulbs into the sockets. 18. Install glass balls starting from bottom (layer 1
and working your
way to the top (layer 6) as shown in figures L1-L6.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents..
M
L IST ED
US
ASSEMBLY INSTRUCTIONS
L6 L5
L4 L3 L2 L1
Talia Small Semi-Flush Mount Item # JN 4110
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
163mm L (6pcs + 2pcs spare parts)
137mm M (15pcs + 2pcs spare parts)
110mm S (6pcs + 2pcs spare parts)
M
L IST ED
US
ASSEMBLY INSTRUCTIONS
L1
M
L3
S M
M S
S M
M
S
L5
L M
L
M
M L
L M
L2
L L
L4
(No Glass Parts on Layer 4)
S
L6
M M
M
M
M M
S
Talia Small Semi-Flush Mount Item # JN 4110
