FR-7S3208-Lite Smart Industrial Ethernet Switch LITE
Product Information: Product Name: FR-7S3208-Lite Brand:
Fiberroad Model: FR-7S3208L Description: Smart Industrial Ethernet
Switch designed for small industrial networks Main Features: –
Compact, all-aluminium case with a fanless design – DIP Switch
supports RSTP/VLAN/SPEED – 9K bytes Jumbo frame compatible with
multiple extension protocols – IEEE802.3az energy-efficient
Ethernet – Electricity surge protection for outdoor use – Detailed
status indicator for easy monitoring – Power input polarity
protection – DIN rail or Wall Mount installation – Easy-to-use
WebGUI interface Product Specifications: – Ethernet Interface:
8×10/100/1000Base-TX RJ45 ports + 2×100/1000Base-X SFP ports – Port
Mode(Tx): Auto-Negotiation – Speed: Full/Half Duplex Mode – Auto
MDI/MDI-X Connection – Standards: IEEE 802.3 for 10BaseT, IEEE
802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3ab for
1000BaseT(X), IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3x for
flow control, IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE
802.1w for Rapid Spanning Tree Protocol, IEEE 802.1p for Class of
Service, IEEE 802.1Q for VLAN Tagging – Packet Buffer Size: 2M Up
to 9K – MAC Address Table: 4K Store and Forward (full/half duplex
mode) – Transmission Mode: Delay time < 7s, Backplane bandwidth:
20Gbps – IGMP Group VLAN ID Range: 256 VID 1 to 4094 – Power
Supply: 9-56VDC, Redundant dual inputs – Power Consumption: 5 Watts
Max (Full Load) – Power Inputs Connector: 1 removable 6-contact
terminal blocks – Protection: Overload Current Protection, Reverse
Polarity Protection Software Features: – Redundancy Protocol:
Support STP/RSTP – Multicast Support: Support IGMP Snooping V1 –
VLAN: Support IEEE 802.1Q 4K VLAN, Port Isolation, Trunk Group
Setting – QOS: Support Port, 1Q, ACL, DSCP, CVLAN, SVLAN, DA, SA,
Port Priority, Queue Weight – Diagnostic Maintenance: Support port
mirroring, Port Statistics, Cable Diagnostic – Management Function:
WEBSNMPv1, EEE, Green Ethernet – Security: Broadcast/Multicast
Storm Protection, MAC filtering, MAC Constraint – Advance
Functions: Bandwidth Control (Ingress and Egress Rate), Jumbo
Frame, Firmware Online Upgrade, Configuration Backup Physical
Characteristics: – Housing: Aluminum case – IP Rating: IP40 –
Dimensions: 138mm x 108mm x 49mm (L x W x H) – Installation: DIN
Rail/Wall Mount – Weight: 680g Environmental: – Operating
Temperature: -40 to 75°C – Operating Humidity: 5%~90%
(non-condensing) – Storage Temperature: -40~85°C – MTBF: 907,476
hours @ Telcordia SR-332 Standard – Heat Dissipation: 34 BTU/h –
Cooling: Passive Cooling, Fanless Design – Noise Level: 0 dBA
Product Usage Instructions: 1. Installation: – Determine
whether to mount the switch using DIN Rail or Wall Mount. – Choose
a suitable location for installation, ensuring proper ventilation
and protection from environmental factors. – Connect the power
inputs to the appropriate 6-contact terminal blocks, following the
power input polarity protection. – Connect Ethernet devices to the
RJ45 ports or SFP ports as required. 2. Configuration: – Access the
switch’s WebGUI interface using a web browser on a connected
device. – Configure network settings, VLANs, and other parameters
as per your network requirements. – Save the configuration settings
after making changes. 3. Monitoring and Maintenance: – Monitor the
detailed status indicator to check the working state of the switch
at a glance. – Utilize the diagnostic maintenance features such as
port mirroring, Port Statistics, and Cable Diagnostic for
troubleshooting and monitoring. – Perform firmware upgrades and
configuration backups using the provided software tools. 4. Power
and Protection: – Ensure a stable power supply within the input
voltage range of 9-56VDC. – Be aware of overload current protection
and reverse polarity protection to prevent damage to the switch. 5.
Environmental Considerations: – Operate the switch within the
specified operating temperature range of -40 to 75°C. – Maintain an
operating humidity level between 5% and 90% (non-condensing). –
Store the switch in a dry and cool environment with a temperature
range of -40~85°C. Note: For detailed instructions on specific
configurations and advanced features, refer to the user manual
provided with the product.
FR-7S3208-Lite
Fiberroad’s Smart Industrial Ethernet Switch FR-7S3208L is an innovative and independent product for industrial networking. We define it as the LITE model, designed specifically for small industrial networks and highly cost-effective. In addition to adopting industry-leading technical standards, this product can guarantee reliable and reliable Ethernet transmissions.
Main Features
A compact, all-aluminium case with a fanless design.
The temperature from -40 to 75°C maintains performance in extreme conditions
DIP Switch supports RSTP/VLAN/SPEED. Provide 9K bytes Jumbo frame that is
compatible with multiple extension protocols Facility IEEE802.3az energy-efficient Ethernet Complete with electricity surge protection, easy
to use in an outdoor environment Detailed status indicator, working state at a
glance Design for power input polarity protection Either DIN rail or Wall Mount Installation An easy-to-use WebGUI interface
Operation Temp
Surge
IP40 RATED
Ethernet data exchange, convergence, and long-distance optical transmission are available with efficient bandwidth and reliable fibre optic networks. Industrial switches conform to many characteristics, such as no fan, low power consumption, high reliability and stability, and easy maintenance. Industrial Ethernet Switch adopts mature technology and open network standards, adapts to low temperature and high temperature, protects against electromagnetic interference, anti-salt fog, antivibration, and anti-shake, and is equipped with redundant dual It can also operate either at the standard operating temperature range of -40 to 75. Industrial switches support standard 19″ rack mounts with IP40 protection and are perfect choices for harsh environments.
©2022 Fiberroad Technology Co., Ltd All right reserved
Page 1 of 6
Product Specifications
Ethernet Interface Mode Ports Port Mode(Tx)
Standards
Packet Buffer Size Maximum Packet Length MAC Address Table Transmission Mode
Exchange Property
IGMP Group VLAN ID Range
Power Supply Input Voltage Power Consumption Power Inputs Connector Protection
LED
PWR RUN
Link/ACT (1-10)
State ON OFF Blinking ON Blinking OFF
FR-7S3208 8×10/100/1000Base-TX RJ45 ports+2×100/1000Base-X SFP ports
Auto-Negotiation Speed Full/Half Duplex Mode Auto MDI/MDI-X Connection IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3ab for 1000BaseT(X) IEEE 802.3z for 1000BaseSX/LX/LHX/ZX IEEE 802.3x for flow control IEEE 802.1D-2004 for Spanning Tree Protocol IEEE 802.1w for Rapid Spanning Tree Protocol IEEE 802.1p for Class of Service IEEE 802.1Q for VLAN Tagging
2M Up to 9K
4K Store and Forward (full/half duplex mode)
Delay time: < 7s Backplane bandwidth: 20Gbps
256 VID 1 to 4094
9-56VDC,Redundant dual inputs 5 Watts Max(Full Load) 2
1 removable 6-contact terminal blocks Pin 1/2 for Power 1, Pin 3/4 for Power 2, Pin 5/6 for fault alarm
Overload Current Protection, Reverse Polarity Protection
Description
Power is being supplied Power is not being Supplied. The system is running well Port connection is active Data transmitted Port connection is not active.
©2022 Fiberroad Technology Co., Ltd All right reserved
Page 2 of 6
Product Specifications
Software Features Redundancy Protocol Multicast Support VLAN QOS Diagnostic Maintenance Management Function Security Advance Functions
Support STP/RSTP Support IGMP Snooping V1 Support IEEE 802.1Q 4K VLAN, Port Isolation, Trunk Group Setting Support Port, 1Q, ACL, DSCP, CVLAN, SVLAN, DA, SA, Port Priority, Queue Weight Support port mirroring, Port Statistics, Cable Diagnostic WEBSNMPv1, EEE, Green Ethernet Broadcast/Multicast Storm Protection, MAC filtering, MAC Constraint Bandwidth Control(Ingress and Egress Rate), Jumbo Frame, Firmware Online Upgrade, Configuration Backup
Physical Characteristics Housing IP Rating Dimensions Installation Weight Environmental Operating Temperature Operating Humidity Storage Temperature MTBF Heat Dissipation Cooling Noise Level
Aluminum case IP40 138mm x 108mm x 49mm (L x W x H) DIN Rail/Wall Mount 680G
-40 to 75 5%~90% (non-condensing) -40~85 907,476 hours @ Telcordia SR-332 Standard 34 BTU/h Passive Cooling, Fanless Design 0 dBA
DIP Switch #1 #2 #3
RSTP Enable/DisableDefault: Enable VLAN Enable/Disable (Default: Disabled) SFP port fixed speed, ON as 100M (Default: 100/1000M Adaptive)
Notes: 1. RSTP switches to the ON position, which indicates RSTP is in disabled status. 2. VLAN switches to the ON position, which indicates VLAN is in enabled status. All LAN ports are only
able to communicate with the SFP uplinks when this option is enabled. 3. To take effect the DIP Switch function while the ethernet switch is in operation, there is a need to
reboot the Ethernet switch after tuning the DIP switch.
©2022 Fiberroad Technology Co., Ltd All right reserved
Page 3 of 6
Product Specifications
Regulatory & Warranty Safety EMI EMS
Shock Free Fall Vibration Environmental Warranty
Package Contents Device Installation Kit
Documentation
IEC/EN 62368-1 EN55032 Class A, CISPR 32 FCC Part 15B Class A EN61000-4-2 (ESD) EN61000-4-3 (RS) EN61000-4-4 (EFT) EN61000-4-5 (Surge) EN61000-4-6 (CS) EN61000-4-8 (PFMF IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 RoHS 5 Years, Details See: www.fiberroad.com
1x Industrial Ethernet Switch
2 x Caps, plastic, for SFP Slots Or 2 x Caps, plastic, for SC fiber port Or 2 x Caps, plastic, for ST fiber port 2x Wall-Mount Kits 1x DIN Rail Buckle 1 x Quick installation guide 1 x Warranty card 1x Product notice
Dimensions Unit: mm
8 108mm
Side View
46
32.7
DIN Rail Clip
49mm
33
8 26.6
43
Rack Mount Kit
Rear View
166 152 109.8 18
138mm
©2022 Fiberroad Technology Co., Ltd All right reserved
Page 3 of 6
Accessories(Sold Separately)
Power Supply FR-I-60-24 FR-I-120-48 FR-I-240W-48 FR-I-480W-48
DIN-rail 24 VDC power supply with 60W/0.6A, 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature
DIN-rail 48-58V VDC power supply with 120W/1.2A, , 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature
DIN-rail 48-55V VDC power supply with 240W/2A, , 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature
DIN-rail 48-55V VDC power supply with 480W/4A, , 85 to 264 VAC, or 120 to 370 VDC input, -20 to 70°C operating temperature
SFP Optical Transceiver FRSX-1L311C-I FRSX-1L341C-I FRSX-1L5X1C-I FRSX-1L3523/5323C-I
1.25Gb/s 1310nm 10km SFP, wide operation temperature range of -40-85-40 – 185
1.25Gb/s 1310nm 40km SFPwide operation temperature range of -40-85-40 – 185
1.25Gb/s 1550nm 80/100km SFPwide operation temperature range of -40-85-40 – 185
1.25Gb/s 1310nm/1550nm 20km BiDi SFPwide operation temperature range of -40-85-40 185
Armored Fiber Patch Cable / LAN Cable
FRPC-A-LC
Armored LSZH LC UPC to LC UPC Duplex OS2 single mode 7.0mm for Ourdoor Application , 1-50m
FRLC-A-CAT6
Armored Cat6 Snagless shielded(SFTP) Ethernet Network Patch Cable, 26AWG, 1000Base-T, 0.5m 3m
Precautions
To avoid damage to the equipment and personal injury caused by improper use, please observe the following precautions:
Keep the power off during installation, wear an anti-static wrist, and ensure that the anti-static wrist is in good contact with the skin to avoid potential safety hazards.
The switch can work normally under the correct power supply. Please confirm that the power supply voltage matches the
voltage indicated by the switch. Before powering on the switch, please make sure that the power circuit is not overloaded, so as not
to affect the normal operation of the switch and even cause unnecessary damage. To avoid the risk of electric shock, do not open the case while the switch is working, even if it is not
charged, do not open it yourself. Before cleaning the switch, pull out the power plug of the switch. Do not wipe with a wet cloth. Do
not use liquid to clean it. The equipment installed in the rack is generally from bottom to top to avoid overload installation. Avoid placing other heavy objects on the surface of the switch to avoid accidents.
©2022 Fiberroad Technology Co., Ltd All right reserved
Page 5 of 6
Order Information
Model Number FR-7S3204 FR-7S3208L
10/100/1000Base-T(X), RJ45
4
8
100/1000Base-X Port
2
2
Optical Port Connector Option
LC
LC
PoE Standard — —
Input Voltage
DC9-56V
DC9-56V
Operating Temp.
-40 to +75
-40 to +75
The information in this document is subject to change without notice. Fiberroad has made all effects to ensure the accuracy of the information, but all information in this document does not constitute any kind of warranty. Visit our website for the most up-to-date product information
For more information
For more information about Fiberroad Smart Industrial Ethernet series products, Visit https://www.fiberroad.com or contact your local account representative.
©2022 Fiberroad Technology Co., Ltd All right reserved
Page 6 of 6
