WIN-616-GA-CL-MWP Winham Six Light Chandelier
Product Information
Model: #WIN-616-GA-CL-MWP
Minimum Hanging Height: 6 Stem
Recommended Bulb: 6 – Candelabra Base Bulb, 40
Watts
Maximum Bulb: 60 Watts
Fixture Rating: DAMP RATED
Detailed Illustration
The user manual provides a detailed illustration of the product
components and their placement.
Crystal Key
- A: 3 Sets. (11)14mm + (10)20mm + (1)30mm
- B: 3 Sets. (10)14mm + (8)20mm + (2)30mm
- C: 3 Sets. (13)14mm + (9)20mm
- D: 3 Sets. (9)14mm + (9)20mm + (1)30mm
- E: 3 Sets. (9)14mm + (9)20mm + (1)30mm
- F: 3 Sets. (9)14mm + (12)20mm
- G: 6 Sets. (7)14mm + (8)20mm
- H: 6 Sets. (4)14mm + (4)20mm + (3)30mm
- I: 6 Sets. (10)14mm + (6)20mm
- J: 6 Sets. (6)14mm + (7)20mm
- K: 6 Sets. (7)14mm + (6)20mm + (2)30mm
- L: 6 Sets. (10)14mm + (6)20mm
- M: 18 Sets. (3)14mm + (4)20mm + (1)30mm
- N: 18 Sets. (2)14mm + (4)20mm + (2)30mm
- O: 18 Sets. (4)14mm + (2)20mm + (1)30mm
Part Numbers
- A: (1) – Mounting Hardware
- B: (1) – Canopy(W5,H0.79) #XRE616GACAN5IN
- C: (1) – Swivel
- D: (5) – Threaded Pipe
- E: (1) – Hanging Stem(6,15.9mm) #XRE615GAROD6IN
- F: (3) – Hanging Stem(12,15.9mm) #XRE615GAROD12IN
- G: (6) – Ball Nut # XRE612GABANUT
- H: (1) – Metal Frame
- I: (1) – Finial # XRE615GAFIN
- J: (5) – Flat Screw
Product Usage Instructions
- Do a complete inventory of all parts and components before you
start installation. - Attach all four stems together, making sure the 6 stem is
installed and located at the top. - Feed fixture’s wiring through the stem assembly prior to
connection. - Take the bottom of the stem assembly (12 stem) and connect it
to the fixture frame. - Attach the top side of the stem assembly (6 stem) to the
swivel. - Insert the recommended bulb (not included).
- Dress the fixture with crystal as illustrated using the Crystal
Key for reference.
ASSEMBLY INSTRUCTION MODEL #WIN-616-GA-CL-MWP
The minimum hanging height: 6″ Stem
23″ 31.8″
Crystorama.com
24″
DETAILED ILLUSTRATION
O M N O M N O M N OMN
N M
O M
O N M O N
LGH
K
J I H
F E
A
I JK BC
LGH D
E
F
I J K L
N O M N
O
M
GD
AG
M
O
LC
BH
N
N M
O N M
O
K JI
B
HG
N MON
AF E LKJ I
M ON
C D HG L
K
I J
M O N MO
N
O
M N O M
SUGGESTED CRYSTAL PLACEMENT TOP VIEW PLEASE REFERENCE CRYSTAL KEY
A= B= C= D= E= F= G= H= I= J= K= L= M= N= O=
You will need 6 -Candelabra Base Bulb
40 Watts Recommended 60 Watts Max. USE LED BULBS FOR EXTENDED USE THIS FIXTURE IS DAMP RATED
1.Do a complete inventory of all parts and components before you start installation.
2.Attach all four stems together, making sure the 6″ stem is installed and located at the top.
3.Feed fixtures wiring through the stem assembly prior to connection.
4.Now take the bottom of the stem assembly (12″ stem) and connect it to the fixture frame.
5.The top side of the stem assembly (6″ stem), will then be attached to the swivel.
6.Insert recommended bulb (not included). 7.Dress the fixture with crystal as
illustrated.
Crystal Key
A.3 Sets. (11)14mm + (10)20mm + (1)30mm
B.3 Sets. (10)14mm + (8)20mm + (2)30mm
C.3 Sets. (13)14mm + (9)20mm
D.3 Sets. (9)14mm + (9)20mm + (1)30mm
E.3 Sets. (9)14mm + (9)20mm + (1)30mm
F.3 Sets. (9)14mm + (12)20mm
G.6 Sets. (7)14mm + (8)20mm
H.6 Sets. (4)14mm + (4)20mm + (3)30mm
I.6 Sets. (10)14mm + (6)20mm
J.6 Sets. (6)14mm + (7)20mm
K.6 Sets. (7)14mm + (6)20mm + (2)30mm
L.6 Sets. (10)14mm + (6)20mm
M.18 Sets. (3)14mm + (4)20mm + (1)30mm
N.18 Sets. (2)14mm + (4)20mm + (2)30mm
O.18 Sets. (4)14mm + (2)20mm + (1)30mm
PART NUMBER MODEL #WIN-616-GA-CL-MWP
Crystorama.com
A. (1) – Mounting Hardware
B. (1) – Canopy(W5″,H0.79″) #XRE616GACAN5IN
C. (1) – Swivel
D. (5) – Threaded Pipe
E. (1) – Hanging Stem(6″,15.9mm) #XRE615GAROD6IN
A
F. (3) – Hanging Stem(12″,15.9mm) #XRE615GAROD12IN
G. (6) – Ball Nut # XRE612GABANUT
H. (1) – Metal Frame
I. (1) – Finial # XRE615GAFIN
J. (5) – Flat Screw
B
C D
E
F
G
H I J
Crystorama Lighting
