FFE-PLHLP Eureka P L Iso Lateral Horizontal Leg Press

Product Information

Product Name: FRENCH FITNESS EUREKA P/L ISO-LATERAL HORIZONTAL
LEG PRESS

Model: FFE-PLHLP

Warranty: 10 Years Part, 1 Year Labor (Commercial)

Product Usage Instructions

Assembly Steps

  1. Attach part number 8118-0900 to the main frame using 8 M10*125
    screws and 8 flat gaskets.
  2. Attach part number 8118-0100 to the main frame using 8 M10
    locknuts and 8 flat gaskets.
  3. Attach part number 8118-0200 to the main frame using 8 M10
    locknuts.
  4. Attach part number 8118-1600 to the main frame using a 6#
    hexagonal screwdriver and wrench.
  5. Attach part numbers 8118-1200, 8118-0500, and 8118-1100 to the
    main frame using a M10*70 screw, 4 M10*6 screws, and 8 M10
    locknuts.
  6. Attach part numbers 8118-1300, 8118-0400, and 8118-0300 to the
    main frame using a M10*70 screw, M10*6 screws, and M10 flat
    gaskets.
  7. Attach part numbers Barbell combination and Back cushion to the
    main frame.
  8. Attach part number 8118-0700B to the main frame.
  9. Attach part number Cushion to the main frame.
  10. Attach part number 8118-0004 to the main frame using 16 M10*70
    screws and 12 M8*20 screws.

Please refer to the provided parts list and plastic package
screw schedule for detailed information on individual parts and
screws required for assembly.

FFE-PLHLP
FRENCH FITNESS EUREKA P/L ISO-LATERAL HORIZONTAL LEG PRESS
ASSEMBLY MANUAL

FEATURES
· Paint Color: Silver · Vinyl Color: Black · 11 gauge steel · High quality steel tube ASTM A36 with 50 x 80 x 3mm · Tungsten Inert Gas (TIG) welding · Quality PU leather · Electrostatic powder coating · California Residents see Prop 65 WARNINGS
TECH SPECS
· Weight: 326 lb (148 kg) · Dimensions: 71″L x 60″W x 61″H (L:1780mm, W:1520mm, H:1530mm)
WARRANTY
10 Years Part, 1 Year Labor (Commercial)

TABLE OF CONTENTS
PARTS LIST …………………………………………………………………….4 PLASTIC PACKAGE SCREW SCHEDULE …………………………..6 MAIN FRAME ASSEMBLY STEPS………………………………………7

Parts list-1 (individual packaging)

No.1

8118-0900*1pc

No.2

8118-0100*1pc

No.3

8118-0200*1pc

No.4

8118-0600*1pc

No.5

8118-1200*1pc

No.6

8118-0500*1pc

No.7

8118-1100*1pc

No.8

8118-1300*1pc

No.9

8118-0400*1pc

No.10

0300*1pc

No.11

8118-0600*1pc

No.12

8118-0700*1pc

No.13

Barbell combination*4pcs

No.14

8118-0700B left*1pc

No.15

Cushion*1pc

No.16

0004*1pc

No.17

Back cushion*1pc

No.18

8118-0700C right*2pcs

4

Parts list-2 (assembly parts)

No.19

8118-1000*1pc

No.20

8118-1400*1pc

No.21

Stainless steel pedal*2pcs

No.22

Plunger*1pc

No.23

Galvanized shaft*2pcs

No.24

Spring*1pc

No.25

Circlip for 45 holes*4pcs

No.26

GT004*4pcs

No.27

Stainless steel plug*6pcs

No.28

Aluminum cap*4pcs

No.29

End plug*4pcs

No.30

Tube plug 0607*11pcs

No.31

Tube olug 0606*9pcs

No.32

Aluminum part*2pcs

5

Parts list-3 (assembly parts)

No.33

Hard rubber*8pcs

No.34

New foot pad cap*4pcs

No.35

Rubber sleeve*4pcs

Plastic package screw schedule-4 (standard parts)

A

Hexagon head screws M10*700

B

Hexagon head screws M10*25

C

Hexagon head screws M10*125

D

Cross recessed round head screws M6*10

E

Hexagon head screws M10*20

F

Hexagon head screws M10*95

G

Locknut M10

H

Hexagon socket head screw M6*20

I

Flat gasket M10

J

Hexagon socket head screw M6*8

6

Main frame assembly steps

Step

No.

Name

Qty

No.

Name

Qty

No.1

8118-0900

1

C

M10*125

8

No.2

8118-0100

1

I

Flat gasket

8

1

No.3

8118-0200

1

G

Locknut M10

8

No.4

8118-1600

1

Tools/equipment

6# Hexagonal screwdriver, wrench

7

Step 2

No. No.5 No.6 No.7

Tools/equipment

Main frame assembly steps

Name 8118-1200 8188-0500 8118-1100
M10*70

Qty

No.

Name

Qty

1

M10*6

4

1

M10 Lucknut

8

1

M10 Flat gasket

8

4

6# Hexagonal screwdriver, wrench

8

Main frame assembly steps

Step

No.

Name

Qty

No.

Name

Qty

No.8

8118-1300

1

No.12

8188-0700

1

No.9

8118-0400

1

3

No.10

8118-0300

1

No.11

8118-0600

1

Tools/equipment

9

Main frame assembly steps

Step

No.

Name

Qty

No.

Name

Qty

No.13

Barbell combination

4

No.17

Back cushion

1

No.14

8118-0700B

1

4

No.15

Cushion

1

M10*70

16

M8*20

12

No.16

8118-0004

1

Tools/equipment

10
