Metropolitan N7356-790 Prima Vista 6 Light Aged Antique Brass Island Chandelier Instruction Manual

N7356-790 Prima Vista 6 Light Aged Antique Brass Island Chandelier

Product Information:

Fixture Model: N7356-790

Date of Manufacture: May 20, 2022

Product Components:

• Set#A-012 (Crossbar, Ground Screw, Mounting Screw *2)
• Fixture Loop (H)
• Upper Assembly (K)
• Rod (M)
• Socket Assembly (S)
• Frame Assembly (R)
• Plastic Washers and Finials (Q)
• All Thread (C)
• Lock Washer (Y1) and Hex Nut (Y2)
• Quick Link (F)
• Chain (G)
• Acrylic Pole# – GP7356-1 *12 and GP7356-2 *4
• Canopy (D)
• Finial (E)
• Candelabra Base Bulbs (P) – up to 60 watts each or CFL or LED
  equivalent
• Chain# HCH2372-790

Product Usage Instructions:

WARNING: Before starting the installation, make
sure to shut off power at the fuse box or circuit breaker.

1. Remove the old fixture, including the mounting hardware, by
   shutting off power and carefully detaching it.
2. Unpack the new fixture and lay out all the parts in a clean
   area, taking care not to misplace any small parts necessary for
   installation.
3. Adjust the arms of the fixture to the proper position.
4. Thread the fixture loop (H) onto all thread (J) of the upper
   assembly (K).
5. Secure the rod (M) to all thread (O) of the socket assembly
   (S), then thread the upper assembly (K) to the rod (M).
6. Carefully place the rod threads (N) through the holes on top of
   the frame assembly (R). Tighten with plastic washers and finials
   (Q).
7. Thread all thread (C) into the center lock hole of the crossbar
   (A) using the lock washer (Y1) and hex nut (Y2) until snug. Adjust
   the length of all thread (C) into the crossbar if necessary.
8. Mount the crossbar (A) assembly to the ceiling junction box
   using the mounting screws (B). Ensure that the side of the crossbar
   (A) marked GND faces out.
9. Attach the quick link (F) to the fixture loop (H) and chain
   (G). Measure and determine the correct number of links needed for
   the desired hanging height. Use chain pliers to open one end link
   of the chain, discard excess chain, and attach the quick link (F)
   to the loop on the bottom of the canopy (D). Lace the fixture wires
   through chain links and pull until tight. Feed wires through the
   canopy and all thread, then pull until tight.
10. Use the support cable (I) to support the weight of the fixture
    while wiring. Align the fixture to the crossbar (A) and attach the
    hook (T) on the end of the support cable (I) into a slot located on
    the crossbar (A). Allow the support cable (I) to support the weight
    of the fixture while wiring.
11. Connect the electrical wires as shown in Fig. 3. Secure all
    wire connectors. If your junction box has a ground wire, connect
    the fixture’s ground wire to it. Otherwise, connect the fixture’s
    ground wire directly to the crossbar using the provided green
    screw.
12. Tuck wire connections neatly into the junction box.
13. Place the canopy (D) over the end of the all thread (C) and
    secure it with the hex nut (Y2) until snug.
14. Thread the finial (E) onto the end of the all thread (C) and
    hand tighten until snug.
15. Install (6) six candelabra base bulbs (P) up to 60 watts each
    or CFL or LED equivalent, following the fixture specification. Do
    not exceed the maximum wattage rating.
16. Your installation is now complete. Return power to the junction
    box and test the fixture.

INSTALLATION INSTRUCTIONS FOR FIXTURE Item#N7356-790 (New. 2022/5/20)
WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER.
AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.

ASSEMBLING THE FIXTURE (FIG. 1 & Fig. 4)

Fig. 1

T

1. Shut off power at the fuse box or circuit breaker box and remove the old

Set#A-012

fixture including the mounting hardware.

– Crossbar

2. Carefully unpack your new fixture and lay out all the parts in a clean area. – Ground Screw

Take care not to misplace any small parts necessary for installation.

– Mounting Screw *2

3. The arms have been placed to lay flat for shipping. Adjust arms to proper

position. (See Fig. 4)

4. Thread fixture loop (H) onto all thread (J) of upper assembly (K).

5. Secure rod (M) to all thread (O) of socket assembly (S). Then thread upper

assembly (K) to rod (M).

6. Carefully place rod threads (N) through holes on top of frame assembly

(R). Then tighten with plastic washers and finials (Q).

Fig. 4

ASSEMBLING THE FIXTURE (Fig. 2) 7. Thread all thread (C) into center lock hole of crossbar (A) with lock washer
(Y1) and hex nut (Y2) until snug. Note: The length of all thread (C) into crossbar may be adjusted if necessary. 8. Take crossbar (A) assembly and mount to ceiling junction box (Not included) using mounting screws (B) (Size: # 8-32N*L1″). The side of
crossbar (A) marked “GND” must face out. 9. Attach quick link (F) to fixture loop (H) and chain (G). Quick link must be
completely closed when installed. By measuring, determine correct number of links needed for desired hanging height. Use a pair of chain pliers to
open one end link of chain and discard excess chain. Attach quick link (F) to loop on bottom of canopy (D), then close quick link (F). Carefully lace fixture wires through chain links and pull until tight. Feed wires through canopy and all thread, then pull until tight.
10. The support cable is provided to support the weight of fixture while wiring. Align fixture to the crossbar (A) and attach hook (T) on the end of support
cable (I) into a slot located on crossbar (A). Carefully allow the support cable (I) to support weight of fixture while wiring.

Acrylic Pole# – GP7356-1 *12 – GP7356-2 *4
Fig. 2

CONNECTING THE WIRE (Fig. 3) 11. Connect the electrical wires as shown in Fig. 3, making sure that all wire
connectors are secured. If your junction box has a ground wire (green or bare copper), connect fixture’s ground wire to it. Otherwise, connect fixture’s ground wire directly to crossbar using green screw provided.
12. Tuck wire connections neatly into junction box.

Chain# HCH2372-790

COMPLETING THE INSTALLATION (Fig. 1) 13. Place canopy (D) over end of all thread (C) and secure with hex nut (Y2)
until snug. 14. Thread finial (E) onto end of all thread (C) and hand tighten until snug. 15. Install (6) six candelabra base bulbs (P) up to 60 watts each or CFL or LED
equivalent (not included) in accordance with the fixture specification. –DO NOT EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS DEPASSER LA PUISSANCE NOMINALE MAXIMALE!)
Your installation is now complete. Return power to the junction box and test the fixture.

Fig. 3

Note: Illustration (Fig. 1) on this manual is for installation purposes only. It may or may not be identical to the fixture purchased.

Notice: It is important to use proper chain pliers (not included)
To OPEN and CLOSE the chain included with this fixture. Do not open them with other tools that may twist or stress the
chain links. It is important to use proper chain pliers like the ones shown in the diagram.
