Product Information: Product Name: Premium Single
Monitor Stand Model Number: TPM-MA01N-12-US1.0 Supported VESA
Sizes: 75×75, 100×100 Weight Capacity: 2~14kg (4.4~30.9lbs) Package
Contents: Upper Arm, Lower Arm, Base, Bracket, Base Support Cover,
VESA Plate, Clamp, Carriage Bolt, Grommet Base, Support Plate,
Wingnut, M6x10 Bolts, Pads, Bolt, 3mm Allen Key, 4mm Allen Key, 6mm
Allen Key, M4x12mm Screws, M4x16mm Screws, M6x12mm Screws, M6x16mm
Screws, D6mm Washer, Spacer H5mm Warning: Improper installation or
use may cause damage or serious injury. Keep small parts away from
children under 3 years old. Product Usage
Instructions: 1. Before starting assembly, check that all
necessary accessories are included and undamaged. 2. Clamp
Installation: – Mount Bracket (D) to Base (C) using Bolts (L) and
tighten with the 4mm Allen Key (P). – Attach Clamp (G) to Bracket
(D) using Bolts (L) and the 4mm Allen Key (P). – Adjust the Clamp
width to fit your desk and secure the stand to the desktop by
tightening the Clamp (G) or using the Allen key (Q). – Attach Base
Support Cover (E) to Bracket (D). 3. Grommet Base Installation: –
Place Carriage Bolt (H) through the center of Grommet Base (I). –
Mount Grommet Base to Base (C) using Bolts (L) and tighten with the
4mm Allen Key (P). – Run Carriage Bolt (H) through the Grommet Hole
on the desktop. – Attach Support Plate (J) and Wingnut (K), then
tighten the Wingnut (K). 4. Arm Installation: – Install the lower
arm (B) and the upper arm (A) to the base (C). – Secure the arm by
tightening the inside screw using the 3mm Allen Key (O). Do not
overtighten. – Note: Install the lower arm (B) with the labeled
side facing the base (C). 5. Attach Monitor: – For flat back
monitors, attach the VESA plate (F) to the back of the monitor
using the 6mm Allen Key (Q), screws (M-A or M-C), and washers
(M-E). Do not overtighten. – For curved back monitors, follow the
manufacturer’s instructions for attaching the monitor to the VESA
plate (F). 6. Ensure that the stand is securely attached to the
desk and do not move it outside of the desk area for safety. If you
have any questions or need assistance, please contact us via
Amazon.
Premium Single Monitor Stand
Instruction Manual
75×75 100×100
35″
2~14kg 4.4~30.9lbs
If you have any questions, please feel free to contact us via Amazon.
TPM-MA01N-12-US1.0
WARNING!
If you have any confusion or are not quite sure about the installation, please do not hesitate to ask for our help.
Before assembly, please check and make sure all necessary accessories are included and undamaged. Improper installation, such as using the product for monitors over its load capacity or for any purpose not explicitly specified, may cause damage or serious injury. We would not be liable for any damage or injury caused by improper mounting or inappropriate use.
The kit contains small items that could be choking hazards if swallowed. Please keep them OUT OF REACH OF CHILDREN UNDER 3 YEARS OLD. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x1) Upper Arm
B (x1) Lower Arm
C (x1) Base
D (x1) Bracket
E (x1) Base Support Cover
F (x1) VESA Plate
G (x1) Clamp
H (x1) Carriage Bolt
I (x1) Grommet Base
J (x1) Support Plate
K (x1) Wingnut
L(x5) M6x10
M (x4) Pad
N (x1) Bolt
O (x1) 3mm Allen Key
P (x1) 4mm Allen Key
Q (x1) 6mm Allen Key
M-A (x4) M4x12mm
M-B (x4) M4x16mm
M-C (x4) M6x12mm
M-D (x4) M6x16mm
30.9lbs 14kg
DO NOT EXCEED WEIGHT CAPACITY.
01
M-E (x4) D6mm Washer
M-F (x4) Spacer H5mm
NOTE: Not all hardware included will be used.
C
C1
Q
C1
Q
02
ASSEMBLY STEPS
STEP 1: Clamp Installation OR Grommet Base Installation
OPTION A: Clamp Installation Mount Bracket (D) to Base (C) with Bolts (L). Bolts could be tightened by the 4mm Allen Key (P). Apply pads (M) to the Bolts (L) to avoid desk scratches.
C
L
M
P
D
Similarly, attach Clamp (G) to Bracket (D) with Bolts (L) and 4mm Allen Key (P).
10-55mm 0.39-2.17″ 50-80mm 2.17-3.15″
D
OR
G
L
L D
G P
P
Adjust the Clamp width to fit with desk. Secure stand to desktop by tightening Clamp (G) or by Allen key (Q). Attach Base Support Cover (E) to Bracket (D).
D E
OR G
Q
03
STEP 1: (Continued)
OPTION B: Grommet Base Installation Place Carriage Bolt (H) through the center of Grommet Base (I). Mount Grommet Base to Base (C) bottom with Bolts (L) and tighten by 4mm Allen Key (P). Apply pads (M) to the Bolts (L) to avoid desk scratches.
M
C
P
I L
H
Run Carriage Bolt (H) through Grommet Hole on desktop. Attach Support Plate (J) and Wingnut (K). At last, tighten Wingnut (K).
J
K H
10-80mm 0.39-3.15″
ø 0.4~2.4″ ø 10~60mm
DESK
DESK
04
STEP 2: Arm Installation
Install the lower arm (B) and the upper arm (A) to the base (C). Secure the arm by tightening the inside screw using a 3mm Allen Key (O).
B
DO NOT tighten the screw excessively or it might be stripped.
C
O A
DO NOT tighten the screw excessively or it might be stripped.
O
Note: Please note that the side with the label”” is installed on the base(C) when installing the lower arm(B) to the base (C).
DESK
DESK
Please do not move stand outside desk for safety!
05
STEP 3 : Attach Monitor
OPTION A: Flat Back Monitor
Attach the VESA plate (F) to the back of monitor and secure it by using a 6 mm Allen Key (Q) to tighten screws (M-A or M-C) along with washers (M-E). Do not tighten the screws excessively or your monitor might be damaged.
F
OPTION B: Curved Back Monitor
Attach the VESA plate (F) to the back of monitor and secure it by using a 6 mm Allen Key (Q) to tighten screws (M-B or M-D) along with washers (M-E) and spacers (M-F). Do not tighten the screws excessively or your monitor might be damaged.
F
NOTE: Hand tightens screws to avoid over tightening.
06
Monitor
Monitor Monitor
Q M-A M-C M-E
No!
Monitor
Monitor Monitor
Q M-B M-D M-E
M-F
No!
STEP 4: Hang Monitor
Slide the monitor onto the head of swivel arm, install the security bolt (N). Make sure the security bolt is installed before you rotate the monitor.
N
Important Notice: The pressure of the gas spring is initially set at the lowest value. So when the monitor is hung on, make sure you hold it with both hands and DO NOT let it go down suddenly.
Guideline to adjust monitor tilting angle
Problem: If monitor faces down
Q
07
Solution: 1. Loosen the tilting bolt.
2. Hold the bottom of monitor with one hand and adjust to determine your desired tilt angle.
3. Retighten the tilting bolt towards “” to fix the angle.
STEP 5: Adjust Tension
For proper functioning of this mount, depending on different weight of monitor you might need to adjust tension in upper arm (A) using 6 mm Allen Key (Q).
Q
A
CAUTION
Note1:
Be sure to keep the arm in horizontal position during adjustment.
Situation 1: Arm falls down Upper Arm with monitor falls down and fails to stay where intended. Solution: Turn the inside screw counterclockwise(“+”direction) to increase gas spring tension until the arm can stay as intended.
Situation 2: Arm rises up Upper Arm with monitor rises up and fails to stay where intended.
Solution: Turn the inside screw clockwise(“-“direction) to decrease gas spring tension until the arm can stay as intended.
Note2:
As for how many circles the screw should be turned, the table below is for reference.
Monitor Weigh
6.6lbs
(3kg)
Circles (AT LEAST) 5
8.8lbs
(4kg)
7
15.4lbs
(7kg)
10
22lbs
(10kg)
13
28.7lbs 30.9lbs
(13kg)
(14kg)
16
20
08
STEP 6: Cable Management
Remove Cable Cover
Remove bottom plastic covers from arm as shown in diagram. Do not need to take much effort to pull the ends of the cable cover away from the arm.
Press
1
Press
2
Slide
Press
1
Press
Attach Cable Cover
Run cables from monitor through bottom of arm. Reattach plastic covers as shown in diagram.
Slide
Press
1
Press
09
Press
1
Press
2
Adjust as Desired
Allen key(Q,O) can be stored in Base Support Cover(E) for next time using.
Note:
When tilted, if the monitor sags or does not stay, please fasten the tilting bolt on the mount until the monitor can be held at any angle as needed.
Swivel ±90°
Q
Swivel
±180°
Rotation ±180°
O
+90°
Tilt
-45°
Swivel ±180°
Height
Tilt Swivel Rotation Height
Note: To ensure stability, the tightness of the rotating axis has been preset, so it would be kind of difficult to rotate the VESA plate. Suggestion: Please attach the monitor first, then hold the two sides of it with both hands, and rotate vigorously. If that doesn’t work out, please do not hesitate to ask for our help.
10
Product Dimensions
360°
360°
180°
8.3″
10″-12.4″ 1.9″
2.9″ 3.9″ 4.5″
360°
2.9″ 3.9″ 4.5″
+90° -45°
6.7″-19.7″
3.9″ 0.4″-3.3”
CAUTION AND MAINTENANCE:
· Never allow children to climb, stand, hang, or play on any part of monitor or stand. · This product is intended for indoor use only. Using this product outdoors could lead to
product failure and personal injury. · Check that the bracket is secure and safe to use at regular intervals (at least every three months).
