Pure110+ and AC200+ Adhesive Anchoring System
Product Information:
The DEWALT Pure110+ and AC200+ are adhesive anchoring and
post-installed reinforcing bar connection systems. These systems
are designed to provide strong and reliable connections in
construction applications.
The adhesive used in these systems has a published working time,
which is the amount of time during which it can be used
effectively. It is important to follow the instructions provided in
the MPII (Manufacturer’s Product Information and Instructions) for
proper usage.
Product Usage Instructions:
- Before starting the installation, ensure that you have the
necessary DEWALT piston plug assembly, which includes the nozzle,
flexible tubing extension, and piston plug. - Follow the standard installation instructions provided in the
MPII until you reach Step #3. - In Step #3, if the initial cartridge is depleted and you need
to continue with consecutive installations, you can transfer the
piston plug assembly from the depleted cartridge to a new
cartridge. - To transfer the piston plug assembly, carefully remove it from
the depleted cartridge and attach it to the new cartridge. - Once the transfer is complete, you need to balance the new
cartridge by following the steps provided below:
- Ensure that the piston plug assembly is securely attached to
the new cartridge. - Restart the dispensing of adhesive into the hole within the
published working time of the adhesive. - Make sure to complete this balancing step before the working
time of the adhesive expires.
replace the piston plug assembly with each new cartridge.
tested and determined to be equivalent to the standard procedures
given in the MPII.
If you have any technical questions or need further assistance,
you can contact DEWALT at [email protected] or call (800)
524-3244.
September 19, 2019
DEWALT 701 East Joppa Road Towson, MD 21286 P: (800) 524-3244 anchors.DEWALT.com
DEWALT Pure110+ and AC200+ Adhesive Anchoring and Post-Installed Reinforcing Bar Connection Systems
Supplemental Installation Instructions for Preparation of the Adhesive in Step #3: Cartridge Balancing
Cartridge adhesives must be properly mixed to achieve published properties for anchoring applications into concrete and masonry. In accordance with the Manufacturer’s Printed Installation Instructions (MPII) the supplied mixing nozzle must be attached to the cartridge. The cartridge is loaded into the recommended dispensing tool. Prior to dispensing adhesive into the drilled hole, separately dispense at least three full strokes of adhesive through the mixing nozzle until the adhesive is a consistent color: product must be Red color for mixed Pure110+ product or Gray color for mixed AC200+ product.
During consecutive installations using DEWALT piston plugs, it is permissible to transfer the piston plug assembly (nozzle, flexible tubing extension and piston plug) to a new cartridge when the initial cartridge is depleted. For the transfer and continued use of the piston plug assembly to be viable, the cartridge balancing steps shown below and restart of dispensing adhesive into the hole must be completed within the published working time of the adhesive as provided in the MPII.
Procedure for Cartridge Balancing: 1. Remove piston plug assembly from the depleted cartridge. 2. Load a new cartridge into dispensing tool (without new mixing nozzle). 3. Remove cap and balance cartridge by dispensing adhesive until both components are flowing separately and equally through the cartridge opening. Suggest removing any excess adhesive from cartridge opening prior to the next step. 4. Attach nozzle of piston plug assembly to the balanced cartridge. 5. Resume dispensing and placement of adhesive into hole.
Step #3
Provided these steps are followed, replacing the piston plug assembly with each new cartridge is not necessary. This supplemental procedure for cartridge balancing has been tested and determined to be equivalent to the standard procedures given in the MPII.
Technical Bulletin
1
Anchoring and Fastening Systems from DEWALT Anchors & Fasteners
