DFL Series Constant Current Independent Dimmable Driver

Product Information

The Constant Current Independent Dimmable Driver DFL Series,
produced by BOKE Drivers Co., Ltd., is a versatile product that
offers various features and functions to support efficient and
customizable lighting solutions. It supports DALI-2 DT6 + D4i
dimming mode and advanced functions such as Emergency Lighting (EL)
and Constant Light Output (CLO). The driver allows for programming
of the output current through both the DALI interface and the NFC
interface. It also enables quick installation of sensors and
wireless control modules through the D4i interface. The driver
features input AC and output DC power metering, as well as loop-in
and loop-out wiring without the need for a junction box. With its
16-level current output, soft dimming, and flicker-free operation
at any brightness level, it meets the requirements of ErP
certification. The driver utilizes HPC patented technology to
ensure consistent brightness at any dimming level.

Interfaces:

DALI-2 D4i (DT6+Part 250,251,252,253)

Functions:

Supports central emergency application
Supports self-contained emergency application
Emergency lighting (EL)
Constant light output function (CLO)
Programming via DALI
Programming via NFC
Protective features (short-circuit, overload, no-load, hot
plug-in protection)

Suitable for:

Luminaries with independent drivers such as downlights,
spotlights, panel lights, etc.

Typical Applications:

LED indoor lighting
LED office lighting
LED commercial lighting

Product Usage Instructions

To use the BOKE Constant Current Independent Dimmable Driver DFL
Series, follow these instructions:

Ensure that the input voltage supplied to the driver falls
within the rated input voltage range of 200-240VAC/DC.
Connect the driver to luminaries with independent drivers, such
as downlights, spotlights, or panel lights. Make sure the wiring is
secure.
If emergency lighting functionality is required, configure the
driver according to the desired application (central emergency or
self-contained emergency).
To dim the lights, use the DALI-2 DT6+D4i dimming mode. Adjust
the output current through the DALI interface or the NFC interface
to achieve the desired brightness level.
For advanced functions such as Emergency Lighting (EL) or
Constant Light Output (CLO), program the driver via DALI or NFC
interfaces.
Ensure that the protective features are enabled to prevent
short-circuits, overloads, no-load situations, and hot plug-in
issues.
If power metering is required, monitor the input AC and output
DC power levels.
If necessary, perform loop-in and loop-out wiring without the
need for a junction box.
If desired, utilize the 16-level current output feature using
the DIP-switch.
Enjoy soft dimming and flicker-free operation at any brightness
level, meeting the requirements of ErP certification.

For more information or assistance, you can contact BOKE Drivers
Co., Ltd. at [email protected] or visit their website at www.bokedriver.com.

View Fullscreen

BOKE Drivers Co., Ltd.

Constantcurrentindependentdimmabledriver DFLSeriessuffixDF(DALI-2DT6+D4i+EL+CLO+DALIPROG+NFCPROG)

Features – Support DALI-2 DT6 + D4i dimming mode – Support advanced functions such as EL, CLO – The output current programming can be realized through the DALI interface
and the NFC interface – Quickly install the sensor and the wireless control module through the D4i interface – Input AC and output DC power metering – Loop-in and loop-out wiring without junction box – 16-level current output can be realized by DIP-switch – Soft dimming and flicker-free at any brightness, meets the new requirements
of ErP certification – Using HPC patented technology, at any dimming level, the brightness of
the luminaries is the same – Dimming range 1~100%, output current accuracy 2% – Standby power input < 0.5W, meets the requirements of ErP certification – High PF, high efficiency, low THD – Screw-free and pressing type strain relief, easier install – Supports 0.75-1.5mm2 input wires, stronger wiring – Intelligent LED hot-plug protection function – SELV and Class II design, suitable for use outside of the light – Passed CE, ENEC, UKCA, RCM, DALI-2, EL and other certifications – IP20 protection grade, indoor use – Nominal life-time up to 100,000 h – 5-year guarantee

Interfaces – DALI-2 D4i (DT6+Part 250,251,252,253) Functions – Support central emergency application – Support self-contained emergency application – Emergency lighting(EL) – Constant light output function(CLO) – Programming via DALI – Programming via NFC – Protective features (short-circuit, overload,no-load, hot plug-in protection ) Suitableforlights – Suitable for luminaries with independent drivers such as
downlights, spotlights, panel lights, etc – Not suitable for luminaries with built-in drivers Typicalapplications – LED indoor lighting – LED office lighting – LED commercial lighting

[email protected]

tuvsud .com / ps – cert
Energy Data

PROG EL CLO

www.bokedriver.com

REV 1.0 2022-7-10 P1

BOKE Drivers Co., Ltd.

Modelcodingrulesof DFLseries

BK – D F L X X X – A X X X X z

Function mode(DP: DALI-2 DT6+D4i+EL+CLO+DALI PROG+NFC PROG) Output load voltage range identification code Output current Distinguish code
Product series
BOKE

Functionlist Model

Suffix

Wired dimming Energy detection

Advanced functions

Device Configuration

DALI-2

D4i

AOC

CLO DALI interfaces NFC interfaces

BK-DFL042-A

BK-DFL060-A

Modellist

Model

Input voltage Output power

Output voltage

Output current

BK-DFL042-A1100ADF 200-240VAC/DC BK-DFL060-A2000ADF 200-240VAC/DC

42W MAX. 12-38/40/42VDC 61.2W MAX. 12-30/32/34/36/38/40/42VDC

0.45-1.1A 0.8-2A

Dimension

Certification

L160*W86*H30mm CE, ENEC, UKCA, RCM, DALI-2, EL L180*W86*H30mm CE, ENEC, UKCA, RCM, DALI-2, EL

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P2

BOKE Drivers Co., Ltd.

Technical data

Product model Output parameters Regulation method Rated output current range Rated output voltage range Rated output power Output current adjustment Output current ripple LF Output current accuracy

BK-DFL042-A1100ADF
Constant Current 0.45-1.1A
12-38/40/42V 42W Max
DIP S.W(16 levels) ±2% ±2%

Linear regulation

±1%

Load regulation No load output voltage

±1% 50VDC

Flicker-free(typical) Input parameters

Flickering percent(IEEE 1789)=0.177%, Flicker index(IEEE 1789)=0.001, Pst LM = 0.032, SVM = 0.005, (The above parameters are obtained from testing the panel lights)

Rated input voltage range Input voltage range Input votage shock Input current Input frequency

200-240VAC 200-240VDC 180-264VAC 180-264VDC <380 V AC <0.25A (Rated input voltage ) 0/50/60Hz

Input PF/Input DF Input THD Efficiency(typical) In-rush current Start/Switchover/Turn off

PF>0.95 (230V AC & Full load),DF>0.98 (230V AC & Full load) 10% (230V AC & Full load) 87% (230V AC & Full load) 11.99A peak ,200us duration(50 % Ipeak), see the description below for details <0.7s(AC start),<0.7s(DC start),<0.3s(AC/DC switchover),<0.5s(Turn off )

Switching cycles Power consumption Safety Withstand voltage Mains surge capability Leakage current

> 50,000 switching cycles Full load(Pin):47.4W, No load(Pno): N/A, On stand-by(Psb) : <0.5W, Network stand-by(Pnet) : N/A
I/P-O/P(LED):3750V AC,I/P-DALI:1 500V AC, O/P(LED)-DALI:1500V AC L-N:2KV(Performance criterion:B) 0.4mA (230V AC & Full load)

Isolation resistance Control interface DALI dimming port pushDIM dimming port 1-10V 3in1 dimming port

I/P-O/P:100M/500Vdc/25/70% RH
Voltage range: 9.5-22.5V, typical 16V, interface current consumption: 1.8mA Voltage range: 180-264V 47/63Hz N/A

Auxiliary power supply Dimming range

N/A 1%-100%

Dimming drive mode

AM(amplitude modulation)

Emergency support Central emergency system

Supported

Self-contained emergency Supported

Environment & Life time

Operating temperature Case temperature Operating humidity Storage temp./humidity IP grade MTBF

Ta=-20-45 Tc=85 5-85% RH, not condensed -40-80, 5-85% RH, not condensed IP20 500,000H,MIL-HDBK-217F(25)

Life-time Vibration resistant Acoustic Noise Environmental protection

Nominal life-time up to 100,000 h, see the description below for details 10~500Hz,5G 12min./1cycle,period for 72min. each along X,Y,Z axes <25dB(30cm, Normal operation) RoHS

Certifications and standards

Certified

CE, ENEC, UKCA, RCM, DALI-2, EL

Safety

EN61347-1, EN61347-2-13, EN62384

EMC

EN55015, EN61000-3-2 , EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547

DALI-2

IEC 62386-101(DALI-2), IEC 62386-102(DALI-2), IEC 62386-207(DALI-2),DALI Part 250,251,252,253

Compatible IEC 61347-2- 13 Annex J , compatible with EN 60598-2-22 and EN 50172

N/A

Remarks
1.By default, all parameter are measured at 230VAC input, full load and 25 of ambient temperature.

2.The driver can not be installed inside the luminare. when the driver is used with the luminare, the EMC of the whole luminare needs to be tested.

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P3

BOKE Drivers Co., Ltd.

Technical data

Product model Output parameters Regulation method Rated output current range Rated output voltage range Rated output power Output current adjustment Output current ripple LF Output current accuracy

BK-DFL060-A2000ADF
Constant Current 0.8-2A
12-30/32/34/36/38/40/42VDC 42W Max
DIP S.W(16 levels) ±2% ±2%

Linear regulation

±1%

Load regulation No load output voltage

±1% 50VDC

Flicker-free(typical) Input parameters

Flickering percent(IEEE 1789)=0.339%, Flicker index(IEEE 1789)=0.001, Pst LM = 0.046, SVM = 0.005, (The above parameters are obtained from testing the panel lights)

Rated input voltage range Input voltage range Input votage shock Input current Input frequency

200-240VAC 200-240VDC 180-264VAC 180-264VDC <380 V AC <0.36A (Rated input voltage ) 0/50/60Hz

Input PF/Input DF Input THD Efficiency(typical) In-rush current Start/Switchover/Turn off

PF>0.95 (230V AC & Full load),DF>0.98 (230V AC & Full load) 10% (230V AC & Full load) 87% (230V AC & Full load) 17.23A peak ,207us duration(50 % Ipeak), see the description below for details <0.7s(AC start),<0.7s(DC start),<0.3s(AC/DC switchover),<0.5s(Turn off )

Switching cycles Power consumption Safety Withstand voltage Mains surge capability Leakage current

> 50,000 switching cycles Full load(Pin):69.4W, No load(Pno): N/A, On stand-by(Psb) : <0.5W, Network stand-by(Pnet) : N/A
I/P-O/P(LED):3750V AC,I/P-DALI:1 500V AC, O/P(LED)-DALI:1500V AC L-N:2KV(Performance criterion:A) 0.4mA (230V AC & Full load)

Isolation resistance Control interface DALI dimming port pushDIM dimming port 1-10V 3in1 dimming port

I/P-O/P:100M/500Vdc/25/70% RH
Voltage range: 9.5-22.5V, typical 16V, interface current consumption: 1.8mA Voltage range: 180-264V 47/63Hz N/A

Auxiliary power supply Dimming range

N/A 1%-100%

Dimming drive mode

AM(amplitude modulation)

Emergency support Central emergency system

Supported

Self-contained emergency Supported

Environment & Life time

Operating temperature Case temperature Operating humidity Storage temp./humidity IP grade MTBF

Ta=-20-45 Tc=85 5-85% RH, not condensed -40-80, 5-85% RH, not condensed IP20 500,000H,MIL-HDBK-217F(25)

Life-time Vibration resistant Acoustic Noise Environmental protection

Nominal life-time up to 100,000 h, see the description below for details 10~500Hz,5G 12min./1cycle,period for 72min. each along X,Y,Z axes <25dB(30cm, Normal operation) RoHS

Certifications and standards

Certified

CE, ENEC, UKCA, RCM, DALI-2, EL

Safety

EN61347-1, EN61347-2-13, EN62384

EMC

EN55015, EN61000-3-2 , EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547

DALI-2

IEC 62386-101(DALI-2), IEC 62386-102(DALI-2), IEC 62386-207(DALI-2),DALI Part 250,251,252,253

Compatible IEC 61347-2- 13 Annex J , compatible with EN 60598-2-22 and EN 50172

N/A

Remarks
1.By default, all parameter are measured at 230VAC input, full load and 25 of ambient temperature.

2.The driver can not be installed inside the luminare. when the driver is used with the luminare, the EMC of the whole luminare needs to be tested.

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P4

BOKE Drivers Co., Ltd.

Electrical values

BK-DFL042-A1100ADF Operating window

Output voltage (V)

Eficiency (%)

50 40 30 20 10 00
0

450

700

800

900

1000 1100

Output current(mA) Efficiency vs load

Operating window 100 % Operating window dimmed

90.00 85.00 80.00 75.00 70.00 65.00 60.00 55.00 50.00
10% 1.1A 0.7A

20% 30% 40% 50% 60%

1.05A 0.65A

1A 0.6A

0.95A 0.55A

0.9A 0.525A

70% 80% 90% 100%

0.85A 0.5A

0.8A 0.475A

0.75A 0.45A

Load(%)

Power factor vs. Load

1.000

0.900

0.800

0.700

0.600

0.500

0.400 10% 20%

1.1A 0.7A

1.05A 0.65A

30% 40% 50% 60%

1A 0.6A

0.95A 0.55A

0.9A 0.525A

70% 80% 90% 100%

0.85A 0.5A

0.8A 0.475A

0.75A 0.45A

Load(%)

Expected life-time

Life-time(H)

Life-time vs. case temperature

110,000 100,000
90,000 80,000 70,000 60,000 50,000 40,000 30,000 20,000

Case temperature(Tc)

THD

Output current (mA)

Operating window

1200 1000
800 600 400 200
00 0 5 10 15 20 25 30 35 40 45

Output power(W) THD vs. Load

Operating window 100 % Operating window dimmed

60.0

50.0

40.0

30.0

20.0

10.0

0.0 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

1.1A 0.7A

1.05A 0.65A

1A 0.6A

0.95A 0.55A

0.9A 0.525A

0.85A 0.5A

0.8A 0.475A

0.75A 0.45A

Load(%)

Displacement factor vs. Load

1.000

0.900

0.800

0.700

0.600

0.500

0.400 10% 1.1A 0.7A

20% 30% 40% 50%

1.05A 0.65A

1A 0.6A

0.95A 0.55A

60% 70% 80% 90%

0.9A 0.525A

0.85A 0.5A

0.8A 0.475A

100% 0.75A 0.45A

Load(%)

-The life-time of the LED driver is shown in the figure above (calculated based on the 90% survival rate). – The relation of tc to ta temperature depends also on the luminaire design.

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P5

BOKE Drivers Co., Ltd.

Electrical values

BK-DFL060-A2000ADF Operating window

Output voltage (V)

50 40 30 20 10 00
0

800 1000 1200 1400 1600 1800 2000

Eficiency (%)

Output current(mA) Efficiency vs load

Operating window 100 % Operating window dimmed

90.00 85.00 80.00 75.00 70.00 65.00 60.00 55.00 50.00

10% 20% 30% 40% 50%

2A 1.25A

1.9A 1.2A

1.8A 1.15A

1.7A 1.1A

60%
1.6A 1.05A

70% 80% 90% 100%

1.5A 1.A

1.4A 0.9A

1.3A 0.8A

Load(%)

Power factor vs. Load

1.000

0.900

0.800

0.700

0.600

0.500

0.400

10% 20% 30% 40% 50%

2A 1.25A

1.9A 1.2A

1.8A 1.15A

1.7A 1.1A

60% 70% 80% 90% 100%

1.6A 1.05A

1.5A 1.A

1.4A 0.9A

1.3A 0.8A

Load(%)

Expected life-time

Life-time(H)

Life-time vs. case temperature

110,000 100,000
90,000 80,000 70,000 60,000 50,000 40,000 30,000 20,000

Case temperature(Tc)

THD

Output current (mA)

Operating window

2100 1800 1500 1200
900 600
00 0

30 35 40 45 50 55 60 65

Output power(W) THD vs. Load

Operating window 100 % Operating window dimmed

70.0

60.0

50.0

40.0

30.0

20.0

10.0

0.0 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

2A 1.25A

1.9A 1.2A

1.8A 1.15A

1.7A 1.1A

1.6A 1.05A

1.5A 1.A

1.4A 0.9A

1.3A 0.8A

Load(%)

Displacement factor vs. Load

1.000 0.900 0.800

0.700

0.600

0.500

0.400

10% 20% 30% 40%

2A 1.25A

1.9A 1.2A

1.8A 1.15A

50% 1.7A 1.1A

60% 70% 80% 90% 100%

1.6A 1.05A

1.5A 1.A

1.4A 0.9A

1.3A 0.8A

Load(%)

-The life-time of the LED driver is shown in the figure above (calculated based on the 90% survival rate). – The relation of tc to ta temperature depends also on the luminaire design.

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P6

BOKE Drivers Co., Ltd.

Surge

Model

Ipeak

BK-DFL042-A1100ADF 11.99A BK-DFL060-A2000ADF 17.23A

Twidth 200us 207us

Condition

Relative number of MCB/pcs B10 B13 B16 B20 B25 C10 C13 C16 C20 C25 D10 D13 D16 D20 D25

AC 230V,Full load,

33 41

64 33

83 33

Cold start,Ta30,

MCB is not installed side by side

23 28

44 23

56 23

Remarks
– The number of drives mounted under different MCBs in the table is the maximum value. Please do not exceed this number during installation.
– Calculation uses typical values from ABB series S200 as a reference. – Different brands and models of miniature circuit breakers, the number of drives
mounted will be slightly different. – If the ambient temperature of the MCB installation exceeds 30°C or multiple MCBs
are installed side by side, the number of drives mounted will be reduced and the
calculation needs to be recalculated. – Electrician’s usually consider Type B for household lighting and Type C for commercial
lighting application.

Ipeak

Twidth

50% Ipeak

Functions
Output short-circuit behaviour – In case of a short-circuit at the LED output ,the LED output is switched off. – After restart of the LED driver ,the output will be activated again.
Output no-load operation – The LED driver will not be damaged in no-load operation. – The output will be deactivated and is therefore free of voltage. – If a LED load is connected , the device has to be restarted before the output
will be activated again. Output overload protection – If the output voltage range is exceeded the LED driver turns off the LED output. – After restart of the LED driver the output will be activated again.
Output hot plug-in – For protection LED if plug the LED into the output of the powered driver,
the LED will not on, the device has to be restarted.
Driver restart method There are two ways to restart the device:
– Through the AC input portr:disconnect the AC of the driver and power it again.
– Through dimming interface.
DALI:send”OFF”command first,then send “MAX”command.
Adjustable output current (AOC) – The output current of the driver can be adjusted within a certain range, and 2 options can be selected through the device configuration software. Setting 1 (default): DIP-switch The output current is determined by the selection of the DIP-switch. Setting 2: Programming The output current is determined by the programming setting.

Constant light output (CLO)
– The luminous flux of a LED decreases constantly over the life-time. – The CLO function ensures that the emitted luminous flux remains stable.For
that purpose the LED current will increase continuously over the LED life-time. – In device configuration it is possible to select a start value(in percent) and an expected life-time.The LED Driver adjusts the current afterwards automatically.
Emergency lighting(EL) – The driver works normally under DC input. – When the driver is applied in DC input, the positive pole of the DC cable should be connected to the ACL/DC+ terminal, and the negative pole of the DC cable should be connected to the ACN/DC- terminal. If the connection is reversed, the driver will not be damaged, but it will affect the EL function normal work. – The output response action after DC input can be set through device configuration software. Setting (default): When DC input, the output of the driver remains unchanged, and the dimming function responds normally. Setting : When DC input, the output of the driver jumps to the set brightness, and the dimming function is invalid.

Insulation between circuits

Isolation
Input Output
DALI Case

Input
Double Basic Double

Output
Double –
Basic Basic

DALI
Basic Basic
Basic

Case
Double Basic Basic
–

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P7

Label

BOKE Drivers Co., Ltd.

DIP-switch & output current

BK-DFL042-A1100ADF

Pin(W)

Output

typ. Prated(W) Irated(mA) Voltage(Vdc)

21.5 18.90 450

12-42 ON ON ON ON

22.7 19.95 475

12-42

— ON ON ON

23.8 21.00 500

12-42 ON — ON ON

24.9 22.05 525

12-42

— — ON ON

26.1 23.10 550

12-42 ON ON — ON

28.4 25.20 600

12-42

— ON — ON

30.7 27.30 650

12-42 ON — — ON

33.0 29.40 700

12-42

— — — ON

35.4 31.50 750

12-42 ON ON ON —

37.7 33.60 800

12-42

— ON ON —

40.1 35.70 850
42.5 37.80 900 44.9 39.90 950 47.2 42.00 1000 47.4 42.00 1050 47.4 41.80 1100

12-42 12-42 12-42 12-42 12-40 12-38

ON — ON — — ON -ON ON — — ON — -ON — — — — — —

BK-DFL060-A2000ADF

Pin(W)

Output

typ. Prated(W) Irated(mA) Voltage(Vdc)

37.9 33.6 800

12-42 ON ON ON ON

42.5 37.8 900

12-42

— ON ON ON

47.2 42.0 1000

12-42 ON — ON ON

49.6 44.1 1050

12-42

— — ON ON

51.9 46.2 1100

12-42 ON ON — ON

54.3 48.3 1150

12-42

— ON — ON

56.6 50.4 1200

12-42 ON — — ON

59.0 52.5 1250

12-42

— — — ON

61.0 54.6 1300

12-42 ON ON ON —

65.7 58.8 1400

12-42

— ON ON —

67.4 60.0 1500
68.3 60.8 1600 69.2 61.2 1700 69.4 61.2 1800

12-40 12-38 12-36 12-34

ON — ON — — ON -ON ON — — ON — —

69.2 60.8 1900 68.6 60.0 2000

12-32 ON — — —

12-30

— — — —

Remarks: 1. It means that this item is the factory default current.
— 2. It means that this channel is OFF.

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P8

BOKE Drivers Co., Ltd.

D4icontrollerapplication1(busmountapplication)

Internet

DALIbus

Cloud/Computer

APPcontroller Buspowersupply

LEDDriver(D4i)

Sensor

-TheapplicationcontrollercanobtaintherelevantdataofDALIPart251.252.253oftheD4idriverthroughtheD4ispecification, suchasenergyinformation,luminareinformation,operationinformation,etc. -WhentheD4idriverismountedtotheDALIbusapplication, Ifthebushasmountedbuspower,youneedtoturnoffthebuspowerinsideallD4idrivers! Ifthebushasnobuspowermounted,youcanturnontheinternalbuspowerforupto4D4idrivers! -ThebuspowerinsidetheD4idrivercanbeturnedonoroffviatheDALIconfigurationtool.
Loop-inandloop-outwiring(optional)Connectionschematic
Wiring diagram
ACN ACL DA1 DA2

ACL/DC+ ACN/DCDA+ DAACL/DC+ ACN/DCDA+ DA-

DFL driver

LED+ LED 1 2 3 4 ON

ACL/DC+ ACN/DCDA+ DAACL/DC+ ACN/DCDA+ DA-

DFL driver

LED+ LED 1 2 3 4 ON

Remarks: – Standard DALI control line voltage range:9.5V to 22.5V ,type 16V. – The two DALI control lines polarity-reversible. – Max. 64 DALI drivers per DALI control line. – The maximum distance length of the DALI control line is 300m at 2×1.5mm2. – DALI bus can be wired together with any mains voltage cables, but separate wiring
is recommended. – The configuration parameters of the driver can be set through the DALI configuration
tool or DALI application controller during installation, such as setting device address, group address, power-on level, bus-failure level, scene level, fade time, dimming curve, etc.
Please refer to the table below

Cable size 2×0.50mm2 2×0.75mm2 2×1.00mm2 2×1.50mm2

Distance max.100m max.150m max.200m max.300m

Power-onlevel:
When the driver is in DALI- dimming mode, the factory default level after each power-on is the brightest.
The power-on level can be set through the DALI configuration tool or DALI application controller during installation, and can be set to memory or fixed any brightness (such as off, darkest, %, etc.).
Note: The recommended setting for the default factory power-on level of the DALIdriver is the brightest in the DALI- standard.

Max.x15 Supportloop-inandloop-outwiring

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P9

BOKE Drivers Co., Ltd.

D4idimmingapplication2(intelligentlightingapplication)

D4icontroller
D4icontrolleroptionsare: -ZigbeetoDALIcontroller -BluetoothtoDALIcontroller -DALI+wirelessnode -occupysensor -lightsensor

ACL/DC+ ACN/DCDA+ DAACL/DC+ ACN/DCDA+ DA-

DFL driver

LED+ LED1 2 3 4 ON

-TheD4icontrollerispoweredbytheD4idriverandmustcomplywiththeDALIPart351specification. -ThebuspowerinsidetheD4idrivermustbeturnedon,anditcanbesetthroughtheDALIconfigurationtool,anditisturnedonbydefault.

Dimmingcurve

Output current(%)

100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
0

Logarithmic dimmer curve

100 150 200 254

dimming level

Remarks: The dimming curve can be selected by DALI configuration. The default is logarithmic dimming curve.

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P10

BOKE Drivers Co., Ltd. Device configuration Optional 1
USB

EasySet

NFC Reader Such as ID CPR30-USB

Optional 2

NFC

ACL/DC+ ACN/DCDA+ DAACL/DC+ ACN/DCDA+ DA-

DFL driver

LED+ LED1 2 3 4 ON NFC
Thedrivedoesnotrequirepower

USB
EasySet
Configure tools and software Name NFC Reader DALI Configurator PC Software
Parameters configure Configuration items Product information Adjustable output current(AOC) Emergency lighting(EL) Constant light output function(CLO) Hot plug-in protection(HPP) Run time Other parameters

USB

Switch

USB DALI OK
NG DALI Programmer
ERR

DA DA DA DA
DALI Programmer

Need to be powered
ACL ACN

ACL/DC+ ACN/DCDA+ DAACL/DC+ ACN/DCDA+ DA-

DDL driver

LED+ LED1 2 3 4 ON

Brand FEIG BOKE BOKE

Name CPR30-USB DALI Programmer
EasySet

Minimum version V1.0.0 V1.0.0 V1.0.0

Factory settings –
Activated Activated(setting 1)
Deactivated Activated

Parameter configuration NO YES YES YES YES NO YES

Read/Wirte Read Only Read/Wirte Read/Wirte Read/Wirte Read/Wirte Read Only

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P11

BOKE Drivers Co., Ltd.
Installation Mechanical dimensions Unit:mm DFL042
160

DFL060 180

INPUT

Pin Numbering function

ACL/DC+

ACN/DC-

DA+

DA-

ACL/DC+

ACN/DC-

DA+

DA-

colour orange orange
blue blue orange orange
blue blue

Input wire 0.75-1.5mm2
8-9mm

OUTPUT

Pin Numbering 1 2

function LED+ LED-

colour red black

Output wire 0.5-1.0mm2
8-9mm

Installation note

Hot plug-in – Hot plug-in is not supported due to residual output voltage of > 0 V. – If a LED load is connected the device has to be restarted. – Restart can be achieved by re-powering the driver or executing a on/off command (action) through the control interface (DALI, pushDIM) Wiring guidelines
– All connections must be kept as short as possible to ensure good EMI behaviour. – Mains leads should be kept apart from LED Driver and other leads (ideally 5 10 cm distance) – Max. lenght of output wires is 2 m. – Incorrect wiring can damage LED modules.

Mounting screw specifications and torque
– Max. torque at the clamping screw: 0.5 Nm / M4
Replace LED module
1. Mains off 2. Remove LED module 3. Wait for 5 seconds 4. Connect LED module again

Installation requirements
-Thedrivershouldbeinstalledinadry,acid-free,oil-free,fat-freeenvironment. – The installation ambient temperature of the drive shall not exceed the value of Ta at any time. -Thedrivershouldkeepacertaindistancefromtheheatingstuff(suchastheluminaireradiator).
– If the driver is used externally , the installation of the driver should also meet the following conditions: 1.The driver should be a certain distance between the drivers, as shown in Figure 1. 2.The driver keeps a certain distance from surrounding objects, as shown in Figure 2.

15cm

10mm
15cm 15cm

15cm

70mm

20mm

[email protected]

Figure 1

www.bokedriver.com

Figure 2 REV 1.0 2022-7-10 P12

Packaging

BOKE Drivers Co., Ltd.

Product

Packaging

10pcs×3layer=30pcs/CIN

Model DFL042-A

Product size L160*W86*H30mm

DFL060-A L180*W86*H30mm

Weight 235g 314g

Packaging size L170*W95*H40mm L190*W95*H40mm

Carton size L 360*W210*H220mm L410*W210*H220mm

Qty/carton 30pcs

N.W 7.05kg

30pcs

9.42kg

G.W 8.15kg 10.4kg

Additional information
1. This product can only be used outside the light body, Can not be used inside of the light, and it must be used within the specified working environment. 2. The life and MTBF of the product are for reference only, and do not represent a warranty statement. 3. For more information, please send an email to [email protected].

[email protected]

www.bokedriver.com

REV 1.0 2022-7-10 P13
