Minka Lavery 2898-691 3 Light Chandelier Instruction Manual

2898-691 3 Light Chandelier

Product Information and Usage Instructions

The product being installed is Item#2898-691, which is a fixture
used for lighting. The installation instructions were last updated
on August 18th, 2021.

Installation Instructions

Before beginning the installation process, it is important to
shut off power at the fuse box or circuit breaker box. The old
fixture including the mounting hardware should be removed. The new
fixture should be carefully unpacked, and all the parts laid out in
a clean area.

The desired hanging height should be determined, and the thread
rods (F1, F2 and F3) should be attached to all thread (E) on top of
the fixture body. The canopy (C) should be attached by threading
onto rod (F1). Wires should be carefully fed through each rod as
you assemble. The mounting plate (A) should be attached to the
junction box with mounting screws (B). The side of the mounting
plate (A) marked GND and two convex points must face out.

Connecting the Wires

The electrical wires should be connected as shown in Fig. 2,
making sure that all wire connectors are secured. If your junction
box has a ground wire (green or bare copper), connect the fixture’s
ground wire to it. Otherwise, connect the fixture’s ground wire
directly to the mounting plate (A) using the green screw
provided.

Finishing the Installation

The canopy (C) should be slid over the mounting plate (A) and
secured with screws (D). Three candelabra base bulbs (H) up to 60
watts each or CFL or LED equivalent (not included) should be
installed in accordance with the fixture specification. Glass
shades (I) should be screwed onto socket cups (G).

After the installation is complete, power should be returned to
the junction box, and the fixture should be tested.

INSTALLATION INSTRUCTIONS

Item#2898-691 (New. 2021/08/18) READ AND SAVE THESE INSTRUCTIONS
W AR NI N G ! S HU T P O WE R O F F AT F U S E O R CI R C UI T B R E AK E R .

AVERTISSEMENT! COUPER LE COURANT AU NIVEAU DES FUSIBLES OU DU DISJONCTEUR.

MOUNTING THE FIXTURE (Fig.1)

Fig. 1

1. Shut off power at the fuse box or circuit breaker box and Set# A-021-118DH

remove the old fixture including the mounting hardware.

-Mounting plate

2. Carefully unpack your new fixture and lay out all the parts -Ground screw in a clean area. Take care not to misplace any small parts -Mounting screws*2

necessary for installation.

3. Determine the desired hanging height and thread rods (F1,

F2 and F3) to all thread (E) on top of fixture body. Attach

A

canopy (C) by threading onto rod (F1). Carefully feed wires

B

through each rod as you assemble. Note: Remove all

C

thread, if installing with one 6″ rod only.

4. Attach mounting plate (A) to junction box (Not included)

D

with mounting screws (B) (Size: #8-32N*L0.5″). The side of

F1

the mounting plate (A) marked “GND” and two convex

points must face out.

CONNECTING THE WIRES (Fig. 2)
5. Connect the electrical wires as shown in fig 2, making sure

F2

that all wire connectors are secured. If your junction box

F3

has a ground wire (green or bare copper), connect the

E

fixture’s ground wire to it. Otherwise, connect the fixture’s

ground wire directly to the mounting plate (A) using the

green screw provided.

6. Tuck wire connectors neatly into the junction box.

FINISHING THE INSTALLATION (Fig.1)

7. Slide canopy (C) over mounting plate (A) and secure with

screws (D).

8. Install (3) three candelabra base bulbs (H) up to 60 watts

each or CFL or LED equivalent (not included) in accordance with the fixture specification. — DO NOT

EXCEED THE MAXIMUM WATTAGE RATING! (NE PAS

DEPASSER LA PUISSANCE NOMINALE MAXIMALE!) 9. Screw glass shades (I) onto socket cups (G).

Your installation is now complete. Return power to the junction box and test the fixture.

Rod# W30-1-84*1(F1) W30-1-84*2(F2) W30-H-84*1(F3)
G H I

Note: Illustration (Fig.1) on this manual is for installation

purposes only. It may or may not be identical to the

fixture purchased.

Fig. 2

FIXTURE WIRES Black or Smooth

FIXTURE WIRES White or Ribbed

FIXTURE WIRES Bare Copper (Ground)

HOUSE WIRES Black (Hot)

HOUSE WIRES White (Neutral)

HOUSE WIRES Green (Ground)

Page:1/1

LA-3463E
