BEAMZ MADE EAZY
150.455 V1.0
SP420IP
QUICK START GUIDE
| MENU | DESCRIPTION | |
| DMX ADDR | AOOI-Axxx | Select dmx start address |
| CHANNEL MODE | 1-CH | Choose between 1, 3, 5 or 9 channel mode |
| AUTO | CCQ0-CC99 CP00-CP99 DEOO-DE99 | Jump mode from slow to Fast Fade mode from slow to Fast Pulse mode From slow to fast |
| MANUAL | 0000- 0255 y000 – y255 | Dimmer Amber All Leds Dimmer Warm white All leds |
| DISPLAY | ON / OFF | Display On/ Off |
DMX CHANELS
1 CHANNEL
| CHANNEL | FUNCTION | VALUE | DESCRIPTION |
| 1 | Tungsten mode | 000-255 | Full tungsten mode on 4 Leds |
3 CHANNELS
| CHANNEL | FUNCTION | VALUE | DESCRIPTION |
| 1 | Master dimmer | 000-255 | Master dimmer |
| 2 | Dimmer | 000-255 | Amber |
| 3 | Dimmer | 000-255 | Warm White |
5 CHANNELS
| CHANNEL | FUNCTION | VALUE | DESCRIPTION |
| 1 | Ma s t e r dimmer | 000-255 | Master dimmer |
| 2 | Tungsten mode | 000-255 | Tungsten mode Led 1 |
| 3 | 000-255 | Tungsten mode Led 2 | |
| 4 | 000-255 | Tungsten mode Led 3 | |
| 5 | 000-255 | Tungsten mode Led 4 |
9 CHANNELS
| CHANNEL | FUNCTION | VALUE | DESCRIPTION |
| 1 | Master dimmer | 000-255 | Master dimmer |
| 2 | Dimmer Led 1 | 000-255 | Amber |
| 3 | Dimmer Led 1 | 000-255 | Warm White |
| 4 | Dimmer Led 2 | 000-255 | Amber |
| 5 | Dimmer Led 2 | 000-255 | Warm White |
| 6 | Dimmer Led 3 | 000-255 | Amber |
| 7 | Dimmer Led 3 | 000-255 | Warm White |
| 8 | Dimmer Led 4 | 000-255 | Amber |
| 9 | Dimmer Led 4 | 000-255 | Warm White |
