  • Unplug machine
  • Empty dirt tank by pressing the release button on top of the carrying handle and pulling off machine
  • Separate the lower portion of the dirt tank by pressing the latch on the upper portion on front of machine
    • Lower portion can be hand washed
    • Allow to dry completely before reassembling
    • Clean the screen of upper portion to remove any debris
  • Remove the pre-motor filter located behind the dirt tank by pushing the tab at the top of clear door
    • Wash the filter with water and a mild detergent
    • Allow to dry completely before reassembling
  • With the dirt tank removed, open the filter cover by pulling it up and unscrew the post-motor filter
  • Tap this filter against a waste bin to remove any excess dust or debris
  • Remove the upholstery hose from the back of the vacuum, pushing in the Hose Release on the left and pulling the hose up from the hose holder on the right
    • Run a broom handle through the hose to remove any clogs
  • Remove the lower hose by unscrewing the 3 Screws that hold on the clear plastic window
    • Pull lower hose down flat and run a broom handle through to remove any clogs
  • Check the Air Flow Diverter inside the clear window of lower hose
    • The diverter should be to the right for suction from the hose and to the left for suction from the floor
