801 Series Decorative Strip 8 Foot

Product Information

The 801 SERIES is a decorative strip light fixture designed for
surface mounting, chain suspended mounting, or cable suspended
mounting. The fixture has an LED assembly that can be adjusted for
kelvin and wattage using dip switches located on the driver. It is
available in three different color temperatures: 3000K, 4000K, and
5000K.

Surface Mounting

Attach the baffle on the lamp if needed.
Detach the LED assembly by starting at one end of the fixture
and pressing each side of the base.
Adjust kelvin and wattage as desired using the dip switches
located on the driver.
Fix the lamp to the ceiling with plastic anchors and screws
(not included).
Wire to main power through the junction box.
Push lamp upward to snap into place.

Chain Suspended Mounting

Detach the LED assembly by starting at one end of the fixture
and pressing each side of the base.
Adjust kelvin and wattage as desired using the dip switches
located on the driver. Close LED assembly.
Connect the V-hooks to the lamp.
Attach chain to the V-hooks.
Connect the AC wires per wiring diagram.

Cable Suspended Mounting

Detach the LED assembly by starting at one end of the fixture
and pressing each side of the base.
Adjust kelvin and wattage as desired using the dip switches
located on the driver. Close LED assembly.
Connect cable to beam.
Attach fixture to the cable.
Connect the AC wires per wiring diagram.

WARNING:

To avoid electric shock, disconnect power at source prior to
installation.
The installation should be performed by qualified electricians
or lighting technicians.
Before conducting any installation, maintenance, or removal,
disable all power.
Do not touch the fixture while it is in service.
If there is any problem with the fixture, turn off power and DO
NOT attempt repair unless you are a qualified technician or the
customer service member.

Wiring Diagram:

Wiring Diagram

View Fullscreen

801 SERIES
Decorative Strip Installation Guide

Page 1 of 2

WARNING
1. To avoid electric shock, disconnect power at source prior to installation. 2. The installation should be performed by qualified electricians or lighting technicians. 3. Before conducting any installation, maintenance, or removal, disable all power. 4. Do not touch the fixture while it is in service. 5. If there is any problem with the fixture, turn off power and DO NOT attempt repair unless
you are a qualified technician or the customer service member.

Surface Mounting

Fixture Base

3000K 4000K 5000K

Press

1Attach the baffle on the lamp if needed.

LED Assembly
2 Detach the LED assembly by starting at one end of the fixture and pressing each side of the base.

3Adjust kelvin and wattage as desired using the dip switches located on the driver.

4 Fix the lamp to the ceiling with plastic anchors and screws (not included)

5Wire to main power through the junction box. (below)

6 Push lamp upward to snap into place.

Wiring Diagram

120277V
