WIN-615-BF-CL-MWP Winham 5 Light Chandelier
Product Information:
Model: #WIN-615-BF-CL-MWP
Minimum Hanging Height: 6 Stem
Recommended Bulb Type: Candelabra Base Bulb
Recommended Bulb Wattage: 40 Watts
Maximum Bulb Wattage: 60 Watts
Fixture Rating: Damp Rated
Product Usage Instructions:
1. Assemble the fixture according to the detailed illustration
provided in the user manual. Refer to the labeled parts (A, B, C,
etc.) and match them with the corresponding part numbers mentioned
in the manual. 2. Start with mounting the hardware (part A) using
the provided mounting hardware. 3. Attach the canopy (part B) to
the mounting hardware using screws or other fasteners. 4. Connect
the swivel (part C) to the canopy for adjustable positioning of the
fixture. 5. Thread the threaded pipes (part D) into the swivel to
create the desired hanging length. 6. Attach the hanging stem (part
E) to the last threaded pipe, ensuring a secure connection. 7. For
longer hanging lengths, use additional hanging stems (part F) by
attaching them between the threaded pipes. 8. Secure the fixture by
using ball nuts (part G) at each connection point of the threaded
pipes and hanging stems. 9. Attach the metal frame (part H) to the
assembled structure, ensuring it is properly aligned and secured.
10. Use the finial (part I) to cover and secure the topmost end of
the fixture. 11. Use flat screws (part J) to secure any loose
components or connections. 12. Refer to the suggested crystal
placement top view diagram provided in the user manual for guidance
on crystal placement. 13. Use the crystal key provided in the
manual to determine the number and size of crystals required for
each crystal set (A, B, C, etc.). 14. Install the crystals
according to the suggested crystal placement diagram, ensuring they
are securely attached. 15. Install 5 candelabra base bulbs with a
recommended wattage of 40 Watts. LED bulbs can also be used for
extended use. 16. Ensure the maximum bulb wattage does not exceed
60 Watts. 17. Once the assembly is complete and the bulbs are
installed, the fixture is ready for use. 18. This fixture is damp
rated, meaning it is suitable for use in areas with high humidity
or moisture levels. 19. Refer to the user manual for any additional
maintenance or care instructions. Please note that this is a
simplified version of the instructions. For detailed and accurate
instructions, refer to the product user manual provided by
Crystorama.com.
ASSEMBLY INSTRUCTION MODEL #WIN-615-BF-CL-MWP
The minimum hanging height: 6″ Stem
19″ 27.8″
Crystorama.com
20″
DETAILED ILLUSTRATION
K J I
M L
K
J I
M L K J
LMI J K L M I J KL
E D H
FG
C B
H
D A
E B
F C
GH D
AE
GA
FC
E D
H
B G
A F
C ED
B
F G
CH
B H
A G
F
D E
M I J K L
M
I
J K L M
I ML K J
I I ML K J
SUGGESTED CRYSTAL PLACEMENT TOP VIEW PLEASE REFERENCE CRYSTAL KEY
A= B= C= D= E= F= G= H= I= J= K= L= M=
You will need 5 -Candelabra Base Bulb 40 Watts Recommended 60 Watts Max. USE LED BULBS FOR EXTENDED USE THIS FIXTURE IS DAMP RATED
1.Do a complete inventory of all parts and components before you start installation. 2.Attach all four stems together, making sure the 6″ stem is installed and located at the top. 3.Feed fixtures wiring through the stem assembly prior to connection. 4.Now take the bottom of the stem assembly (12″ stem) and connect it to the fixture frame. 5.The top side of the stem assembly (6″ stem), will then be attached to the swivel. 6.Insert recommended bulb (not included). 7.Dress the fixture with crystal as illustrated.
Crystal Key
A.5 Sets. (11)14mm + (5)20mm + (2)30mm
B.5 Sets. (10)14mm + (6)20mm + (1)30mm
C.5 Sets. (9)14mm + (8)20mm
D.6 Sets. (5)14mm + (3)20mm + (1)30mm
E.6 Sets. (6)14mm + (4)20mm + (1)30mm
F.6 Sets. (2)14mm + (4)20mm + (1)30mm
G.6 Sets. (9)14mm + (3)20mm + (1)30mm
H.6 Sets. (4)14mm + (4)20mm
I.9 Sets. (4)14mm + (2)20mm + (1)30mm
J.9 Sets. (3)14mm + (2)20mm + (1)30mm
K.9 Sets. (4)14mm + (4)20mm
L.9 Sets. (3)14mm + (3)20mm + (1)30mm
M.9 Sets. (2)14mm + (2)20mm + (1)30mm
PART NUMBER MODEL #WIN-615-BF-CL-MWP
Crystorama.com
A. (1) – Mounting Hardware
B. (1) – Canopy(W5″,H0.79″) #XRE610BFCAN5IN
C. (1) – Swivel
D. (5) – Threaded Pipe
E. (1) – Hanging Stem(6″,15.9mm) #XRE615BFROD6IN
A
F. (3) – Hanging Stem(12″,15.9mm) #XRE615BFROD12IN
G. (5) – Ball Nut #XRE612BFBANUT
H. (1) – Metal Frame
B
I. (1) – Finial #XRE615BFFIN
C
J. (5) – Flat Screw
D E
F
G H I J
Crystorama Lighting
