GK800 Series Durable Strikes for Residential and Business
Product Information
The GK800 series electric strikes are durable strikes designed
for residential and business use. They provide different models to
accommodate various applications and locksets. The GK800 is
compatible with European latches and cylindrical locks, while the
GK810 is designed for European mortise locks. The GK850 is suitable
for use with ANSI/Euro locks for universal range applicability, and
the GK880 includes an ANSI faceplate for cylindrical/mortise
locksets.
The electric strikes feature a brushed stainless steel finish
and are made of zinc alloy construction for durability. They have a
static strength of 800 lbs (363 Kg) and come with a stainless steel
keeper for enhanced security. The strikes are non-handed and fully
reversible, allowing for fail-safe or fail-secure operation. They
have an endurance of 1,000,000 cycles.
The GK880 model includes three faceplates of different sizes and
optional lip extensions. It can be set to fail-secure when two
faceplates are facing up or fail-safe when one faceplate is facing
up.
Product Usage Instructions
- To install the electric strike, follow the instructions
provided in the installation manual. - Ensure that the electric strike is compatible with your lockset
type (European latches, cylindrical locks, European mortise locks,
or ANSI/Euro locks). - Choose the appropriate model of the electric strike based on
your lockset type. - If using the GK880 model, select the desired faceplate size and
optionally use the lip extensions. - Connect the electric strike to a power source with a dual 12/24
VDC voltage. - For fail-safe operation, ensure that one faceplate is facing up
on the GK880 model. For fail-secure operation, make sure that two
faceplates are facing up. - If desired, the fail-safe or fail-secure setting can be changed
by reversing the round screw on the electric strike. - Test the electric strike to ensure proper functioning.
Note: For any warranty-related information or specifications
changes, please refer to the manufacturer’s website or contact them
directly.
Electric Strikes
GK800 Series
Durable Strikes for Residential and Business
GK800
European Style
GK810
European Style
(For doors with deadbolt entry)
GK850
Universal (For ANSI/Euro locks)
GK880
ANSI Style
The GK800 series electric strike provides different models to accommodate various applications and locksets. It includes an optional latch monitor and is field reversible for fail-safe or fail-secure operation. The GK800 is compatible with European latches and cylindrical locks. The GK810 is designed for use with European mortise locks . The GK850 is suitable for use with ANSI/Euro locks for universal range applicability. The GK880 includes ANSI faceplate for cylindrical/mortise locksets.
Standard Features
Brushed stainless steel finish Endurance 1,000,000 cycles Field reversible fail-safe or fail-secure Non-handed fully reversible Static strength 800 lbs (363Kg) Zinc alloy construction Stainless steel keeper for enhanced security
Changing Fail-Safe / Fail-Secure
Fail-safe or fail-secure is field reversible by reversing the round screw.
Optional Feature
Latch monitor
GK880 Special Features
Includes 3 faceplates of different sizes Optional lip extensions
Fail-secure when “2” facing up.
Fail-safe when “1” facing up.
1
GIANNI INDUSTRIES, INC.
Tel: +886-2-2267-7986 Fax: +886-2-2267-9876 www.gianni.com.tw [email protected]
GK800 Series Electric Strikes
Models
Faceplate
Width (mm)
Voltage (VDC)
Current Draw
GK800
25.4
Dual 12/24
GK810
25
Dual 12/24
GK850
28
Dual 12/24
GK880
31.8
Dual 12/24
ºLatch Monitor : Optional
300mA/12VDC 150mA/24VDC
300mA/12VDC 150mA/24VDC
300mA/12VDC 150mA/24VDC
300mA/12VDC 150mA/24VDC
Dimensions
30.5 25.4
20.2
Latch Throw (mm)
Reversible Fail-Safe Or Fail-Secure
12
12
15
19
31 25 14
20.2
Finish Brushed stainless steel Brushed stainless steel
Silver Brushed stainless steel
44
80
250
235.4
80 44 146.5 160
40
12
74
2.5
GK800
34 39.25
4.5 3
GK810
37.7
31.8
43
31.8
30 136
149.5 44.5 123.8 174.6
168 201.6
19
3
28
19.3
4.9
31.8
1.5 3
GK850
GK880 with 3 faceplates
All dimensions in mm
Warranty The proudct is warranted against defects in material and workmanship while used in normal service for a period of 3 years from the date of sale to the original client. The GEM policy is one of continual development and improvement; therefore GEM reserves the right to change specifications without notice.
