SLD-50 Series 50W linear LED Driver

50W linear LED Driver

SLD-50 series
User’s Manual

IS 15885(Part 2/Sec13)

THOMAS SAMUEL

THOMAS SAMUEL

R-41027766

/

File Name:SLD-50-SPEC 2022-02-18

50W Constant Voltage+Constant Current LED Driver

SLD-50 series

SPECIFICATION

MODEL

SLD-50-12

SLD-50-24

OUTPUT

DC VOLTAGE

12V

CONSTANT CURRENT REGION Note.2 8.4 ~12V

RATED CURRENT

4.2A

RATED POWER

Note.5 50.4W

RIPPLE & NOISE (max.) Note.3 150mVp-p

VOLTAGE TOLERANCE Note.4 ±4.0%

24V 16.8 ~24V 2.1A 50.4W 240mVp-p ±3.0%

LINE REGULATION LOAD REGULATION SETUP, RISE TIME Note.6 HOLD UP TIME (Typ.)

±0.5% ±1.5% 500ms, 80ms 115VAC / 230VAC 10ms/230VAC 10ms/115VAC

±0.5% ±0.5%

VOLTAGE RANGE

110 ~ 305VAC 155 ~ 431VDC Note.5 (Please refer to “STATIC CHARACTERISTIC” section)

FREQUENCY RANGE

47 ~ 63Hz

POWER FACTOR

PF0.97/115VAC, PF0.95/230VAC, PF0.92/277VAC@full load (Please refer to “POWER FACTOR (PF) CHARACTERISTIC” section)

TOTAL HARMONIC DISTORTION

THD< 10%(@load60%/115VC,230VAC; @load75%/277VAC) (Please refer to “TOTAL HARMONIC DISTORTION(THD)” section)

INPUT

EFFICIENCY (Typ.) AC CURRENT INRUSH CURRENT(Typ.)

88%

90%

0.6A / 115VAC 0.3A / 230VAC 0.25A/277VAC COLD START 50A(twidth=270s measured at 50% Ipeak) at 230VAC; Per NEMA 410

MAX. No. of PSUs on 16A CIRCUIT BREAKER

8 units (circuit breaker of type B) / 16 units (circuit breaker of type C) at 230VAC

LEAKAGE CURRENT

<0.25mA / 277VAC

NO LOAD POWER CONSUMPTION <0.5W

OVER CURRENT

95 ~ 108% Constant current limiting or Hiccup mode, recovers automatically after fault condition is removed

SHORT CIRCUIT PROTECTION
OVER VOLTAGE

Hiccup mode, recovers automatically after fault condition is removed

14 ~ 17V

28 ~ 34V

Shut down and latch off o/p voltage, re-power on to recover

OVER TEMPERATURE

Shut down output voltage, re-power on to recover

WORKING TEMP.

Tcase=-20 ~ +90 (Please refer to ” OUTPUT LOAD vs TEMPERATURE” section)

MAX. CASE TEMP.

Tcase=+90

WORKING HUMIDITY

20 ~ 95% RH non-condensing

ENVIRONMENT STORAGE TEMP., HUMIDITY -40 ~ +80, 10 ~ 95% RH

TEMP. COEFFICIENT

±0.03%/ (0 ~ 50)

VIBRATION

10 ~ 500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY STANDARDS

UL8750,CSA C22.2 No. 250.13-12, ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384, EAC TP TC 004, GB19510.1,GB19510.14, IS15885(Part2/Sec13) approved

WITHSTAND VOLTAGE

I/P-O/P:3.75KVAC

ISOLATION RESISTANCE I/P-O/P:100M Ohms / 500VDC / 25/ 70% RH

Parameter

Standard

Test Level / Note

Conducted

BS EN/EN55015(CISPR15) ,GB/T17743 —–

EMC EMISSION

Radiated

BS EN/EN55015(CISPR15) ,GB/T17743 —–

Harmonic Current

BS EN/EN61000-3-2,GB/T17625.1

Class C @load60%

SAFETY &

Voltage Flicker

BS EN/EN61000-3-3

—–

EMC

BS EN/EN61547

Parameter

Standard

Test Level / Note

ESD

BS EN/EN61000-4-2

Level 3, 8KV air ; Level 2, 4KV contact

Radiated

BS EN/EN61000-4-3

Level 2

EMC IMMUNITY

EFT / Burst Surge

BS EN/EN61000-4-4 BS EN/EN61000-4-5

Level 2 1KV/Line-Line

Conducted

BS EN/EN61000-4-6

Level 2

Magnetic Field

BS EN/EN61000-4-8

Level 2

Voltage Dips and Interruptions

BS EN/EN61000-4-11

>95% dip 0.5 periods, 30% dip 25 periods, >95% interruptions 250 periods

MTBF

4150.1K hrs min. Telcordia SR-332 (Bellcore) ; 362.8K hrs min. MIL-HDBK-217F (25)

OTHERS DIMENSION

280*30*16.8mm (L*W*H)

NOTE

PACKING

0.175Kg;64pcs/12.4Kg/ 0.67CUFT

, https://www.meanwell.com/serviceDisclaimer.aspx

File Name:SLD-50-SPEC 2022-02-18

50W Constant Power Mode LED Driver

SLD-50 series

SPECIFICATION

MODEL

SLD-50-56

RATED CURRENT

1050mA

RATED POWER

Note.2 50.4W

CONSTANT CURRENT REGION Note.3 30 ~56V

FULL POWER CURRENT RANGE 900~1400mA

OUTPUT OPEN CIRCUIT VOLTAGE (max.) 60V

CURRENT ADJ. RANGE

450-1400mA

CURRENT RIPPLE CURRENT TOLERANCE

5.0%(@rated current) ±5%

SET UP TIME

Note.5 500ms/230VAC, 1200ms/115VAC

VOLTAGE RANGE

110 ~ 305VAC 155VDC ~ 431VDC Note.2 (Please refer to “STATIC CHARACTERISTIC” ang ” DRIVING METHODS OF LED MODULE”section)

FREQUENCY RANGE POWER FACTOR (Typ.)

47 ~ 63Hz PF0.97 / 115VAC, PF0.95 / 230VAC, PF0.92 / 277VAC at full load (Please refer to “Power Factor Characteristic” section)

TOTAL HARMONIC DISTORTION

THD< 10% (@ load60% at 115VAC/230VAC ,@load75% at 277VAC) Please refer to “TOTAL HARMONIC DISTORTION (THD)” section

INPUT

EFFICIENCY (Typ.) AC CURRENT (Typ.) INRUSH CURRENT(Typ.)

90%
0.6A / 115VAC 0.3A / 230VAC 0.25A / 277VAC COLD START 50A(twidth=270s measured at 50% Ipeak) at 230VAC; Per NEMA 410

MAX. NO. of PSUs on 16A CIRCUIT BREAKER LEAKAGE CURRENT

8 unit(circuit breaker of type B) / 16 units(circuit breaker of type C) at 230VAC <0.25mA / 277VAC

NO LOAD POWER CONSUMPTION <0.5W

OVER POWER
PROTECTION SHORT CIRCUIT OVER VOLTAGE
OVER TEMPERATURE WORKING TEMP. MAX. CASE TEMP. WORKING HUMIDITY ENVIRONMENT STORAGE TEMP. TEMP. COEFFICIENT

110 ~ 150% Hiccup mode, recovers automatically after fault condition is removed Hiccup mode, recovers automatically after fault condition is removed 61 ~ 80V Shut down output voltage, re-power on to recovery Shut down output voltage, re-power on to recovery Tcase=-20 ~ +90(Please refer to “OUTPUT LOAD vs TEMPERATURE” section) Tcase=+90 20 ~ 95% RH non-condensing -40 ~ +80 ±0.03%/ (0 ~ 60)

VIBRATION

10 ~ 500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes

SAFETY STANDARDS

UL8750,CSA C22.2 No. 250.13-12, ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent, BS EN/EN62384, EAC TP TC 004, GB19510.1,GB19510.14, IS15885(Part2/Sec13) approved

WITHSTAND VOLTAGE

I/P-O/P:3.75KVAC

ISOLATION RESISTANCE
EMC EMISSION SAFETY & EMC

I/P-O/P:100M Ohms / 500VDC / 25/ 70% RH

Parameter

Standard

Test Level / Note

Conducted

BS EN/EN55015(CISPR15) ,GB/T17743 —–

Radiated

BS EN/EN55015(CISPR15) ,GB/T17743 —–

Harmonic Current

BS EN/EN61000-3-2,GB/T17625.1

Class C @load60%

Voltage Flicker

BS EN/EN61000-3-3

—–

BS EN/EN61547

Parameter

Standard

Test Level / Note

ESD

BS EN/EN61000-4-2

Level 3, 8KV air ; Level 2, 4KV contact

EMC IMMUNITY

Radiated EFT / Burst Surge Conducted

BS EN/EN61000-4-3 BS EN/EN61000-4-4 BS EN/EN61000-4-5 BS EN/EN61000-4-6

Level 2 Level 2 1KV/Line-Line Level 2

Magnetic Field Voltage Dips and Interruptions

BS EN/EN61000-4-8 BS EN/EN61000-4-11

Level 2
>95% dip 0.5 periods, 30% dip 25 periods, >95% interruptions 250 periods

OTHERS

MTBF DIMENSION PACKING

4150.1K hrs min. Telcordia SR-332 (Bellcore) ; 362.8K hrs min. 280*30*16.8mm (L*W*H) 0.175Kg;64pcs/12.4Kg/ 0.67CUFT

MIL-HDBK-217F (25)

NOTE

, https://www.meanwell.com/serviceDisclaimer.aspx

File Name:SLD-50-SPEC 2022-02-18

50W linear LED Driver
BLOCK DIAGRAM

EMI FILTER

I/P

&

RECTIFIERS

PFC CIRCUIT

POWER SWITCHING

O.T.P.

O.L.P.

PWM & PFC CONTROL

SLD-50 series

PFC fosc : 50~120KHz PWM fosc : 60~130KHz

RECTIFIERS

Vo+

& FILTER

Vo-

O.L.P.

DETECTION CIRCUIT

O.V.P.

DRIVING METHODS OF LED MODULE
SLD-50-12,24 This series is able to work in either Constant Current mode (a direct drive way) or
Constant Voltage mode (usually through additional DC/DC driver) to drive the LEDs.

100

Vo(%)

70 (min.)

(A) Constant
Voltage area

(B) Constant Current area

(C) Hiccup Protection

50

100

Io(%)

Typical output current normalized by rated current (%) SLD-50-56

60V 55V 50V 45V 40V 35V 30V 25V
!

450mA, 56V

EÖ ÆD

1400mA, 36V

900mA, 30V

1400mA, 3 0V

300mA

600mA

900mA

1200mA

1500mA

Recommend Performance Region

In the constant current region, the highest voltage at the output of the driver depends on the configuration of the end systems. Should there be any compatibility issues, please contact MEAN WELL.

File Name:SLD-50-SPEC 2022-02-18

LOAD (%)

50W linear LED Driver
OUTPUT LOAD vs TEMPERATURE

SLD-50 series

100

230VAC

80

60

50

110VAC

40

20

-20 -10

0

15

30 40 50

60 65 70 (HORIZONTAL)

AMBIENT TEMPERATURE,Ta ()

STATIC CHARACTERISTIC

100 90 80 70 60 50 40
100 110 125 135 145 155 165 175 180 200 230 305
INPUT VOLTAGE (V) 60Hz De-rating is needed under low input voltage.

TOTAL HARMONIC DISTORTION (THD)

24V Model, Tcase at 75

14 12 10
8 6 4 2
50% 60% 70% 80% 90% 100%
LOAD

277V 230V 115V

EFFICIENCY(%)

PF LOAD (%)

100 80 60 40 20

-20 -15

0

15

30

50

60

90 (HORIZONTAL)

Tcase ()

POWER FACTOR (PF) CHARACTERISTIC
Tcase at 75 Constant Current Mode

1 0.9 0.8 0.7 0.6 0.5 0.4 0.3
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
LOAD

277V 230V 115V

EFFICIENCY vs LOAD
SLD-50 series possess superior working efficiency that up to 90% can be reached in field applications. 24V Model, Tcase at 75

96%

94%

92%

90%

277V

88% 230V
86%

84%

115V

82%

80%

78% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

LOAD

THD LOAD (%)

File Name:SLD-50-SPEC 2022-02-18

50W linear LED Driver

SLD-50 series

LIFE TIME

LIFETIME(Kh)

120 100
80 60 40 20 0
25 30 35 40 45 50 55 60 65 70 75 80 85 90 Tcase ()
Mechanical Specification

Unit:mm

TB1
2-3.5

280 272
T case

56V with Io adjustable TB2
4 113.6

22 4

30

20.1

T case: Max. Case Temperature.

16.8

TB1 wiring: 9-10mm

0.75-1.50mm2

Terminal Pin No. Assignment (TB1) : DEGSON DG219-3.5(GRAY)

Pin No. 1 2

Assignment AC/L AC/N

INSTALLATION MANUAL
Please refer to:http://www.meanwell.com/manual.html

TB2 wiring: 9-10mm

0.75-1.50mm2

Terminal Pin No. Assignment (TB2) : DEGSON DG219-3.5(RED/BLACK)

Pin No. 1 2

Assignment +V -V
