HAY-1403-PN Eight Light Ceiling Mount
Product Information
- Model: HAY-1403-PN
- Part Number: HAY-1403-PN
- Assembly Instruction: Included
- Fixture Rating: Dry Rated
- Recommended Bulb Type: Candelabra Base Bulb
- Recommended Bulb Wattage: 40 Watts
- Maximum Bulb Wattage: 60 Watts
- Extended Use: Use LED Bulbs
- Electrical Safety: All electrical components must be installed
by a licensed electrician in accordance with the National Electric
Code and the appropriate local electrical codes. - California Proposition 65 Warning: This product can expose you
to Lead, which is known to the State of California to cause cancer
and/or birth defects or reproductive harm. For more information go
to www.P65Warnings.ca.gov
Assembly Instructions
- Attach the mounting plate onto the outlet box using two outlet
screws. - Hang the frame onto the mounting plate by hooking the cable
wire into the slots as shown. - Install bulbs (not included) and proceed to connecting the
power. - Insert the pin into the crystal and then insert the crystal
onto the band ring. - After all the crystals are installed, raise the fixture up to
the ceiling and secure with the finial.
Detailed Illustration
Part Numbers
- A. (2)-Wire Connector
- B. (1)-Mounting Plate
- C. (2)-Outlet Box Screws
- D. (2)-Ground Wire
- E. (2)-Cable Wire
- F. (1)-Frame
- G. (1)-Washer
- H. (1)-Nut
- I. (1)-Check Ring
- J. (1)-Finial (XFB1400PNFIN)
Part Bags
- Part Bag 1: Includes Parts A, C
- Part Bag 2: Includes Parts B, G, H, I, J
LIGHTING THE WAY FOR SIXTY YEARS ASSEMBLY INSTRUCTION MODEL #HAY-1403-PN
WARNING:
8″
18″
DETAILED ILLUSTRATION
A
20
200
B
20
150
C
20 100
Electrical Danger Turn Power Off
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
C
U R
L
C
You will need 8-Candelabra Base Bulb
B
40 Watts Recommended 60 Watts Max
A
USE LED BULBS FOR EXTENDED USE
The fixture is dry rated
How to Install
1. Attach the mounting plate onto the outlet box using two outlet screws.
2. Hang the frame onto the mounting plate by hooking the cable wire into the slots as shown.
3. Install bulbs (not included) and proceed to connecting the power.
4. Insert the pin into the crystal and then insert the crystal onto the band ring.
5. After all the crystal are installed, raise the fixture up to the ceiling and secure with the finial.
Pin
Crystal Sets
A. 12Sets. (1)30x200mm B. 24Sets. (1)30x150mm C. 36Sets. (1)30x100mm
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer and/or birth defects or reproductive harm. For more information go to www.P65Warnings.ca.gov
LIGHTING THE WAY FOR SIXTY YEARS
PART NUMBER MODEL #HAY-1403-PN
Part Number
Part Numbers A. (2)-Wire Connector B. (1)-Mounting Plate C. (2)-Outlet Box Screws D. (2)-Ground Wire E. (2)-Cable Wire F. (1)-Frame G. (1)-Washer H. (1)-Nut I. (1)-Check Ring J. (1)-Finial (XFB1400PNFIN)
PART BAG: Includes Parts A, C PART BAG : Includes Parts B, G, H, I, J
