You-Bend™ Arrowg+ard Blue® Two-Lumen
Hemodialysis Catheter for
High Volume Infusions
Contents:
1: Two-Lumen Catheter‡: 12 Fr. (4.06 mm OD) x 20 cm Radiopaque Polyurethane with Blue FlexTip®, ARROWg+ard® Antimicrobial Surface Treatment, Extension Line Clamps
1: Spring-Wire Guide, Marked: .035″ (0.89 mm) dia. x 26-3/4″ (68 cm) (Straight Soft Tip on One End – “J” Tip on Other) with Arrow Advancer
1 : Catheter: 18 Ga. x 2-1/2″ (6.35 cm) Radiopaque over 20 Ga. RW Introducer Needle
1: Pressure Transduction Probe
1: Introducer Needle: 18 Ga. x 2-1/2″ (6.35 cm) XTW and 5 mL Arrow® Raulerson Spring- Wire Introduction Syringe
1 : Tissue Dilator: 12 Fr. (4.0 mm) x 14 cm
2: Dust Cap: Non-Vented
1 : Drape: 24″ x 36″ (61 cm x 91 cm)
1 : Scalpel: #11 All components are CE 2797 unless otherwise noted.
All components are CE 2797 unless otherwise noted.
Rx only
Warning: Read all package insert warnings, precautions, and instructions prior to use.
Failure to do so may result in severe patient injury or death. www.teleflex.com/IFU California Prop. 65
⚠ WARNING: Cancer and Reproductive Harm. www.P65Warnings.ca.gov
‡MR Conditional Not made with natural rubber latex. Store below 25°C (77°F). Avoid excessive heat above 40°C (104°F). Fluid path components are non-pyrogenic. Contraindications: The Arrow large-bore two-lumen catheter is not designed for long-term (≥ 30 days) hemodialysis or for use in patients with thrombosed vessels. The Arrowg+ard Blue antimicrobial catheter is contraindicated for patients with known hypersensitivity to chlorhexidine, silver sulfadiazine, and/or sulfa drugs.
 Lumen | Priming Volume* (mL) | Flow Rate (mL/min) | Venous Pressure Setting†† (mmHg) |
| Distal ( 12 G a . ) | 1.8 | 200 | 100 |
| Proximal ( 12 G a . ) | 1.7 | 340 | 200 |
| 200 | 100 | ||
| 340 | 200 | ||
* Priming volumes are approximate and are done without accessories. †† Blood flow rates are approximate and were determined by varying the venous pressure setting from 100 to 200 mmHg in an in vitro experiment using a blood analog solution.
You-Bend™ Arrowg+ard Blue® Two-Lumen Hemodialysis Catheter for High-Volume Infusions
EU Authorized Representative and Importer:
Teleflex Medical IDA Business and
Technology Park Dublin Road, Athlone Co.Westmeath, Ireland
Arrow International LLC
Subsidiary of Teleflex Incorporated
3015 Carrington Mill Blvd.
Morrisville, NC 27560 USA
www.teleflex.com
LBL058902 R 00 (2021-06)
