plus opto LF-AAA series 0-10v Dimmable Constant Current LED Drivers
Features
- Class 2 Power supply Constant Current dimmable
- Supports 0-10V, PWM, Rx dimming
- No Flicker
- 0.1% diming depth
- Selectable output current by DIP switch
- Fully encapsulated to IP20
- High efficiency
- Short circuit protection
To support our extensive range of LED products we offer a comprehensive range of LED drivers designed specifically for lighting applications. The LF-AAA series 0-10V dimmable drivers offer selectable output current and flicker free dimming control.
Specifications
| Part Number | Output Power | Input Voltage | Output Voltage | Output Current | Efficiency (full load) 230VAC | PFC (full load) 230VAC | Dimensions mm |
| LF-AAA008-0350-42 | 8W | 220-240 VAC | 9-42 Vdc | 100-350mA | 76% | 0.90 | 142.1×29.8×20.5 |
| LF-AAA008-0700-12 | 8W | 2-12Vdc | 350-700mA | 76% | 0.90 | 142.1×29.8×20.5 | |
| LF-AAA0012B-0400-42 | 12W | 9-42 Vdc | 150-400mA | 83% | 0.90 | 121.9×39.9×25 | |
| LF-AAA020B-0500-42 | 20W | 250-500mA | 85% | 0.95 | 121.9×39.9×25 | ||
| LF-AAA030-0750-42 | 30W | 550-750mA | 86% | 0.95 | 141.5x46x27.5 | ||
| LF-AAA040B-1050-42 | 40W | 750-1050mA | 87% | 0.95 | 141.5x46x27.5 |
High compatibility with single and multiple dimmer modules
Notes:
This data is for selection reference only. Please check the full data sheet for the latest specifications
Specifications may be subject to change without notice
