HED6045/BT Bluetooth Dimmable LED Drivers with Bluetooth 5.0 SIG Mesh
Product Information
The HED6045/BT is a Bluetooth dimmable LED driver with a maximum
power output of 45W. It is designed for direct projects or new
luminaire designs for lighting manufacturers. With Bluetooth
wireless mesh networking, it enables easy communication between
luminaires without the need for hardwiring, saving costs and time.
The driver features a Switch-Dim interface using a push switch and
Bluetooth dimming interface. It also includes various hardware
features such as insulated terminal cover, active power factor
correction, logarithmic and linear dimming, configurable constant
current output, and more. The driver is equipped with safety
features like overload protection, short-circuit protection,
open-circuit protection, and device firmware update over-the-air
(OTA). It comes with a 5-year warranty and is designed for a long
lifetime of up to 50,000 hours.
Product Usage Instructions
- Setup and commissioning can be done via the dedicated
smartphone app available for both iOS and Android platforms. - For advanced setup and project planning, use the app’s quick
setup mode or advanced setup mode. The floorplan feature simplifies
project planning. - For on-site configuration, there is an iPad version of the app
called rKoolmesh Pro. - You can group luminaires via the mesh network to control them
collectively. - Create scenes with detailed motion sensor settings to customize
lighting effects. - Configure push switch settings for controlling the driver.
- Schedule scenes to run based on specific times and dates.
- Utilize the astro timer feature to synchronize lighting with
sunrise and sunset. - Ensure correct current selection before starting the
driver. - The driver is compatible with EnOcean self-powered switch
module PTM215B (HBES01/W & HBES01/B). - For further technical specifications and precautions, refer to
the product manual available at www.hytronik.com/download.
LED Drivers with
5.0 SIG Mesh
HED6045/BT Dimmable Driver & Constant Current
Product Description
HED6045/BT is a Bluetooth dimmable LED driver, with maximum power
output of 45W. It comes with Switch-Dim interface by using Push switch
(retractive switch) and of course Bluetooth dimming interface. It is ideal for
direct projects or new luminaires design for lighting manufacturers. With
Bluetooth wireless mesh networking, it makes communication between
luminaires much easier without time-consuming hardwiring, which eventually
saves costs for projects. Meanwhile, simple device setup and commissioning
can be done via
app.
DApp Features Quick setup mode & advanced setup mode Floorplan feature to simplify project planning Web app/platform for dedicated project management rKoolmesh Pro iPad version for on-site configuration Grouping luminaires via mesh network a Scenes Detailed motion sensor settings Push switch configuration f Schedule to run scenes based on time and date t Astro timer (sunrise and sunset)
Hardware Features Switch-Dim Flicker free (1-100%)
ANALOGUE
Bluetooth dimmable control Insulated terminal cover with cord restraint >0.93 Active PFC design Logarithmic Dimming Linear Dimming Configurable constant current (CC) output via DIP switch Loop-in and loop-out terminals for efficient installation
Staircase function (primary & secondary) Internet-of-Things (IoT) featured
Open-circuit Open-circuit Protection Protection
Device firmware update over-the-air (OTA)
Short-circuit Protection
Device social relations check
Overload Protection
Bulk commissioning (copy and paste settings) Power-on status (memory against power loss)
5-year warranty, designed for long lifetime up to 50,000 hours
Offline commissioning Different permission levels via authority management
* Certain scenes which require external photocell can
Network sharing via QR code or keycode
be achieved by using together with Hytronik Bluetooth
Remote control via gateway support HBGW01 Interoperability with Hytronik Bluetooth product portfolio
sensors,such as HBIR29, HCD038/BT + sensor head etc.
Compatible with EnOcean switch HBES01/W & HBES01/B
Continuous development in progress…
Subject to change without notice.
Edition: 11 Jul. 2022 Ver. Draft Page 1/6
5.0 SIG mesh
iOS
Android
for iOS
for Android
Smartphone app for both iOS & Android platform
for iPad
Koolmesh Pro app for iPad
Web for Web
Web app/platform: www.iot.koolmesh.com
Output Configuration
Fully support EnOcean self-powered switch module PTM215B (HBES01/W & HBES01/B)
D1050mA 1000mA 950mA 900mA 800mA 700mA 600mA 500mA 350mA 12345 rWarning: Please make sure the correct current is selected before starting the driver!
a Technical Specifications
Bluetooth Transceiver Operation frequency
f Transmission power t Range (Typical indoor)
2.4 GHz – 2.483 GHz 4 dBm 10~30m
Environment Operation Temp. Case Temp. (Max.) IP Rating
-20 ~ +50 80 IP20
Protocol
5.0 SIG Mesh
Safety and EMC
Input Mains Voltage Mains Current Power Factor Max. Efficiency Psb/Pno
220~240VAC 50/60Hz 0.24~0.22A 0.95 89% <0.5W
EMC Standard
Safety Standard Dielectric strength Abnormal protection
EN55015, EN61547,
EN61000-3-2/-3-3, EN300328,
EN301489-1/-17, EN50663
EN61347-1, EN61347-2-13
Input¹output: 3000VAC / 5mA /1min Output short-circuit protection Overload Protection Open-circuit Protection
Output Output Current Output Voltage Uout Max. Turn-on Time
Dimming Interface
350mA~1050mA 10-54V 75VDC <0.5s
Switch-Dim
Max. output power/current/voltage range
HED6045/BT
3.5-19W/ 350mA /10-54VDC
5-27W/ 500mA /10-54VDC 6-32W/ 600mA /10-54VDC 7-38W/ 700mA /10-54VDC
8-42W/ 800mA /10-52VDC 9-45W/ 900mA /10-50VDC 9.5-45W/ 950mA /10-47VDC 10-45W/ 1000mA /10-45VDC 10.5-44W/ 1050mA /10-42VDC
Subject to change without notice.
Edition: 11 Jul. 2022 Ver. Draft Page 2/6
Mechanical Structure & Dimensions
P1 P2
L
N
LED+ LED
LED current selection
3.9
DBuilt-in installation r a f 126
129.4
t 140.6
79.2
Stand-alone installation 4.1
185
79.2
23
23
Wire Preparation
0.75 – 1.5mm 8mm
To make or release the wire from the terminal, use a screwdriver to push down the button.
Subject to change without notice.
Edition: 11 Jul. 2022 Ver. Draft Page 3/6
Wiring Diagram
P1
P1
P1
P2
P2
P2
L
L
N
L
N
N
LED+ LED
P1 P1 P2
D P2 L L N N LED+ LED
r a Note: There is no need for any hardwirings on “push” terminal between one driver to another. The installer only needs to connect the push switches to the nearest driver to save labor and cost. The push switches can be assigned to control any Bluetooth driver through the app commissioning.
f t Loading and In-rush Current
Model
HED6045/BT
In-rush Current (Imax.)
17.8A
Pulse Time
72 s
Circuit Breaker Information
Automatic circuit breaker type HED6045/BT
B16A 43
B10A 27
B13A 35
B20A 54
B25A 67
The data above is calculated according to the formula: Maximum Amount = 16/(Pn/230). In order to provide a more reliable reference in real application, the data have been revised to take 60% of the number calculated, i.e. 16/(Pn/230) x 60%. Please kindly take note that the calculation is based on ABB circuit breaker series S200. Actual values may differ due to different types of circuit breaker used and installation environment.
Subject to change without notice.
Edition: 11 Jul. 2022 Ver. Draft Page 4/6
Performance Characteristics
1.0
0.9
1.00 0.8
0.98 0.7
0.96
EFFICIENCY
0.6
0.94
PF Power output(%)
0.5
500mA
0.92
0.4
700mA
0.90
1000mA
0.88
0.3
0.86
0.2
0.84
0.1
0.82
220V 230V 240V
0
50%
60% 70% 80% 90% 100% LOAD
0
50%
60%
70%
80%
90% 100% LOAD
D* Typical Efficiency vs Load
* Typical Power Factor vs Load
Dimming Characteristics
100
100
r90
90
80
80
70
70
a 60
60
50
50
40
40
30
30
20
20
10
10
f 0
0
t 10 20 50 100
1% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
Power output(%)
Dim Level
Dim Level
Dimming Interface Operation Notes
Switch-Dim
The provided Switch-Dim interface allows for a simple dimming method using commercially available non-latching (momentary) wall switches. Up to 64 LED drivers maybe connected to one switch. Detailed Push switch configurations can be set on Koolmesh app.
Switch Function
Action
Descriptions
Short press (<1 second) * Short press has to be longer than
0.1s, or it will be invalid.
– Turn on/off – Turn on only – Turn off only
– Recall a scene – Exit manual mode – Do nothing
Push switch
Double push Long press (1 second)
– Turn on only – Turn off only – Recall a scene
– Dimming – Colour tuning – Do nothing
– Exit manual mode – Do nothing
Simulate sensor
/
– Upgrade a normal on/off motion sensor to a Bluetooth controlled motion sensor
Subject to change without notice.
Edition: 11 Jul. 2022 Ver. Draft Page 5/6
Additional Information / Documents
1. Regarding precautions for LED driver installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->LED Drivers – Precautions for Product Installation and Operation
2. To learn more about detailed product features/functions, please refer to www.hytronik.com/download->knowledge ->Introduction of App Scenes and Product Functions
3. Regarding precautions for Bluetooth product installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->Bluetooth Products – Precautions for Product Installation and Operation
4. Data sheet is subject to change without notice. Please always refer to the most recent release on www.hytronik.com/products/bluetooth technology ->Bluetooth Drivers
5. Regarding Hytronik standard guarantee policy, please refer to
D r a f t www.hytronik.com/download ->knowledge ->Hytronik Standard Guarantee Policy
Subject to change without notice.
Edition: 11 Jul. 2022 Ver. Draft Page 6/6
