VCON3450AT HDMI Converter
User Manual
Preface
Thank you for purchasing the Nedis VCON3450AT.
This document is the user manual and contains all the information for correct, efficient and safe use of the product.
This user manual is addressed to the end user. Read this information carefully before installing or using the product.
Always store this information with the product for use in the future.
Product description
Intended use
The VCON3450AT is an HDMI to VGA converter that converts digital HDMI signal into analog VGA video and analog audio.
The product is not intended for professional use.
Any modification of the product may have consequences for safety, warranty and proper functioning.
Specifications
Product | HDMI Converter |
Article number | VCON3450AT |
Dimensions (l x w x h) | 108 x 100 x 21 mm |
Bandwidth | 60 Hz |
Supported HDMI resolution | 1920 x 1200 @ 60 Hz |
1600 x 1200 @ 60 Hz | |
Input | 1 x HDMI 19 pin female |
Output | 1 x VGA HD 15 pin female |
1 R/L RCA audio connector | |
Power supply | 5 VDC |
Main parts (image A)
 |
A |
1. Power supply port |
2. Input signal indicator LED |
3. HDMI input |
4. VGA output |
5. Output signal indicator LED |
6. R/L output |
7. Power cable |
Safety instructions
WARNING
- Only use the product as described in this manual.
- Read the instructions before use.
- Do not use a damaged product.
- Do not expose the product to direct sunlight, naked flames or heat.
- Do not expose the product to water or moisture.
- Place the product on a stable and flat surface.
- Do not drop the product and avoid bumping.
- Do not open the product.
- Keep the product out of reach from children.
Use
- Make sure all the devices you want to connect have been turned off.
1. Plug an HDMI cable (not included) from your video source into A2.
- A3 lights up.
2. Plug a VGA cable (not included) from your display into A4.
- A5 lights up.
3. Plug an RCA cable (not included) from your speakers into A6.
4. Plug A8 into A7.
5. Plug the other end of A8 into a power outlet.
- The converter does not give an output when the HDMI source has copyright protection.
Maintenance
- Clean the product regularly with a soft, clean, dry cloth. Avoid abrasives that can damage the surface.
- Do not use aggressive chemical cleaning agents such as ammonia, acid or acetone when cleaning the product.
Warranty
Any changes and/or modifications to the product will void the warranty. We accept no liability for damage caused by improper use of the product.
Disclaimer
Designs and specifications are subject to change without notice. All logos, brands and product names are trademarks or registered trademarks of their respective owners and are hereby recognized as such.
Disposal
 | This symbol indicates that this product should not be thrown away with other household waste throughout the EU. To prevent possible harm to the environment or human health by uncontrolled waste disposal, you are responsible for recycling it so that it can promote the sustainable reuse of raw materials. To return your used product, you can use the regular return and collection systems or contact the store where the product was purchased. They can recycle this product for the environment. |
