CART-V01BK Black Height Adjustable Laptop Desk Exercise Bike Cart
Product Information:
The Black Laptop Desk / Exercise Bike Cart is a versatile
product that can be used as a desk or exercise bike cart. The
product comes with support columns, a crossbar, feet, locking
casters, casters, a desktop, screws, and wrenches. The product has
a weight capacity of 11lbs (5kg) and is designed to prevent
tip-over and choking hazards. The product can be assembled by
following the instructions provided in the manual.
Product Usage Instructions:
- Decide whether you want the Locking Casters (D) to be in the
front or rear of the cart. The front of the Feet (C) are the holes
furthest away from the foot mounting plate. Screw the Casters (D,
E) into the Feet (C) using the wrench (T-A). - Attach the Cross Bar (B) to each of the Support Columns (A)
using M6x25 Screws (S-A). Note that the larger hole in the Cross
Bar (B) should be facing upwards. Tighten with the 4mm Allen Wrench
(T-B). - With the column assembly flipped upside down, secure the Feet
(C) to the Support Columns (A) using M6x12 Screws (S-B). Tighten
with the 4mm Allen Wrench (T-B). Note: make sure the longer end of
the foot (C) is on the same side as the longer end of the Support
Columns (A). - Attach the Support Columns (A) to the Desktop (F) using M5x12
Screws (S-C). Tighten using the Philips end of the 4mm Allen Wrench
(T-B) or a Phillips screwdriver. - Loosen the levers on the Support Columns (A) to adjust the
height of the desktop.
If any parts are received damaged or defective, please contact
the VIVO support team at 309-278-5303 or [email protected]. The
support team is available Monday-Friday from 7:00am-7:00pm CST and
can offer immediate assistance with rapid response times. They are
happy to replace parts to ensure you have a fully functioning
product.
Black Laptop Desk / Exercise Bike Cart
Instruction Manual
SKU: CART-V01BK
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cart-v01bk
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
www.vivo-us.com Chat live with an agent!
309-278-5303
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or inappropriate use.
TIPOVER WARNING
SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP PREVENT TIPOVER: · NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART OF CART. · USE TIPOVER RESTRAINT OR ANCHOR CART TO WALL USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK OF TIPOVER.
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x2) Support Column
Set
B (x1) Cross Bar
C (x2) Foot
D (x2) Locking Caster
E (x2) Caster
F (x1) Desktop
S-A (x4) M6x25 Screw
S-B (x8)
S-C (x8)
M6x12 Screw M5x12 Screw
T-A (x1) Wrench
T-B (x1) 4mm Allen
Wrench
DO NOT EXCEED WEIGHT CAPACITY.
11lbs
Failure to do so may result in serious injury.
(5kg)
ASSEMBLY STEPS
STEP 1
Decide whether you want the Locking Casters (D) to be in the front or rear of the cart. The front of the Feet (C) are the holes furthest away from the foot mounting plate. Screw the Casters (D, E) into the Feet (C) using the wrench (T-A).
E
E
T-A
D
D
Foot
Mounting
Plate
C
2
STEP 2
STEP 3
Attach the Cross Bar (B) to each of the Support Columns (A) using M6x25 Screws (S-A). Note that the larger hole in the Cross Bar (B) should be facing upwards. Tighten with the 4mm Allen Wrench (T-B).
With the column assembly flipped upside down, secure the Feet (C) to the Support Columns (A) using M6x12 Screws (S-B). Tighten with the the 4mm Allen Wrench (T-B).
S-A T-B
Note: make sure the longer end of the foot (C) is on the same side as the longer end of the Support Columns (A).
S-B
B Larger Hole
T-B C
A
A
STEP 4
Attach the Support Columns (A) to the Desktop (F) using M5x12 Screws (S-C). Tighten using the Philips end of the 4mm Allen Wrench (T-B) or a Phillips screwdriver.
Front
STEP 5
Loosen the levers on the Support Columns (A) to adjust the height of the desktop.
T-B
A
S-C
F
Front 3
Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us
LAST UPDATED: 11/03/2022 REV1.1
