WB-ENCL1-BLK Wall Mount Bracket for Thin Client Small PC Enclosures

Product Information: WB-ENCL1-BLK or WB-ENCL1-SS4 Wall Mount
Bracket for Thin Client / Small PC Enclosures

The WB-ENCL1-BLK or WB-ENCL1-SS4 Wall Mount Bracket is designed
to be used with Thin Client or Small PC Enclosures. The bracket is
available in two finishes, black (BLK) and stainless steel
(SS4).

The bracket comes with four 1/4-20 bolts for mounting the
enclosure to the bracket. However, the fasteners for mounting the
bracket to the wall surface are not provided.

The bracket has custom hole options for conduit entry into the
rear of the enclosure, or holes in the enclosure. Please refer to
Figure 1 for measurements and hole placement.

Product Usage Instructions

1. Refer to Figure 1 for custom hole placement and
   measurements.
2. Cut holes in the bracket for conduit entry into the rear of the
   enclosure, or cut holes in the enclosure.
3. Mount the bracket to a wall surface using four 1/4 fasteners
   (not provided).
4. Mount the Thin Client or Small PC Enclosure to the bracket
   using the provided four 1/4-20 bolts.

Please note that it is important to use appropriate tools and
safety measures when installing this product. If you have any
questions or concerns, please refer to the user manual or contact
our customer service team for assistance.

Installation Instructions
WB-ENCL1-BLK or WB-ENCL1-SS4 Wall Mount Bracket for Thin Client / Small PC Enclosures

1. Refer to Figure 1. Cut holes in the bracket for conduit entry into the rear of the enclosure, or cut holes in the enclosure.
2. Refer to Figure 1. Mount the bracket to a wall surface using four 1/4″ fasteners (not provided).
3. Mount the enclosure to the bracket using the provided four 1/4-20 bolts.

CUSTOM HOLE OPTION

26.0 mm (1.02″) 62.9 mm (2.47″)
330.2 mm (13.00″)

110.2 mm (4.34″)
FIGURE 1 ­ REAR VIEW

155.6 mm (6.12″)

63.5 mm (2.5″)

355.6 mm (14.00″)

WB-ENCL1-xxx WALL MOUNT
BRACKET

FIGURE 2 ­ SIDE VIEW

THIN CLIENT ENCLOSURE

355.6 mm (14.00″)
355.6 mm (14.00″)
FIGURE 3 ­ FRONT VIEW OF ENCLOSURE
