NAC3MX-W-TOP powerCON True Outdoor Protection IP65 20A Locking Male Cable Connector
Product Information
The powerCON TRUE1 TOP is a combination of an appliance inlet
and outlet connector that allows for power input and output. It
comes in different connector types such as NAC3MPX-TOP,
NAC3MPX-WOT-TOP, NAC3FPX-TOP, NAC3FPX-WOT-TOP, NAC3FPX-ST-TOP,
NAC3PX-TOP, NAC3FX-W-TOP (Connector), and NAC3MX-W-TOP (Plug
connector). The product is approved by VDE EN 60320-1, UL 60320-1,
CAN/CSA-C22.2 No. 60320-1 and rated for 250 V ac / 16 A with cable
types H05VV-F3G 1.0 mm2, Length max. 2 m, H05VV-F3G 1.5 – 2.5 mm2,
H07RN-F3G 1.5 mm2 6.0 – 12.0 mm and 250 V ac / 20 A SJTOW, SJOOW 3
x 12 AWG 6.0 – 12.0 mm.
Product Usage Instructions
- Insert the cable into the bushing and housing after applying
cable pulling lubricant to the cable jacket. - Separate the housing from the bushing while keeping the cable
in the bushing. - Place the chuck over the cable and prepare the cable
accordingly. - Insert the wires into the terminals and fasten the screw with
Torx size T8 with a torque value of 0.7 Nm. - Slide the chuck onto the insert and then both together into the
housing while aligning the chuck and insert by positioning the nose
into the keyway. - Press firmly to complete the assembly with a torque value of
2.0 Nm. - To disassemble, open the twist lock and slide the bushing up
the cable and tighten it with the tool provided.
It is important to align the rubber key and latch while
inserting and to avoid exposing the connection to bending forces.
In case of any broken parts or excessive wear and tear, the
connector must be replaced for safety and certification reasons.
For more details, visit www.neutrik.com.
R
APPLICATION & ASSEMBLY INSTRUCTION NAC3MX-W-TOP | powerCON® TRUE1® TOP
A APPLICATION INSTRUCTION
Application:
· The powerCON® TRUE1® system is certified as a connector with breaking capacity according IEC 60320-1. · It is intended for use as an appliance coupler and interconnection coupler. · It serves to supply power to an appliance and from an appliance to other equipment. · To be installed by qualified person only.
CONNECTOR ASSIGNMENT:
APPLIANCE INLET
NAC3MPX-TOP NAC3MPX-WOT-TOP
Power IN
APPLIANCE OUTLET
NAC3FPX-TOP NAC3FPX-WOT-TOP NAC3FPX-ST-TOP Power OUT
APPLIANCE INLET / OUTLET u Combination NAC3PX-TOP
Power IN
Power OUT
NAC3FX-W-TOP (Connector)
NAC3MX-W-TOP (Plug connector)
NAC3FX-W-TOP (Connector)
NAC3MX-W-TOP (Plug connector)
powerCON® TRUE1® TOP line is full backward compatible with the preceding powerCON TRUE1 products.
Approval based:
VDE EN 60320-1
UL 60320-1 CAN/CSA-C22.2 No. 60320-1
Rating: Cable Type: Cable O.D.:
250 V ac / 16 A H05VV-F3G 1.0 mm2, Length max. 2 m H05VV-F3G 1.5 – 2.5 mm2 H07RN-F3G 1.5 mm2 6.0 – 12.0 mm
250 V ac / 20 A SJTOW, SJOOW 3 x 12 AWG 6.0 – 12.0 mm
B ASSEMBLY INFORMATION
A Insert cable into the bushing and housing.
Note: “Apply cable pulling lubricant to cable jacket.”
40 – 50 mm
B Separate the housing from the bushing (cable
remain in bushing)
NAC3MX-W 12650
22050
P S JET E
i
22500
C
NAC3MX-W 12650 22050 22500
P S JET E
C Place the chuck over the cable.
20 mm
[0.787″]
8 mm
[0.32″]
i Recommendation: Wire Pulling Lubricant – LUB-I/0.95 from 3MTM
20 mm
[0.787″]
8 mm
[0.32″]
D Prepare the cable as shown.
PE 23 mm [0.9″]
PE 23 mm [0.9″]
VDE EN 60320-1
UL 60320-1 CAN/CSA-C22.2 No. 60320-1
BDA 542
Page 1
R ASSEMBLY INSTRUCTION I powerCON® TRUE1® TOP – NAC3MX-W-TOP
E
Torx size T8
Insert the wires into the terminals and fasten the screw with Torx size T8.
Torque Value 0.7 Nm
Wiring
VDE
UL
L Þ
brown
black
N Þ
blue
white
Þ
green / yellow
green
Important: Align rubber key and latch.
NAC3MX-W 12650
22050
P S JET E
2.
22500
F
1. Important: Push and turn simultaneously.
3.
Slide the chuck onto the insert (1) and then both together into housing (2). Important: Align the chuck and insert by positioning the nose into the keyway.
5.
Torque Value 2.0 Nm
G
PRESS FIRMLY
NAC3MX-W 12650
22050
P S JET E
6.
22500
4.
Wrench size 13 mm
C FOR DISASSEMBLY OPEN TWIST LOCK!
1. Press with screw driver to unlock 2. Turn bushing 360°. 3. Repat step 1 + 2 until bushing is unscrewed.
1. 2.
Slide the bushing up the cable and tighten it with the tool as shown. Important: Black O-ring to hide to achieve IP protection (6).
(Tool available: Art. No. HTAC)
Find more details of powerCON TRUE1 TOP on www.neutrik.com.
D SAFETY INFORMATION
NAC3FXP -SW JET E
22050 LIECHTENSTEIN
FORCE
CAUTION
To ensure protection category, do not expose the connection to bending forces (e.g. do not attach loads to the cable, no free-dangling cable windings etc.).
SAFETY WARNING
For safety and certification reasons the connector must be replaced in case of any broken parts or excessive wear and tear.
Draft. Nr.: BDA 542 V3 Update: 2023-02-22
Neutrik AG I LI-9494 Schaan www.neutrik.com
Data subject to change without prior notice. © 2023 NEUTRIK®. NEUTRIK®, powerCON are registered trademark of Neutrik AG. ALL RIGHTS RESERVED.
Page 2
