150.780_150.782_150.784 V1
WBP-SERIES PAR
QUICK START GUIDE
UNPACKING INSTRUCTION
CAUTION!
Immediately upon receiving the product, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damage from shipping or the package itself shows signs of mishandling. Save the package and all packing materials. In the event that the product must be returned to the factory, it is important that the product be returned in the original factory box and packing.
If the unit has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on immediately. The arising condensation water might damage your unit. Leave the unit switched off until it has reached room temperature.
POWERSUPPLY
On the label on the backside of the unit is indicated on this type of power supply must be connected. Check that the mains voltage corresponds to this, all other voltages than specified, the light effect can be irreparably damaged. The product must also be directly connected to the mains and may be used. No dimmer or adjustable power supply.
The unit has a powerconnector output on board. Depending on the local conditions several units can be linked by power connector in- and output. Connect a maximum of four (when using 230V/16A) units in a row. Use an approved three-core cable with a cross-section of at least 1.5 mm². The installation instructions of the manufacturer and the colour coding of the cable must be observed. Do not turn off the unit by turning the power connector but use the power on/off switch or schuko!
WARNING!
Always connect the unit to a protected circuit (circuit breaker or fuse). Make sure the unit has an appropriate electrical ground to avoid the risk of electrocution or fire.
RIGGING
The unit may be set up on a stable and even surface. By means of the fixing facilities of the baseplate, the unit can also be mounted upside down to a truss, see below picture. For fixing, certified clamps with correct save working load are required. According to the figure, the quick lock bolts of the omega brackets are placed into the openings provided in the base plate and turned clockwise until they lock (to the stop). The mounting place must be of sufficient stability and be able to support a weight of 10 times of the unit’s weight. Secure the unit with a safety cable so that it cannot fall down.
When carrying out any installation, always comply European and national guidelines concerning rigging, truss and all other safety issues. Always let the installation checked out by an authorized dealer !
WIRELESS DMX
| OMX UNIVERSE | COLOUR | DMX CHANNELS |
| 1 | Red | 1- 512 |
| 2 | Green | 1- 512 |
| 3 | Yellow | 1- 512 |
| 4 | Blue | 1- 512 |
| 5 | Magenta | 1- 512 |
| 6 | Cyan | 1- 512 |
| 7 | White | 1- 512 |
DMX CHANNELS
D001
| CHANNEL | FUNCTION | VALUE | SESCRIPTION |
| 1 | Colour | 000-255 | Red, 0-100% |
| 2 | 000-255 | Green, 0-100% | |
| 3 | 000-255 | Blue, 0-100% | |
| 4 | 000-255 | White, 0-100% | |
| 5 | 000-255 | Amber, 0-100% | |
| 6 | 000-255 | UV, 0-100% |
A001
| CHANNEL | FUNCTION | VALUE | SESCRIPTION |
| 1 | Msaster | 000-255 | Master dimmer, 0-100% |
| 2 | Colour | 000-255 | Red, 0-100% |
| 3 | 000-255 | Green, 0-100% | |
| 4 | 000-255 | Blue, 0-100% | |
| 5 | 000-255 | White, 0-100% | |
| 6 | 000-255 | Amber, 0-100% | |
| 7 | 000-255 | UV, 0-100% | |
| 8 | Strobe | 000-005 | No function |
| 006-255 | Strobe, from slow to fast | ||
| 9 | Preset colours | 000-010 | No function |
| 011-127 | 40 preset colours | ||
| 128-129 | No function | ||
| 130-255 | 64 factory colours | ||
| 10 | Mode | 000-019 | No function |
| 020-079 | 18 Chases | ||
| 080-127 | Custom chases | ||
| 128-159 | 63 Colour fade | ||
| 128-159 | 63 Colour fade | ||
| 160-191 | 63 Colour jump | ||
| 192-223 | 63 Colour pulse | ||
| 224-255 | Sound control | ||
| 11 | Speed | 000-255 | Speed, from slow to fast |
| 12 | Dimmer curve | 000-005 | No function |
| 006-055 | Dimmer response, Extreme fast | ||
| 056-105 | Dimmer response, Fast | ||
| 106-155 | Dimmer response, Less fast | ||
| 156-205 | Dimmer response, Middle | ||
| 206-255 | Dimmer response, Slow |
