WIN-618-BF-GL-MWP Winham Eight Light Chandelier in Black Forged
Product Information
- Model Number: WIN-618-BF-GL-MWP
- Minimum Hanging Height: 6 Stem
- Recommended Bulb Type: Candelabra Base Bulb
- Recommended Bulb Wattage: 40 Watts
- Maximum Bulb Wattage: 60 Watts
- Fixture Rating: Damp Rated
- Crystal Key:
- A: 8 Sets – (11)14mm + (5)20mm + (2)30mm
- B: 8 Sets – (10)14mm + (6)20mm + (1)30mm
- C: 8 Sets – (9)14mm + (8)20mm
- D: 8 Sets – (6)14mm + (5)20mm + (2)30mm
- E: 8 Sets – (6)14mm + (6)20mm + (1)30mm
- F: 8 Sets – (4)14mm + (5)20mm + (2)30mm
- G: 8 Sets – (9)14mm + (3)20mm + (2)30mm
- H: 8 Sets – (5)14mm + (6)20mm + (1)30mm
- I: 12 Sets – (5)14mm + (2)20mm + (2)30mm
- J: 12 Sets – (4)14mm + (3)20mm + (1)30mm
- K: 12 Sets – (3)14mm + (4)20mm + (1)30mm
- L: 12 Sets – (2)14mm + (4)20mm + (1)30mm
- M: 12 Sets – (4)14mm + (2)20mm + (1)30mm
- Part Number: MODEL #WIN-618-BF-CL-MWP
Product Usage Instructions
- Determine the desired height for the fixture to hang and select
the appropriate stems. - Thread the wires through the chosen stems and the
swivel/canopy. - Attach the stem onto the fixture body.
- Attach the canopy/swivel onto the stem.
- Insert the recommended bulb (not included) into the
fixture. - Dress the crystal strands according to the illustrated crystal
key.
ASSEMBLY INSTRUCTION MODEL #WIN-618-BF-GL-MWP
The minimum hanging height: 6″ Stem
19.5″
27.6″
Crystorama.com
22″
DETAILED ILLUSTRATION
ML K J I ML K J I ML K J I
I
M
J
HG F E DHG F E D
L
K
D
H
K
L M I J
E F G H
CBACBA
A
C
B
B
C
A
G F E D
J I M L
K L M I J
D E F G
A
C
B
B
C
A
AB CAB C
H G F E
K J I M L
K
H
D
K
L
D E F GHD E F GH
J
M
I
I J K LMI JK LMI J K LM
SUGGESTED CRYSTAL PLACEMENT TOP VIEW PLEASE REFERENCE CRYSTAL KEY
A= B= C= D= E= F= G= H= I= J= K= L= M=
You will need 8 -Candelabra Base Bulb 40 Watts Recommended 60 Watts Max. USE LED BULBS FOR EXTENDED USE THIS FIXTURE IS DAMP RATED
1.Determine the height you’d like the fixture to hang and choose the stems needed.
2.Feed wires through the stems and swivel/canopy.
3.Attach the stem onto the fixture body.
4.Attach the canopy/swivel onto the stem.
5.Insert recommended bulb (not included).
6.Dress the crystal strands as illustrated.
Crystal Key
A.8 Sets. (11)14mm + (5)20mm + (2)30mm
B.8 Sets. (10)14mm + (6)20mm + (1)30mm
C.8 Sets. (9)14mm + (8)20mm
D.8 Sets. (6)14mm + (5)20mm + (2)30mm
E.8 Sets. (6)14mm + (6)20mm + (1)30mm
F.8 Sets. (4)14mm + (5)20mm + (2)30mm
G.8 Sets. (9)14mm + (3)20mm + (2)30mm
H.8 Sets. (5)14mm + (6)20mm + (1)30mm
I.12 Sets. (5)14mm + (2)20mm + (2)30mm
J.12 Sets. (4)14mm + (3)20mm + (1)30mm
K.12 Sets. (3)14mm + (4)20mm + (1)30mm
L.12 Sets. (2)14mm + (4)20mm + (1)30mm
M.12 Sets. (4)14mm + (2)20mm + (1)30mm
PART NUMBER MODEL #WIN-618-BF-CL-MWP
Crystorama.com
A. (1) – Mounting Hardware
B. (1) – Square Canopy(L5″,W5″,H0.79″) #XRE618BFCAN5IN
C. (1) – Swivel
A
D. (5) – Threaded Nipple
E. (1) – Hanging Stem(6″,15.9mm) #XRE615BFROD6IN
B
F. (3) – Hanging Stem(12″,15.9mm) #XRE615BFROD12IN
C
G. (4) – Ball Nut # XRE612BFBANUT
D
H. (1) – Metal Frame
E
I. (1) – Finial #XRE615BFFIN
F
G H I
Crystorama Lighting
