HAY-1400-AG Four Light Ceiling Mount
Product Information:
- Model: #HAY-1400-AG
- Part Number: MODEL #HAY-1400-AG
- Fixture Type: Ceiling Light
- Power Source: Electrical
- Bulb Type: Candelabra Base Bulb
- Recommended Bulb Wattage: 40 Watts
- Maximum Bulb Wattage: 60 Watts
- Bulb Compatibility: LED Bulbs for extended use
- Rating: Dry Rated
Assembly Instructions:
- Attach the mounting plate onto the outlet box using two outlet
screws. - Hang the frame onto the mounting plate by hooking the cable
wire into the slots as shown. - Install bulbs (not included) and proceed to connecting the
power. - Insert the pin into the crystal and then insert the crystal
onto the band ring. - After all the crystals are installed, raise the fixture up to
the ceiling and secure it with the finial.
Parts Included:
- (2) Wire Connector
- (1) Mounting Plate
- (2) Outlet Box Screws
- (1) Ground Wire
- (2) Cable Wire
- (1) Frame
- (1) Washer
- (1) Nut
- (1) Check Ring
- (1) Finial (Part Number: XFB1400AGFIN)
LIGHTING THE WAY FOR SIXTY YEARS ASSEMBLY INSTRUCTION MODEL #HAY-1400-AG
WARNING:
Electrical Danger Turn Power Off
All electrical components must be
installed by a licensed electrician
in accordance with the National
Electric Code and the appropriate
local electrical codes.
C
U R
L
10.25″
16″
DETAILED ILLUSTRATION
A
20
250
B
20
200
B A
You will need 4-Candelabra Base Bulb
40 Watts Recommended 60 Watts Max
USE LED BULBS FOR EXTENDED USE
The fixture is dry rated
How to Install
1. Attach the mounting plate onto the outlet box using two outlet screws.
2. Hang the frame onto the mounting plate by hooking the cable wire into the slots as shown.
3. Install bulbs (not included) and proceed to connecting the power.
4. Insert the pin into crystal and then Insert the crystal onto the band ring.
5. After all the crystal are installed, raise the fixture up to the ceiling and secure with the finial.
Pin
Crystal Sets
A. 21Sets. (1)30x250mm B. 32Sets. (1)30x200mm
Outlet box
LIGHTING THE WAY FOR SIXTY YEARS
PART NUMBER MODEL #HAY-1400-AG
Part Number
Part Numbers A. (2)-Wire Connector B. (1)-Mounting Plate C. (2)-Outlet Box Screws D. (1)-Ground Wire E. (2)-Cable Wire F. (1)-Frame G. (1)-Washer H. (1)-Nut I. (1)-Check Ring J. (1)-Finial (XFB1400AGFIN)
PART BAG: Includes Parts A, C PART BAG : Includes Parts B, G, H, I, J
D
