ELGi D400T4F Powerful plus Compact Air Compressor
INSTRUCTION
Maximize your productivity with the dual-pressure D4004F air compressor. You’ll get more work done operating at 100psi and 150psi, longer run-time and digital controller.
- 5-Year/Unlimited Hour Airend Warranty
- 2 x 3/4″ and 1 x 2″ service outlets are placed at the rear of the machine with the digital controller for operator safety
- The Intelligent Start/Stop System prevents cold-starting and blowback
- Cummins’ quiet and efficient engine provides 11-hours of runtime
- Large, double-doors on both sides of the D400 T4F allow for easy access to the spin-on filters and the oversized coolers for fast cleaning
OPTIONS
- Aftercooler
- Cold Weather Package
- Skid
- Telematics
D400T4F
| COMPRESSOR | |
| Capacity – Pressure (psi) | 100 psi – 150 psi Switchable |
| Capacity – Volume (cfm) | 375 cfm |
| Minmum Workig Pressure | 73 psi |
| Drive System Engine-Airend | Direct Drive |
| Compressor Coling System | Air/Oil |
| Oil Cooling Capacity | 7.79 gal |
| Air Outlet Temperature | 105°F + Ambient Temperature |
| Outlet Valves | 2 X 3/4″ +1X 2″ |
| Bettery Capacity | 2 x 12V 74Ah 680A |
| Fuel Tank Capacity | 53gal |
| Fuel Consumption | tt.gph |
| Dimensions with Running Gear (Skid Configuration) | L-168″ W- 76″ H-78″ (Skid L-112″ W- 54″ H- 72″) |
| Dry Weight with Running Gear (Skid Configuration) | 4,950 lbs (Skid 4,345 lbs) |
| DIESEL ENGINE/ ENVIRONMENTAL CONDITIONS | |
| Engine Make | CUMMINS |
| Engine Type | QSF3.8 |
| Engine System | 4 Strokes – Turbo lntercooler Common Rail |
| Displacement | 3800 cc |
| N.Cylinders | |
| Aspiration | Turbo lntercooler |
| Max Engine Power @2200 RPM | 130HP |
| Max Engine Speed | 2200 RPM |
| Min Engine Speed | 1200 RPM |
| Cooling system | Water |
| Cooling System Capacity | 5.81gal |
| Lubrication System | Oil |
| Lubrication System Capacity | 4.12 gal |
| Max Ambient Temperature | |
| Min Working Temperature | |
SERVICE+ SUPPORT
- 5-Year/Unlimited Hour Airend Warranty
- 2-Year/Ll-000-Hour Cummins Engine Warranty
- 1-Year/2000-Hour Full Machine Warranty
- Parts+ Service Help: 70Ll–523-Ll-123 or [email protected]
PORT ABLE COMPRESSORS
elgi.us/portable
