HAY-1405-AG 12 Light Chandelier
Product Information
Model: HAY-1405-AG
Part Number: N/A
Recommended Bulb Type: 12-Candelabra Base Bulb
Recommended Wattage: 40 Watts
Maximum Wattage: 60 Watts
Fixture Rating: Dry
Product Usage Instructions
- Before starting installation, ensure that you have all the
parts and components required. - Take one check ring and slide it over the coupler on top of the
frame. Screw the threaded pipe into the coupler and then slide the
metal tube over the threaded pipe. Place another check ring over
the top of the metal tube and secure it with the fixture loop. - Safely attach the fixture into the outlet box. Install the
bulbs (not included) and connect the power. - When dressing the fixture, start with crystal labeled (A).
- IMPORTANT: Apply crystal sets in alphabetical order.
Crystal Sets:
A. 18 Sets – (1) 30x400mm
B. 30 Sets – (1) 30x300mm
C. 42 Sets – (1) 30x200mm
Note: Ensure that the short end of each crystal set is
positioned above the frame.
WARNING: All electrical components must be
installed by a licensed electrician in accordance with the National
Electric Code and the appropriate local electrical codes. Turn off
power before installation.
CAUTION: For extended use, it is recommended to
use LED bulbs.
LIGHTING THE WAY FOR SIXTY YEARS ASSEMBLY INSTRUCTION MODEL #HAY-1405-AG
WARNING:
95″ 20.5″
22″
DETAILED ILLUSTRATION
Electrical Danger Turn Power Off
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
C
U R
L
You will need 12-Candelabra Base Bulb
40 Watts Recommended 60 Watts Max
USE LED BULBS FOR EXTENDED USE
This fixture is Dry rated
How to Install
1. Do a complete inventory of all parts and components before you start installing.
2. Slide one check ring over the coupler on top of frame. Screw the threaded pipe into the coupler and slide the metal tube over the threaded pipe. Slide another check ring over the top of metal tube and secure with fixture loop.
3. After safety attaching fixture into outlet box, install bulbs (not included) and proceed to connecting the power.
4. When you begin to dress the fixture, start with crystal labeled (A).
5. IMPORTANT: Apply crystal sets in alphabetical order.
Crystal Sets
A. 18Sets. (1)30x400mm B. 30Sets. (1)30x300mm C. 42Sets. (1)30x200mm
Short end above frame
LIGHTING THE WAY FOR SIXTY YEARS
PART NUMBER MODEL #HAY-1405-AG
Part Number
Part Numbers A. (2)-Wire Connector B. (1)-Mounting Plate C. (2)-Outlet Box Screws D. (1)-Lock washer E. (1)-Hex Nut F. (1)-Nipple G. (1)-Canopy; w5″ x h1.25″ (XFB1405AGCAN5IN) H. (1)-Collar Ring I. (1)-Collar Loop J. (1)-Chain; 72″, 5mm (XFB1405AGCHA5MM) K. (1)-Ground Wire L. (1)-Fixture Loop M. (1)-Metal Tube; 8.5″, 16MM thickness (XFB1405AGROD8.5IN) N. (1)-Threaded Pipe; 9.5″, 12MM thickness (XFB1405AGSTEM9.5IN) O. (2)-Check Ring P. (1)-Frame PART BAG: Includes Parts A, C PART BAG : Includes Parts B, D, E, F, H, I
P
