AG324UX Monitors

Product Information

The AG324UX is a TFT color LCD monitor that has a viewable image
size of 80.0cm diagonal (31.5” wide screen) and a pixel pitch of
0.181mm(H) x 0.181mm(V). It has a maximum resolution of
3840×2160@144Hz and a horizontal scan range of 30k-255kHz. The
monitor comes with a stand, base, screwdriver, quick start guide,
warranty card, power adaptor, DP cable, HDMI cable, USB cable, USB
C-C Micphone Quick Switch cable, and Keypad. The connector types
include HDMI, DP, USB C, USB, Earphone, and Microphone
In&Out.

Product Usage Instructions

Unpack the monitor and all its components from the
packaging.
Attach the stand to the base using the screwdriver
provided.
Connect the power adaptor to the monitor and plug it into a
power outlet.
Connect your computer or other device to the monitor using
either HDMI, DP, or USB C cable.
Turn on the monitor by pressing the power button located at the
bottom of the monitor.
Adjust the monitor settings using the Keypad to suit your
preferences.
To turn off the monitor, press the power button again or switch
off the power outlet.

Note: Please refer to the user manual for detailed instructions
on how to operate the monitor and adjust its settings. Also, make
sure to check the compatibility of your device with the monitor
before making any connections.

View Fullscreen

Find your product and get support

FAQ
Europe
https://eu.aoc.com/en/support

Driver

User Manual

https://eu.aoc.com/ru/support

Australia
https://au.aoc.com/user_manual

Hong Kong S.A.R.
https://hk.aoc.com/user_manual

New Zealand
https://nz.aoc.com/user_manual

Philippines
https://ph.aoc.com/user_manual

Singapore
https://sg.aoc.com/user_manual

https://th.aoc.com/user_manual

Vit Nam
https://vn.aoc.com/user_manual

Middle East
https://me.aoc.com/user_manual

https://tw.aoc.com/user_manual

Indonesia
https://id.aoc.com/user_manual

South Africa
https://za.aoc.com/user_manual

Brasil
https://aoc.portaltpv.com.br/

https://jp.aoc.com/user_manual
Malaysia
https://my.aoc.com/user_manual

https://kr.aoc.com/user_manual

India
https://www.aocindia.com/ download_manuals.php

Myanmar
https://mm.aoc.com/user_manual
Printed in China

US/Canada
https://us.aoc.com/en-US/ downloads
Q41G32M1615XXX

Quick Start
AG324UX
www.aoc.com ©2022 AOC.All Rights Reserved

Monitor

Stand

Base

Screwdriver

Quick Start

Warranty Card

Power Adaptor DP

Cable

HDMI Cable

USB USB C-C Micphone Quick Switch

Cable Cable

Cable

Keypad

*Different according to countries/regions
Display design may differ from that illustrated

2
1
3 4

Fast Charger

130mm

HDMI 1 HDMI 2

USBC PC

3
POWER

HDMI1 HDMI2
DP USB C

Light FX Light FX Mode Pattern

Medium Breathing Rainbow

Game Mode

Off

General Specification

Panel

Model Name Driving System Viewable Image Size Pixel Pitch

AG324UX TFT Color LCD 80.0cm diagonal(31.5” Wide Screen) 0.181mm(H) x 0.181mm(V)

Horizontal Scan Range 30k-255kHz

Horizontal Scan Size(Maximum)

697.3056mm

Vertical Scan Range
Vertical Scan Size(Maximum)

48-144Hz 392.2344mm

Max Resolution

3840×2160@144Hz

Others

Plug & Play Power Source
Power Consumption

VESA DDC2B/CI

20.0Vdc, 14.0A
Typical (default brightness and contrast) Max. (brightness =100, contrast =100)
Standby mode

57W 240W 0.5W

Off mode

0.3W(DC Switch Off)

Dimensions(with stand) 714.1x(499.6~629.6)x400.1mm(WxHxD)

Net Weight

Physical

Connector Type

Characteristics Signal Cable Type

10.0kg HDMI / DP/ USB C/ USB / Earphone / Microphone In&Out
Detachable

Temperature

Operating

0°C~ 40°C

Non-Operating -25°C~55°C

Environmental Humidity Altitude

Operating

10%~85% (non-condensing)

Non-Operating 5%~93% (non-condensing)

Operating

0~5000m (0~16404ft )

Non-Operating 0~12192m (0~40000ft )
