Product Information: Front Panel Bottom-Hinged

The front panel of this product is designed to be bottom-hinged,
allowing for easy access to the interior components. The product
comes with various screws and bolts, including Torx M 2.5 x 5 and M
2.5 x 12,3, for installation and assembly. The product is
compatible with europac PRO, ratiopac PRO, compac PRO, and propac
PRO enclosures.

Product Usage Instructions

Begin by identifying the correct enclosure for your product:
europac PRO, ratiopac PRO, compac PRO, or propac PRO.
Using the appropriate screws and bolts provided, attach the
front panel to the bottom hinge of the enclosure.
If necessary, use additional screws and bolts to secure the
front panel to the sides of the enclosure.
To access the interior components of the product, simply lift
the front panel up from the bottom hinge.

Note: Make sure to follow the torque specifications provided in
the user manual when tightening screws and bolts. Also, please note
that some components may not be included in the product package.
Refer to the user manual for more information.

View Fullscreen

Benutzeranleitung Frontplatte klappbar

User Manual Front panel bottom-hinged

Instructions utilisateur Faces avant modulaires abattantes

05/18 Telefon: +49(0)70 82 7 94-0 Telefax: +49(0)70 82 7 94 200

Schroff GmbH www.nvent/schroff.com Langenalber Straße 96 – 100 D-75334 Straubenhardt

60817 – 226 Rev.007

1/4

1a (1x)

3 (2x / 3x)
Torx M 2,5 x 5

4 (2x / 3x)
Torx M 2,5 x 12

5 (3x)
