CHD2527 Small Single Wall Light
Product Information:
- Product Name: Parkington Small Single Wall Light
- Item Number: CHD2527
- Includes: Glass Shade, Metal Shade
- Bulb not included
- Approved for use in the US
- LED compatible
Product Usage Instructions:
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Remove the mounting plate (B) from the fixture by unscrewing
the screws (D). - Install the mounting plate (B) to the junction box and secure
it with the provided mounting screws (C). - Wrap the fixture ground wire (bare copper) around the green
grounding screw (E) on the mounting plate and tighten it. - Connect the fixture wires to the corresponding wires in the
junction box following the color-coded instructions. - Securely tighten all wire connectors.
- Attach the glass shade or metal shade to the fixture according
to your preference. - Insert a compatible LED bulb into the fixture. Ensure that the
bulb is properly seated and secure. - Turn on the power and test the light fixture to ensure proper
functioning.
Care Instructions:
Clean the light fixture only with a soft dry cloth or feather
duster. Do not use abrasive or chemical agents as they may damage
the surface.
ASSEMBLY INSTRUCTIONS
A
BC
D
E
Diagram 1 F
Glass Shade
Metal Shade
Bulb not included
Parkington Small Single Wall Light
Item # CHD2527
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (B) from fixture by removing screws (D). 3. Install mounting plate (B) to the junction box and secure with
mounting screws (C). 4. Wrap fixture ground wire (bare copper) around the green grounding
screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (A). NOTE: It is imperative that the fixture is grounded. 5. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (A). 6. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections. 7. Make sure all wire connections are tight, then carefully tuck into the junction box. 8. Install fixture to mounting plate (B) by securing with screws (D). 9. Remove thumbscrews (E) from fixture, then install shade (F) to fixture body and secure with thumbscrews (E). NOTE: Do not over-tighten otherwise glass could become damaged. 10. Install light bulb into the socket.
Care Instructions: Clean only with a soft dry cloth or feather duster.
Do not use abrasive or chemical agents.
M
L IST ED
US
LED
