99-7427B Nissan Kit
Product Information
The 99-7427 is a kit designed for the installation of an
aftermarket radio in a Nissan Maxima 2009-2014 (non-nav models)
(w/o tech package). The kit includes various components, such as
module brackets, factory Torx head screws, metal DIN sleeve, trim
ring, and ISO brackets, among others. The kit features an ISO DIN
radio provision with pocket and a DIN radio provision with
pocket.
Product Usage Instructions
- Disconnect the negative battery terminal before starting the
installation process. - Follow the dash disassembly instructions to remove the factory
radio and module. - Attach the module brackets to the radio housing using two
Phillips head screws supplied. - Secure the module to the completed assembly using two factory
Torx head screws removed from dash disassembly. - Remove the metal DIN sleeve from the aftermarket radio and
slide the sleeve into the Radio Housing. Secure by bending the
metal locking tabs outward. - Slide the radio back into the sleeve until it clicks in.
- Mount the new radio assembly into the dash and reassemble the
dash in reverse order of disassembly. - Locate the factory wiring harness and antenna plug in the dash
and make all necessary connections to the radio. Use proper mating
adapters from Metra and/or AXXESS. - Re-connect the negative battery terminal and test the radio for
proper operation. - If you encounter any difficulties during installation, refer to
the instructions again before calling Metra’s Tech Support line at
1-800-253-TECH. Have the vehicle apart and ready to perform
troubleshooting steps before calling.
Installation instructions for part 99-7427
Nissan Maxima 2009-2014 (non nav models) (w/o tech package) 99-7427
KIT FEATURES
· DIN Radio Provision With Pocket · ISO DIN Radio Provision With Pocket · PAINTED TO MATCH FACTORY DASH:
99-7427B=BLACK, 99-7427G=GRAY · Textured To Match Factory Dash
KIT COMPONENTS
· A) Radio Housing · B) Trim Plate · C) ISO Brackets · D) Module Brackets · E) (2) Phillips Head Screws
A
B
C
D
E
Table of Contents
Dash Disassembly …………………………………………. 2 Kit Preparation………………………………………………. 2 Kit Assembly DIN Radio Provision With Pocket……………………… 3 ISO DIN Radio Provision With Pocket ……………….. 3
REV. 7/16/2015 INST99-7427
WIRING & ANTENNA CONNECTIONS (sold separately) Wiring Harness: · 70-7552 Antenna Adapter: · 40-NI12 TOOLS REQUIRED · Torx Screwdriver · Panel Removal Tool · Phillips Screwdriver
METRA. The World’s best kits.TM
metraonline.com
CAUTION! Metra recommends disconnecting the negative bat-
tery terminal before beginning any installation, unless the vehicle manufacturer recommends against so. Please check with your local Dealership for more information. All accessories, switches, climate controls panels, and especially air bag indicator lights must be connected before reconnecting the battery or cycling the ignition. Also, do not remove the factory radio with the key in the on position, or the vehicle running. It would be best to remove the key from the ignition and then wait a few seconds before removing the factory radio.
© COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
Dash Disassembly
1. Unclip and remove the panel above the radio including the a/c vents and the climate controls. Unplug and remove the panel. (Figure A)
2. Unclip and remove the panel below the radio. (Figure B)
3. Remove (6) Phillips screws securing the radio. Unplug and remove the radio. (Figure C)
4. Remove (4) Torx head screws securing each side bracket to the factory radio. Remove (1) Torx head screw from each side of the module below the radio, and then remove the radio and module. Retain the module and (2) screws for re-use during kit assembly. (Figure D)
Continue to kit preparation
(Figure B) (Figure C)
(Figure A)
X PASS AIR BAG
OFF
CD CHANGER
AUX IN
(Figure D)
99-7427
Kit Preparation
1. Attach the module brackets to the radio housing using (2) Phillips head screws supplied. (Figure A)
2. Secure the module to the completed assembly using (2) factory Torx head screws removed from dash disassembly. (Figure B) Continue to kit assembly
(Figure A)
(Figure B)
2
DIN radio provision with pocket
1. Remove the metal DIN sleeve from the aftermarket radio.
2. Slide the sleeve into the Radio Housing and secure by bending the metal locking tabs outward. (Figure A)
3. Slide the radio back into the sleeve until it clicks in. (Figure B)
4. Locate the factory wiring harness and antenna plug in the dash and make all necessary connections to the radio. Metra recommends using the proper mating adapters from Metra and/or AXXESS. Re-connect the negative battery terminal and test the radio for proper operation.
5. Mount the new radio assembly into the dash and reassemble the dash in reverse order of disassembly.
(Figure A)
(Figure B)
99-7427
Kit Assembly
ISO DIN radio provision with pocket
1. Remove the metal DIN sleeve and trim ring from the aftermarket radio.
2. Mount the ISO brackets to the radio using screws supplied with the radio. (Figure A)
3. Slide the completed assembly into the Radio Housing until it clicks in. (Figure B)
4. Snap the Trim Plate onto the front of the Radio Housing. (Figure B)
5. Locate the factory wiring harness and antenna plug in the dash and make all necessary connections to the radio. Metra recommends using the proper mating adapters from Metra and/or AXXESS. Re-connect the negative battery terminal and test the radio for proper operation.
6. Mount the new radio assembly into the dash and reassemble the dash in reverse order of disassembly.
3
(Figure A) (Figure B)
Installation instructions for part 99-7427
IMPORTANT
If you are having difficulties with the installation of this product, please call our Tech Support line at 1-800-253-TECH. Before doing so, look over the instructions a second time, and make sure the installation was performed exactly as the instructions are stated. Please have the vehicle apart and ready to perform troubleshooting steps before calling.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry. Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow.
REV. 7/16/2015 INST99-7427
