ML-400 Electric Lock

Product Information: ML-400 Electric Lock

The ML-400 Electric Lock is a series of locks available in three
different models: Mortise mount (ML-400M), Surface mount
(ML-400MSMB), and Surface mount for frameless glass doors &
walls (ML-400MVGL).

Specifications:

Strike Plate Dimensions: 28mm x 28mm x 35mm
Mortise Mount Model Dimensions: 210mm x 185mm x 160mm
Surface Mount Model Dimensions: 50mm x 32.5mm x
180mm/200mm
Glass Mount Model Dimensions: 56mm x 53.5mm x 212mm
Power Input: 12~24VDC/AC
Door Status Output: 1A/125VAC

Components:

Electric lock assembly
Mounting hardware
Wiring connector

Product Usage Instructions:

Mortise Mount Installation:

Ensure the template is the correct way up.
Align the center line (CL) of the lock body template with the
CL of the door leaf. Ensure the CL of the strike plate template
matches the lock body CL as closely as possible.
Tighten the fixing lugs with screws.
Connect power cable to the lock and test before screwing to the
door leaf.

Surface Mount Installation:

Attach the electric lock to the door frame using the mounting
hardware provided.
Connect power cable to the lock and test before securing to the
door leaf.

Glass Mount Installation:

Confirm the installation location and clean the surface of the
glass.
Take off the sticker on the back side of the spacer and attach
the spacer to the glass. Add more spacers if needed per glass
thickness. Use silicone sealant or other adhesives to secure the
bracket firmly.
Tighten the set screws with an Allen wrench, secure the
electric lock to the glass bracket, and then install the
cover.
It is recommended to attach the spacers to the interior/secured
side of the door.
Tighten the set screws firmly but do not overtighten to cause
damage to the glass.
The glass thickness should be 10~13 mm. The bracket can be
adjusted to properly align the position of strike plate and lock
body depending on the door gap ranging from 6 to 10 mm.

View Fullscreen

M L-4 0 0 Ele c t ric Lock Installation Instruction

Specifications
Operating Voltage: 12 ~ 24 VDC/AC Current Draw: 280mA/12VDC; 180mA/24VDC Locking Mode: Fail-Safe Operating Temperature: -10°C~+49°C Humidity: 0~85% non-condensing Applicable to horizontal and vertical installation For single/double action swing doors Latch Throw: 16mm Endurance Rating: 250,000 cycles (Factory tested) Static strength: 1,500 lbs Preload: 500 lbs of pressure strength
ML-400 Series Models
ML-400M: Mortise mount ML-400MSMB: Surface mount ML-400MVGL: Surface mount (for frameless glass doors & walls)
Strike Plate Dimensions

Mortise Mount Model Dimensions

210 185 160

40.5

ML-400M

Unti:mm 2 12

150 125 150 125 100
150 125 100 210 185 210 185 100 210 185 100

2
KP-ML-400-A

2
KP-ML-400-B

2
KP-ML-400-C

2 2
KP-ML-400-D KP-ML-400-E

2
KP-ML-400-F

Complete assembly

Wiring Diagram

Butt Splice (IDC) Connector
Using crimper or pliers and pressing the header of connector down to even position.

Red: + Black: –

12~24VDC/AC

Blue: N.O. Green: COM. Yellow: N.C.

Door Status Output: 1A/125VAC

4-1

Mortise Mount Installation
Door Loop (Optional)
The door loop protects the wiring from damage at the door hinge.

23.5

Door leaf

ø5.2mm

Unti:mm

ø5.2mm

Door Frame

23.5

210

Attention! Please ensure that the template is the correct way up.

5-1
Door Leaf

5-2

Frame

Door Leaf

5-3
ø5.2mm

ø5.2mm
Door Leaf

5-4
Door Leaf

23.5

Alignment CL

ø5.2mm

5-5

ø5.2mm

Frame

23.5

210

Align the center line (CL) of the lock body template with the CL of the door
leaf. Ensure the CL of the strike plate template matches the lock body CL as closely as possible.

ø5.2mm Cut out mortise holes for the lock body and strike plate and drill holes according to the templates.

Tighten the fixing lugs with screws.

Connect power cable to the lock and test before screwing to the door leaf.

Surface Mount Model Dimensions

28
ø5.2mm Affix the strike plate.
Unti:mm

32.5

180 200
180 200

4-2

Surface Mount Installation
Door Freme
Blind Nut

Blind Nut

Door Leaf

Interior/Secured Side
Glass Mount Model Dimensions

53.5

M6 x 25 Screw M6 x 25 Screw
Unti:mm

212 212

4-3

Glass Mount Installation
1.Confirm the installation location and clean the surface of the glasses. 2.Take off the sticker on the back side of the spacer and attach the space to the glass. Add more spacers if needed per glass thickness. Use silicone sealant
or other adhesives to secure the bracket firmly. 3.Tighten the set screws with an Allen wrench, secure the electric lock to the glass bracket, and then install the cover.
1.It is recommended to attach the spacers to the interior/secured side of the door. 2.Tighten the set screws firmly but do not overtighten to cause damage to the glass. 3.The glass thickness should be 10~13 mm. The bracket can be adjusted to properly align the position of strike plate and lock body depending on the door
gap ranging from 6 to 10 mm.

Spacer Frameless Glass Wall

Set Screws

Frameless Glass Door (10 to 13 mm thick)

Spacer

Set Screws

4-4
