SOB0158 Super Extend TV Mount
Product Information:
- Model Number: SOB0158
- Maximum Weight Capacity: 50kg/110Ibs
- Compatible with LCD/PLASMA TVs
- Compatible with VESA 100 / VESA 200 / VESA 200X100 / VESA 300 /
VESA 400 / VESA 400X200 / VESA 400X300 - Includes M8X16 screws (6) and M8 nuts (6)
- Manufactured by Sinox Europe A/S
- Address: Troensevej 11. DK-9220 Aalborg
- Website: www.sinox-europe.com
Product Usage Instructions:
- Identify the type of wall you will be mounting the TV on:
Concrete or Wooden Board. - If mounting on Concrete, use the screws provided in section 4a.
If mounting on Wooden Board, use the screws provided in section
4b. - Attach the screws to the wall using the appropriate method
(e.g. drilling for concrete, screwing into wooden board). - Attach the VESA mount on the back of the TV using the M8 screws
and nuts provided in sections 4c-1 and 4c-2. - Align the VESA mount on the back of the TV with the mount on
the wall and secure it in place.
SOB0158
MAX 50kg/110Ibs
Swivel 180°
Can be assembled with SOB0158 to fit LCD/PLASMA TV. Ready for use with: VESA 100 / VESA 200 / VESA 200X100 / VESA 300 / VESA 400 / VESA 400X200 / VESA 400X300
1
2a CONCRETE
X XX XX X
3a
2b WOODEN BOARD
X XX XX X
3b
4a
M8X16 SCREW(6)
M8 NUT(6)
4b 4c-1 4c-2
Sinox Europe A/S / Troensevej 11. DK-9220 Aalborg / www.sinox-europe.com
