MF 2200 Wimberley Single Library Wall Light
Product Information:
The Wimberley Single Library Wall Light (Item # MF 2200) is a
light fixture that provides illumination for library spaces. It is
designed to be installed on a wall and requires proper assembly and
installation.
Important Notice: This light fixture should be installed in
accordance with all applicable, local installation codes, and by a
person familiar with its construction and operation, as well as the
hazards involved. Before installation, carefully inspect the item
and its contents for any damage or defects. If any issues are
found, do not proceed with the installation. Retain all packaging
material until installation is complete and approved.
Assembly Instructions:
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Remove the mounting plate (A) from the fixture (D) by
unscrewing screws (E). - Install the mounting plate (A) to the junction box and securely
fasten it using mounting screws (B). - Wrap the fixture ground wire (bare copper) around the green
grounding screw (G) and tighten it. - Connect the fixture wires to the corresponding wires in the
junction box using wire connectors or as per local electrical
codes. - Securely attach the fixture (D) to the mounting plate (A) using
screws (E). - If provided, follow Diagram 1 for additional assembly
instructions. - Adjust the position of the fixture using the loosen knobs (J),
then tighten them to secure the desired position. - Install a compatible light bulb into the socket.
Care Instructions:
To maintain the cleanliness and appearance of the Wimberley
Single Library Wall Light, follow these care instructions:
- Use only a soft dry cloth or feather duster to clean the
fixture. - Avoid using abrasive or chemical agents, as they may damage the
surface.
Note: Bulb not included. Ensure you use a suitable light bulb
that meets the specifications recommended by the manufacturer.
ASSEMBLY INSTRUCTIONS
C
J J
BA ED F
G (Packaged separately)
Diagram 1
H Bulb not included
Wimberley Single Library Wall Light
Item # MF 2200
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Scissors
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (A) from fixture (D) by removing screws (E). 3. Install mounting plate (A) to the junction box and secure with
mounting screws (B). 4. Wrap fixture ground wire (bare copper) around the green grounding
screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (C). NOTE: It is imperative that the fixture is grounded. 5. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (C). 6. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (C). CAUTION: Do not reverse the hot and neutral connections. 7. Make sure all wire connections are tight, then carefully tuck into the junction box. 8. Install fixture (D) to mounting plate (A) and secure with screws (E). 9. Remove socket ring (H) from socket (F). 10. Remove shade (G) from packaging and install to socket (F) by securing with socket ring (H). NOTE: If shade has additional packaging, carefully cut off from interior of shade to avoid damages.
M
LI ST ED
US
ASSEMBLY INSTRUCTIONS
C
J J
BA ED F
G (Packaged separately)
Diagram 1
H Bulb not included
Wimberley Single Library Wall Light Item # MF 2200
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
11. Loonsen knobs (J) to adjust fixture to desired position, then tighten knobs (J).
12. Install light bulb into socket.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
