Full Size Gas Convection Oven
Parts Diagram for the Gas Convection Oven
| No. | Part No. | Description | Qty |
| 1 | COF-1-1 | REAR CHIMNEY | 1 |
| 2 | HOUSING ASSEMBLY UNIT | 1 | |
| 3 | LEFT SIDE PANEL | 1 | |
| 4 | RACK | 5 | |
| 5 | RACK HOLDER | 2 | |
| 6 | CONVECTION HOT AIR COMPARTMENT ASSEMBLY | 1 | |
| 7 | COF-7 | DOOR STOPPER ASSEMBLY | 2 |
| 8 | DOOR SHAFT BUSH | 6 | |
| 9 | COF-9 | LEFT DOOR ASSEMBLY | 1 |
| 10 | COF-10 | RIGHT DOOR ASSEMBLY | 1 |
| 11 | LOWER FRONT COVER PLATE | 1 | |
| 12 | COF-12 | WATER-PROOF SWITCH | 3 |
| 14 | COF-14 | TIMER | 1 |
| 15 | COF-15 | BURNER ASSEMBLY | 1 |
| 16 | COF-16 | THERMOSTAT | 1 |
| 17 | CONTROL PANEL ASSEMBLY | 1 | |
| 18 | COF-18 | HOT SURFACE IGNITER | 1 |
| 19 | COF-19 | IGNITION CONTROLLER | 1 |
| 20 | COF-20 | TERMINALS | 1 |
| 21 | TRAVEL SWITCH | 2 | |
| 23 | TRANSFORM ER | 1 | |
| 24 | COF-24 | LEG ASSEMBLY | 4 |
| 25 | CONNECTOR | 4 | |
| 26 | CASTER | 4 | |
| 27 | COF-27 | BUZZER | 1 |
| 28 | STRAIGHT TUBE | 1 | |
| 29 | GR-32 | CONNECTOR | 2 |
| 30 | NUT | 2 | |
| 31 | HOOP | 2 | |
| 32 | MAI NF OLD | 1 | |
| 33 | MICRO SWITCH | 1 | |
| 34 | NOZZLE | 3 | |
| 35 | BULB LAMP HOLDER ASSEMBLY | 1 | |
| 36 | RIGHT SIDE PANEL | 1 | |
| 37 | COF-37 | SAFETY VALVE | 1 |
| 38 | ELBOW | 1 | |
| 39 | STRAIGHT TUBE | 3 | |
| 40 | UNION | 1 | |
| 41 | BALL VALVE | 1 | |
| 42 | ELBOW | 1 | |
| 43 | GAS INLET PIPE | 1 | |
| 44 | TURBO FAN | 1 | |
| 45 | HEAT SHIELD ASSEMBLY | 1 | |
| 46 | MOUNTING CONTOUR POST | 4 | |
| 47 | INSULATION PAD | 1 | |
| 48 | FAN | 1 | |
| 49 | 61N FOOT | 4 |
