N7329-613 Luxour 6 Light Polished Nickel Island Chandelier
Product Information
The product model numbers are N7326-613 and N7329-613. The
product includes a fixture with six candelabra base bulb sockets
that can support bulbs up to 60 watts each or CFL/LED equivalent.
The product also includes a crossbar, mounting screws, junction box
screws, canopy, cap nuts, rods, stem, swivel, and finial.
Product Usage Instructions
- Before starting installation, shut off power at the fuse box or
circuit breaker. - Remove the old fixture and all mounting hardware from the
junction box. - Unpack the new fixture and lay out all parts on a clear
area. - Thread the stem (M) onto all thread (N).
- Determine the desired hanging height and thread rods (H, I, J,
K) to coupling (L). Then thread swivel (G) on canopy (E) onto rod
(H). Pass wires carefully through each rod, swivel (G), and canopy
(E). - Thread two mounting screws (A) into crossbar (B) spaced the
same distance apart as holes in canopy (E). Secure crossbar (B) to
junction box with junction box screws (C). - Use the provided support cable to support the weight of the
fixture. - Install six candelabra base bulbs up to 60 watts each or
CFL/LED equivalent in accordance with the fixture specification. Do
not exceed the specified wattage. - Your installation is now complete. Return power to the junction
box and test the fixture.
INSTALLATION INSTRUCTION FOR N7326-613/N7329-613
READ AND SAVE THESE INSTRUCTIONS
WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER. AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.
PREPATION ASSEMBLING THE FIXTURE(Fig.1) 1. Shut off the power at the fuse box or circuit breaker
box. Remove old fixture and all mounting hardware from junction box. 2. Carefully unpack your new fixture and lay out all the parts on a clear area. Take care not to lose any parts necessary for installation. 3. Thread stem (M) onto all thread (N). 4. Determine desired hanging height and thread rods (H, I, J, K) to coupling (L). Then thread swivel (G) on
canopy (E) onto rod (H). Pass wires carefully through each rod, swivel (G) and canopy (E). MOUNTING THE FIXTURE (Fig.1) 5. Thread two mounting screws (A) (Size: #8
32*1.2″L) into crossbar (B) spaced same distance apart as holes in canopy (E). Secure crossbar (B) to junction box (not provided) with junction box screws (C) (Size: #8-32*0.6″L). The length of mounting screws (A) into crossbar (B) may be adjusted if necessary. The side of crossbar (B) marked “GND” must face out. 6. The support cable is provided to support weight of
fixture while wiring. Attach hook (D) on the end of support cable to crossbar (B). Carefully allow support cable to support the weight of fixture while wiring. CONNECTING THE WIRES (Fig.2) 7. Connect electrical wires as shown in figure 2, making sure that all wire connectors are secured. If your junction box has a ground wire (green or bare copper), connect fixture’s ground wire to it. Otherwise, connect the fixture’s ground wire directly to crossbar (B) using green screw provided. 8. Tuck wire connectors neatly inside the junction box. COMPLETING THE INSTALLATION (Fig. 1) 9. Align canopy (E) to mounting screws (A) and secure with cap nuts (F). 10. Secure finial (P) onto all thread (O). 11. Hook crystal drop (Q) to finial (P).
11. Install (6) six candelabra base bulbs up to 60 watts each or CFL or LED equivalent (not included) in accordance with the fixture specification. (DO NOT EXCEED THE SPECIFIED WATTAGE!) (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!)
Fig.1 Fig.2
Set# A-016 -Crossbar -Ground screw -Mounting screw*2 -Junction box screws*2
W30-H-613
W30-1-613
CCV21060P-613
Your installation is now complete. Return power to the junction box and test the fixture.
A B
C
E F
H
a. Hardware Bag:
A. Mounting Screws *2
B. Crossbar *1
C. Junction Box Screws *2
E. Canopy *1 F. Cap Nuts *2
AB
C
E
P. Finial *1
F
P
b. Hardware Bag: I-J-K. Rod 12” *3
H. Rod 6″ *1
I,J,K H
