FI-EZB-15NV EZBlend Foam Unit
Product Information
Model Number: FI-EZB-15NV
Product Name: EZBlend Foam Unit
Language: English
Power Type: Compressed air
Chemical Pickup Type: Draws from concentrated
product
Dilution Ratio Range: 12.8-16 fl. oz. : 12.8-16
fl. oz. : 1 gallon (378.5-473.2 ml : 378.5-473.2 ml : 3.78
liters)
Number of Products: Two products,
simultaneously unit can draw from
Suction Line Length/Diameter: Two transparent
suction lines, one blue and one green, each 4 ft. (1.2 m) long with
1/4 in. (6.4 mm) inside diameter; with quick disconnect fittings
for chemical jugs
Capacity: 15 gallons (56.78 liters) of water;
Up to 10 gallons (37.85 liters) of concentrate
Discharge Hose Diameter/Length: 30 ft. (9 m)
hose, with 3/4 in. (19 mm) inside diameter
Discharge Wand/Tip Type: Output distance
Output Distance: 10-12 ft. (3-4.6 m)
Output Volume: 15-20 gal/min (56.8-75.7
l/min)
Flow Rate: 2 gal/min (7.6 l/min)
Pump Seals: Viton
Wheel Type: Two 10 inch non-marking wheels, two
5 inch casters with lock
Product Usage Instructions
- Remove the unit from packaging.
- Using the EZBlend Chemical Dispensing Unit or another
dispensing system:- Fill a 5-gallon jug with a blue cap with Sterilex Solution
1/Disinfectant product and secure the cap. - Fill a 5-gallon jug with a green cap with Sterilex Solution
2/Activator product and secure the cap.
Note: Refer to the Acceptable Products chart if needed.
- Fill a 5-gallon jug with a blue cap with Sterilex Solution
- Connect the chemical intake lines to the chemical containers:
- Connect the blue chemical intake line to the blue cap jug.
- Connect the green chemical intake line to the green cap
jug.
- Fill the 15-gallon tank with water.
- Verify that the valve at the base of the suction line is open
to allow fluid into the suction line. - With the discharge ball valve in the closed position, plug an
air line into the air fitting. - Slowly open the discharge ball valve to begin foaming. The
discharge ball valve should be completely open while foaming. - The unit is pre-set to a standard needle valve setting to
deliver the product at the labeled rate. If adjustment is needed
for foam consistency or dilution, refer to the Adjustment for Foam
Consistency and Dilution Instructions.Note: It is recommended to always confirm chemical dilution with
titration after adjusting the needle valve. Use the titration kit
available from Aqua Phoenix Scientific (US part number – TK3319-Z;
Canada part number – TK3319FR) when titrating Sterilex
products.
USER MANUAL
MODEL NUMBER: FI-EZB-15NV
EZBlendTM Foam Unit English (Original Instructions)
User Manual: EZBlend Foam Unit | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
WARNING
Read this manual completely and understand the machine before operating or servicing it.
· Read all instructions before installing or operating unit. · Always wear appropriate personal protective equipment
(PPE) when operating or servicing unit. · Always follow all chemical safety precautions and
handling instructions provided by the chemical manufacturer and Safety Data Sheet (SDS). · If this unit is modified or serviced with parts not listed in this manual, dilution rates may vary, or the unit may not operate correctly. · Never point the discharge wand at yourself, another person, or any object you do not want covered in chemical. · Always depressurize unit after use (as described in the After Use Instructions). Always store unit depressurized, with the discharge ball valve in the closed position. · Do not exceed an incoming air pressure of 100 psi (7 bar). · Do not exceed a fluid temperature of 100°F (37°C). · Only use clean and dry air. Air must be filtered and free of moisture or pump life will be diminished. If needed, install a water separator before the unit. · Do not use an air lubricator before the unit.
PROTECT THE ENVIRONMENT Please dispose of packaging materials, old machine components, and hazardous fluids in an environmentally safe way according to local waste disposal regulations.
Always remember to recycle.
*Specifications and parts are subject to change without notice.
REQUIREMENTS
Compressed air requirements
Liquid temperature range
Chemical compatibility
60 psi (4.1 bar) with 5-10 cfm (141283 l/min) 40-100°F (4.4-37°C)
This unit is specifically configured for use with Sterilex liquid products.
SPECIFICATIONS
Power type
Chemical pickup type
Dilution ratio range (Chemical A:Chemical B:Water)*
Compressed air Draws from concentrated product
12.8-16 fl. oz. : 12.8-16 fl. oz. : 1 gallon (378.5-473.2 ml : 378.5-473.2 ml : 3.78 liters)
Number of products Two products, simultaneously unit can draw from
Suction line length/ diameter
Two transparent suction lines, one blue and one green, each 4 ft. (1.2 m) long with 1/4 in. (6.4 mm) inside diameter; with quick disconnect fittings for chemical jugs
Capacity
15 gallons (56.78 liters) of water; Up to 10 gallons (37.85 liters) of
concentrate
Discharge hose diameter/length
30 ft. (9 m) hose, with 3/4 in. (19 mm) inside diameter
Discharge wand/tip type
12 in. (30.48 cm) stainless steel wand and ball valve with 65° fan tip; includes stainless quick connects
Output distance
10-12 ft. (3-4.6 m)
Output volume
15-20 gal/min (56.8-75.7 l/min)
Flow rate*
2 gal/min (7.6 l/min)
Pump seals
Viton
Wheel type
Two 10 inch non-marking wheels, two 5 inch casters with lock
*Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings.
Model No.: FI-EZB-15NV
Page 2 of 9 | 20230616
User Manual: EZBlend Foam Unit | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
SPECIAL INSTRUCTIONS
This unit is specifically designed for use with Sterilex two-part liquid products. The unit is calibrated to achieve dilution rates as recommended by Sterilex of 12.8oz-16oz Solution 1: 12.8oz-16oz Solution 2: 1 gal water. One jug with a blue cap is labeled “Solution 1/Disinfectant Products” and should only be used with those Sterilex products categorized as “Solution 1/Disinfectant” products below. The other jug with a green cap is labeled “Solution 2/Activator Products” and should only be used with those Sterilex products categorized as “Solution 2/Activator” products below. Modifications to the unit will result in varied dilution rates that may minimize effectiveness of solutions or result in off label product usage.
ALWAYS AFFIX STERILEX CHEMICAL JUG TAGS TO EACH JUG. CONTACT YOUR STERILEX PRODUCT CHEMICAL VENDOR FOR JUG TAGS.
ACCEPTABLE PRODUCTS
Sterilex “Solution 1/Disinfectant” Products Sterilex® Ultra Disinfectant Cleaner Solution 1 (US) Sterilex® Ultra CIP (US) Sterilex® Ultra-Kleen Solution: Solution 1 (Canada) Sterilex® Ultra Soft Metal Disinfectant Cleaner (Canada)
Sterilex “Solution 2/Activator” Products Sterilex® Ultra Activator Solution (US) Ultra Soft Metal Activator (US) Sterilex® Ultra-Kleen Solution: Solution 2 (Canada) Sterilex® Ultra Soft Metal Activator (Canada)
Operation Instructions:
1. Remove unit from packaging.
2. Using EZBlend Chemical Dispensing Unit or other dispensing system:
a. Fill 5 gallon jug with blue cap with Sterilex “Solution 1/Disinfectant” product and secure cap.
b. Fill 5 gallon jug with green cap with Sterilex “Solution 2/Activator” product and secure cap.
NOTE: Refer to the Acceptable Products chart if needed.
3. Connect the chemical intake lines to the chemical containers.
a. Connect the blue chemical intake line to the blue cap jug.
b. Connect the green chemical intake line to the green cap jug.
4. Fill the 15 gallon tank with water.
5. Verify that the valve at the base of the suction line is open, to allow fluid into the suction line.
6. With the discharge ball valve in the closed position, plug an air line into the air fitting.
7. Slowly open the discharge ball valve to begin foaming. The discharge ball valve should be completely open while foaming.
8. Unit is pre-set to a standard needle valve setting to deliver product at labeled rate. If adjustment is needed for foam consistency or dilution, see Adjustment for Foam Consistency and Dilution Instructions. NOTE: It is a best practice to always confirm chemical dilution with titration after adjusting needle valve. Use titration kit available from Aqua Phoenix Scientific (US part number – TK3319-Z; Canada part number – TK3319FR) when titrating Sterilex products.
9. To stop foaming, close the discharge ball valve. Disconnect the air line from the air fitting and relieve any remaining pressure in the system by opening the discharge ball valve.
After Use Instructions:
1. Thoroughly flush the unit with fresh water.
2. Disconnect both blue and green chemical intake lines from the chemical jugs.
3. Connect the air line to the air fitting and open the discharge ball valve to dispense water for at least one minute.
4. Close the discharge ball valve. Disconnect the air line from the air fitting and relieve any remaining pressure in the system by opening the discharge ball valve.
5. Close the ball valve after all pressure has been relieved from the system. Store the unit with the discharge ball valve in the closed position.
Model No.: FI-EZB-15NV
Page 3 of 9 | 20230616
User Manual: EZBlend Foam Unit | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Maintenance Instructions:
To keep your foam unit operating properly, periodically perform the following maintenance procedures:
Note: Before performing any maintenance, ensure that the unit has been disconnected from the air and water supply and depressurized according to the After Use Instructions.
· Inspect the pump for wear and leaks.
· Inspect all hoses for leaks or excessive wear. Make sure all hose clamps are in good condition and properly secured.
· Replace the filter located within the air regulator as needed. Clean by unthreading the air regulator bowl from the air regulator.
· Check the chemical metering tips, suction lines and strainer for debris and clean as needed.
· Drain your air compressor tank on a regular basis to help extend pump life. An air source with a high moisture content will accelerate pump wear. Note: If your air source has a high moisture content, you may wish to install a water separator before the unit.
Troubleshooting Instructions:
· Check to ensure that the discharge hose is uncoiled properly, and that there are no kinks that could obstruct fluid flow.
· Check the air regulator bowl and air filter for debris such as water, oil, or rust particles. Clean by unthreading the air regulator bowl from the air regulator.
· If the needle valve is open too far, the pump may cycle improperly due to lack of air pressure.
· If air passes through the pump without cycling, the pump needs to be replaced.
· If solution backs up into the air regulator bowl, the check valve needs to be replaced.
· If foam comes out wet, no matter where the needle valve is positioned, the check valve may need to be replaced.
· Check for proper air pressure on the air gauge. The air regulator is factory set at 60 psi (4.1 bar). Operating pressure is 60 psi (4.1 bar) with 5 to 10 cfm (141 to 283 l/ min).
· If the unit operates at a reduced pressure: o Check the air compressor supplying the unit. If the pressure is less than 60 psi, turn the unit off until the compressor can catch up. o If the air supply is 60 psi (4.1 bar) or above, check the air gauge, which should read near 60 psi (4.1 bar). If the air gauge reads more or less than 60 psi (4.1 bar), adjust the pressure by turning the knob on the top of the air regulator.
o If both of the above are okay, the stainless steel mixing mesh could be plugged. Remove and clean it by following the instructions below: 1. Be sure the foam unit is not plugged into an air supply and be sure to relieve all stored pressure in the unit by having the ball valve in the open position. 2. Remove the stainless hose barb from the tee fitting. 3. Remove the screen and the mixing mesh from inside the tee fitting. 4. Clean any particles from the mixing mesh and the screen. 5. Replace the mixing mesh and then the screen into the back of the tee and screw the stainless adaptor back into the tee. It is recommended to use a pipe thread sealant when reinstalling the stainless adaptor back into the tee fitting. If the mixing mesh has a lot of foreign particles in it, make sure the strainer is still in place.
· Check the chemical metering tips, suction lines and strainer for debris or damage. Clean or replace as needed. To prevent damage to the unit, the strainer must always be used.
· If concentrated product is back flowing into the water tank, the check valve needs to be replaced.
Adjustment for Foam Consistency and Dilution Instructions:
Note: Always confirm chemical dilution with titration after adjusting needle valve.
· If needle valve adjustment is needed for better foam consistency, while the unit is running and discharging product, adjust the needle valve as needed to regulate the wetness or dryness of the foam following the steps. o For minor adjustment, turn the needle valve handle in 1/8 turn increments allowing 30 seconds between adjustments, until desired consistency of foam is achieved. o Open needle valve in counter-clockwise direction for dryer foam. o Close needle valve in clockwise direction for wetter foam.
· If your dilution is not within the labeled rate: o To decrease concentration, open needle valve counter-clockwise. o To increase concenration, close needle valve clockwise.
Model No.: FI-EZB-15NV
Page 4 of 9 | 20230616
User Manual: EZBlend Foam Unit | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
TANK ASSEMBLY
LDA-7BK
(see datasheet for color opons)
B142012-VS TANK-15NC-BRKT
DPA
TANK-15N-C
B142012-VS PLSS-AXL AXL18
CST5SS
CST5SS-L
PVCV34FM
FW58 W10 FW58 COT
HOSE AND WAND ASSEMBLY
30 ft (9 m) HOSE ASSEMBLY ITEM NUMBER: HA34BL-30
H34BL-F
(Available per ft.)
HBSS1234
SSC34
WAND ASSEMBLY ITEM NUMBER: SSWA-EZB
QCSS12F
SSN126
(Not pictured: MIX7 and SSST)
BVSS12 HBSS1234
ANTI-KINK SPRING WITH RETAINING PIN ITEM NUMBER: AKSS34
AKSS34
ST6570SS SC1212
SSN126
(Not pictured: MIX7 and SSST)
QCSS12PF
Model No.: FI-EZB-15NV
Page 5 of 9 | 20230616
User Manual: EZBlend Foam Unit | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
BACK PLATE ASSEMBLY Inside View
S1012-HL P56V
BRKT-P56
R25DT EC14
H14BL-F HBELF3838 BLUE-TIP-EZB SCI-125X2-EZB HBELF3838
GREEN-TIP-EZB STR38-IL CV38-AP
HBSSEL1438 NV14 HBSSEL1814
R25 AG100 SEL14M SST12HB38A-MX SSC38
H38BL-F
SSC38 HBSSEL1438 HHPB3414 PVCV34FM
BACK PLATE ASSEMBLY Outside View
PLUG34 BPTNA SSSFN12 SSA14BKH
AP14
FWP12 HBSS1234
OPTIONAL COMPONENTS
WATER SEPARATOR ASSEMBLY 30 ft (9 m) AIR HOSE ASSEMBLY ITEM NUMBER: WSA-20CFM ITEM NUMBER: AH30
SN1414
SSU14 WS-20CFM
AP14
Model No.: FI-EZB-15NV
Page 6 of 9 | 20230616
User Manual: EZBlend Foam Unit | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
CHEMICAL JUGS Solution 1 Jug: J5BLS Solution 2 Jug: J5GNS
QCPP14HBEL-HAST
QCPP-M-HAST
JC35BL
H14C-BL
H14C-GN
J5BLS Solution 1 Jug with blue cap
JC35GN
J5GNS Solution 2 Jug with green cap
JUG ASSEMBLY
JC35SSC JC35SSCS
JC35-CV
CHN-BD
QCPP14HBEL-HAST QCPP-M-HAST
J5-SR-EL
Model No.: FI-EZB-15NV
Page 7 of 9 | 20230616
User Manual: EZBlend Foam Unit | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
ITEM NUMBER DESCRIPTION
AG100
AIR GAUGE-1/8IN NPT-100 PSI DRY MODEL
AKSS34
SS ANTI-KINK SPRING FOR 3/4 INCH HOSE
AP14
AIR FITTING 1/4 MPT X PLUG-NICKEL-PLATED BRASS
AXL18
AXLE-STAINLESS-0.625 DIA x 18.31 IN
B142012-VS
1/4-20 X 1/2IN BOLT-STAINLESS-TRUSS HEAD PHILLIPSVIBRASEAL
B142058-VS
1/4-20 X 5/8IN BOLT-STAINLESS-TRUSS HEAD PHILLIPSVIBRASEAL
BLUE-TIP-EZB
BLUE METERING TIP FOR EZB APPLICATION
BPTNA
BACK PLATE THUMB NUT ASSEMBLY – INCLUDES BOLT, THUMB NUT, AND TETHER
BST14201125-VS ¼-20 SET BOLT – 1.125 IN. LONG – VIBRA-SEAL
TN1420
¼-20 THUMB NUT – BRASS INSERT – ASSEMBLED WITH TETHER
BRKT-P56
PUMP BRACKET- STAINLESS STEEL
BST14201125-VS
1/4-20 SET BOLT-1.125 IN LONG-VIBRA SEAL
BVSS12
STAINLESS BALL VALVE-1/2IN NPT
CHN-BD
ROUND BEAD CHAIN, TYPE 304 STAINLESS STEEL, #10
COT
COTTER PIN-STAINLESS-1/8IN X 1IN
CST5SS
SWIVEL CASTER-STAINLESS-5IN CLEARANCE-4IN WHEEL
CST5SS-L
SWIVEL CASTER-STAINLESS-5IN CLEARANCE-4IN WHEEL-WITH LOCK
CV38-AP
CHECK VALVE-3/8IN BARBS-PVC BODY-HASTELLOY SPRING-TEFLON BALL-WHITE
DPA
DRAIN PLUG ASSEMBLY – INCLUDES GASKET
EC14
OETIKER EAR CLAMP FOR 1/4IN HOSE
EC34
OETIKER EAR CLAMP FOR 3/4IN HOSE
EC75
OETIKER CLAMP FOR 3/4IN HOSE
F34SS
STAINLESS CRIMP FERRULE FOR 3/4IN HOSE
FW58
FLAT WASHER FOR 5/8IN PIPE-STAINLESS-0.687 ID X 1.5 OD X 0.07 THK
FWP12
FLAT WASHER FOR 1/2IN NPT-STAINLESS-.875 ID X 1.5 OD X 0.05 THK
FWP14
FLAT WASHER-1/2 F/W-.516 X .875 OD X .0310 THK18-8 SS
GREEN-TIP-EZB
GREEN METERING TIP FOR EZB APPLICATION
H14BL-F
1/4IN BLUE HOSE-HYBRID TPE-AVAILABLE PER FT
H14C
1/4in ID (3/8 in OD) CLEAR PVC TUBING – Available per ft.
H14C-BL
1/4in ID (3/8 in OD) CLEAR BLUE POLY TUBING Available per ft.
H14C-GN
1/4in ID (3/8 in OD) CLEAR GREEN POLY TUBING Available per ft.
H14CP
1/4IN OD POLYETHYLENE TUBING-NATURAL COLOR Available per ft.
H34BL-F
3/4IN BLUE HOSE-HYBRID TPE-AVAILABLE PER FT
H38BL-F
3/8IN BLUE HOSE-HYBRID TPE-AVAILABLE PER FT
H38C
HBELF3838 HBSS1234 HBSS1438 HBSSEL1438 HBSSEL1814 HHPB3414 J5 J5-SR-EL
JC35BL
JC35-CV JC35GN
JC35SSC
JC35SSCS
JC-G35 LDA-7BK
LD-7BK-FLNG LD-7BK-LID LD-PIN MIX7
MIX7 MIX7-BEND NV14 P203CT-FS P56V
20756103B HB14P HB5638V PLPF
PLPF-H PLPF-PIN PLSS-AXL PLUG34 PVCV34FM QCPP14HBEL-HAST
QCPP-M-HAST
3/8in ID (1/2 IN OD) CLEAR PVC TUBING – Available per ft. HOSE BARB ELBOW 3/8″ BY FPT 3/8″ STAINLESS HOSE BARB 1/2 MPT X 3/4 BARB STAINLESS HOSE BARB 1/4 MPT X 3/8 BARB STAINLESS HOSE BARB 1/4 MPT X 3/8 BARB ELBOW STAINLESS HOSE BARB 1/8 MPT X 1/4 BARB ELBOW HEX HEAD POLY BUSHING 3/4 MPT X 1/4 FPT 5 GALLON NATURAL JUG 5 GALLON SUCTION FITTINGS REPLACEMENT KIT (SUCTION TUBE, COUPLER, ELBOW PLUG) BLUE 3.5 INCH ONE WAY VENTED CAP POLYPROPYLENE WITH GASKET AND CHECK VALVE EPDM CHECK VALVE FOR NON LOCKING JUG CAP GREEN 3.5 INCH ONE WAY VENTED CAP POLYPROPYLENE WITH GASKET AND CHECK VALVE 304 SS END COUPLING FOR SIZE 8-10, ROUND BEAD CHAIN SOCKET HEAD CAP SCREW-10-32 MPT-3/4IN LONGVENTED JUG CAP GASKET 3.5 INCH CAP EPDM LID ASSEMBLY-INCLUDES 7IN BLACK LID, LID FLANGE, HINGE PIN, MOUNTING SCREWS 7IN LID FLANGE-POLYETHYLENE-BLACK 7IN LID-POLYETHYLENE-BLACK HINGE PIN FOR 7IN LID AND FLANGE 7 INCH WIRE TWISTED BRUSH-STAINLESS STEEL-13.5IN OVERALL LENGTH TWISTED-IN-WIRE BRUSH-.625 OD x 7IN BEND AND TRIM MIX7 NEEDLE VALVE-1/4IN NPT-INCLUDES BLACK KNOB FOOT STRAINER FOR THE P203CT PUMP WITH VITON SEALS – INCLUDES HOSE BARBS, AIR FITTING, AND EXHAUST BARB Polypro G57 Air Port x HB Straight, w/ Viton o-ring 1/4in BRASS HB AIR FITTING /G57/P56 HOSE BARB FOR P56V PUMP PORTABLE FOAMER BACK PLATE W/ HOLES-HINGE SOLD SEPARATELY HINGE FOR PLPF STAINLESS HINGE PIN FOR PORTABLE PLATE AXLE PLATE-STAINLESS-2.5 IN X 1 IN-2 HOLES TUBING PLUG 3/4 ( FITS 11/16 HOLE) PVC VALVE 3/4in FPT X 3/4in MPT 1/4IN IN-LINE HOSE BARB ELBOW – POLYPRO BODY HASTELLOY SPRING 3/8IN PANEL MOUNT SOCKET – SUCTION 3/8 ID X QUICK CONNECT – HASTELLOY SPRING – 11/16-24 THREAD
Model No.: FI-EZB-15NV
Page 8 of 9 | 20230616
User Manual: EZBlend Foam Unit | English
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
QCSS12F QCSS12PF R25
R25DT S1012-HL S812-FH SC1212 SCI-125X2-EZB
SEL14M SN1212 SN1414 SSU14 SSA14BKH SSC14 SSC38
SS NON CHECK 1/2 IN QUICK CONNECT COUPLER – FPT SS NON CHECK 1/2in QUICK CONNECT PLUG – FPT AIR REGULATOR-TWO 1/4IN FPT PORTS-TWO 1/8IN FPT PORTS-INCLUDES FILTER AND BOWL 3/16 X 5/16 CLEAR PVC TUBING – Available per ft. 10-16 X 1/2 IN SCREW-STAINLESS-HI LO #8 X 1/2IN SCREW-STAINLESS-FLAT HEAD PHILLIPS S.S. COUPLER 1/2in BY 1/2in STAINLESS CHEMICAL INJECTOR-.125 ORFICE-DUAL BARB GREEN & BLUE-EZBLEND STAINLESS ELBOW 1/4IN MPT X 1/4IN MPT 1/2in HEX STAINLESS STEEL NIPPLE STAINLESS HEX NIPPLE ¼ MPT X ¼ MPT STAINLESS STEEL UNION – ¼ IN. FPT BULKHEAD ADAPTER-STAINLESS-1/4 NPT X 1/4 NPSM STAINLESS SCREW BAND CLAMP FOR 1/4 IN HOSE STAINLESS SCREW BAND CLAMP FOR 3/8 IN HOSE
SSN126
SSSFN12 SSP12
SST12HB38A-MX
SST12HB38 MXA- PF
ST6570SS STR38-IL
TANK-15N-C TANK-15NC-BRKT W10
STAINLESS PIPE NIPPLE 1/2 MPT X 1/2 MPT- 6 IN LONG – SCH 40S SERRATED FLANGE NUT-STAINLESS-1/2 IN STAINLESS STEEL AXLE PLATE – 2.5 inch X 1 inch – 2 HOLE STAINLESS TEE ASSEMBLY – ½ IN. FPT X IN. BARB INCLUDES MIXING MATERIAL AND SCREEN STAINLESS TEE ½ FPT BARB – NO MIXING MATERIAL MIXING MATERIAL ASSEMBLY – INCLUDES STAINLESS MESH AND SCREEN SPRAY TIP-65 DEGREE-7.0 GPM-STAINLESS-1/2 MPT IN LINE STRAINER-3/8 BARB-EPDM GASKET-20 MESH SS – BLACK BOWL 15 GALLON CONCENTRATE TANK NATURAL IN COLOR SS BRACKET FOR TANK-15NC WHEEL-NONMARKING-10IN
Model No.: FI-EZB-15NV
Page 9 of 9 | 20230616
