54006 20 PC Modular Wall Organizer
Product Information
The KOBALT 20 PC MODULAR WALL ORGANIZER is a versatile storage
system designed to help you organize your tools and accessories. It
features a modular design, allowing you to customize the layout
according to your needs. The package includes various components
such as posts, shelves, brackets, and hooks. The product is
manufactured by LF, LLC and is protected by trademarks and
registered trademarks.
Package Contents
| Part | Description | Quantity |
|---|---|---|
| A | Post | 4 |
| B | Shelf | 4 |
| C | Left Bracket | 4 |
| D | Right Bracket | 4 |
| E | K Steel Rail | 2 |
| F | 6 in. Post Hook | 4 |
| G | 4 in. K Rail Hook | 2 |
| H | 6 in. Double-head K Rail Hook | 2 |
| I | 6 in. Single-head K Rail Hook | 2 |
Hardware Contents
| Part | Description | Quantity |
|---|---|---|
| AA | ST5x40mm Screw | 20 |
| BB | M6x10mm Bolt | 16 |
| CC | 14×1.0mm Washer | 16 |
Product Usage Instructions
Preparation
Before starting the assembly process, ensure that all parts are
present. Compare the parts with the package contents list and
hardware contents list provided. If any part is missing or damaged,
do not proceed with the assembly.
Estimated Assembly Time: 15 Minutes
Tools Required for Assembly (not included):
- Ladder
- Hammer
- Tape measure
- Stud finder
- Pencil
- Power drill and 1/8 in. drill bit
- Phillips Screwdriver
- Framing square
Safety Information
It is important to read and understand the entire manual before
attempting to assemble, operate, or install the product. If you
have any questions or concerns, please contact customer service at
888-3KOBALT (888-356-2258) or [email protected].
WARNING: Failure to properly install the
product according to the manufacturer’s guidelines could result in
serious injury or death.
WARNING: Electrical, plumbing, or gas lines may
be present in the wall. Before cutting, drilling, or hammering,
verify their location. If needed, consult an electrician, plumber,
or service person.
WARNING: During installation, avoid
overreaching and overextending while on a ladder to prevent
potential falls.
CAUTION: Wear protective eyewear during
installation to avoid potential eye hazards.
Assembly Instructions
Locate the desired position for the first vertical Post (A) on
the exposed wall joist. Mark the location and drill a small pilot
hole (1/8 in). Use a screw (AA) to secure the top-hole position of
the Post (A) to the wall joist. Note: Do not fully tighten the
screw and allow for swinging side to side.Hardware Used: AA ST5 x 40 mm Screw (1)
With only the top-screw in place, rotate the Post (A) 90 degrees
in the desired direction. Place a level on the top of the Post (A)
and ensure it is level. Mark the spot on the new joist using the
bottom hole of the Post (A). Drill a small pilot hole (1/8 in) in
this location.Hardware Used: AA ST5 x 40 mm Screw (9)
Tighten the screws (AA) for each hole on both Posts (A).
Hardware Used: AA ST5 x 40 mm Screw (9)
Place Left Brackets (C) onto the Post (A) as shown in the
picture. Use a hammer to hit the Brackets (C) down and secure
them.Hardware Used: N/A
Note: Please refer to the complete user manual for detailed
instructions on installing shelves, right brackets, steel rails,
and hooks.
KOBALT , K-RAIL and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved.
ITEM #5105949
20 PC MODULAR WALL
ORGANIZER
MODEL #54006 Español p. xx
ATTACH YOUR RECEIPT HERE Serial Number
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 888-3KOBALT (888-356-2258), 8 a.m – 8 p.m., EST, Monday – Sunday.You could also contact us at [email protected].
XXXXXXXX
1
Lowes.com
TABLE OF CONTENTS Package Contents ……………………………………………………………………………………………………………3 Hardware Contents…………………………………………………………………………………………………………….4 Preparation ………………………………………………………………………………………………………………………4 Safety Information……………………………………………………………………………………………………………..5 Assembly Instructions………………………………………………………………………………………………………..6 Operating Instruc.t.i.o..n..s…………………………………………………………………………………………………………9 Care and Maintenance ………………………………………………………………………………………………………9 Troubleshooting ………………………………………………………………………………………………………………..9 Warranty ………………………………………………………………………………………………………………………..10 Replacement Parts List…………………………………………………………………………………………………….10
2
Lowes.com
PACKAGE CONTENTS
PART
A B C D E F G H I
B
D C A
E
G
F
H
I
DESCRIPTION
Post Shelf Left Bracket Right Bracket K Steel Rail 6 in. Post Hook 4 in. K Rail Hook 6 in. Double-head K Rail Hook 6 in. Single-head K Rail Hook
QUANTITY
4 4 4 4 2 4 2 2 2
3
Lowes.com
HARDWARE CONTENTS
AA
BB
CC
ST5x40mm Screw Qty.20
M6x10mm Bolt Qty.16
14×1.0mm Washer Qty.16
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time:15 Minutes Tools Required for Assembly (not included): Ladder,Hammer, Tape measure, Stud finder, pencil, power drill and 1/8 in.drill bit,Phillips Screwdriver and framing square.
4
Lowes.com
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 888-3KOBALT (888-356-2258), 8 a.m – 8 p.m., EST, Monday – Sunday. You could also contact us at [email protected].
WARNING
PERSONAL INJURY HAZARD Failure to properly install according to the manufacturer’s guidelines could result in serious injury or death.
WARNING
ELECTRICAL, PLUMBING OR GAS LINES MAY BE IN WALL. Before cutting, drilling or hammering verify their location. lf needed, contact your electrician, plumber, or service person.
WARNING
POTENTIAL FALL HAZARD During installation of this item, avoid overreaching and overextending while on a ladder.
CAUTION
POTENTIAL EYE HAZARD Wear protective eyewear during installation.
5
Lowes.com
ASSEMBLY INSTRUCTIONS
1. Locate the desired position for the first vertical Post (A) on the exposed
1
32 in.
wall joist. Mark the location and drill
A
a small pilot hole (1/8 in). Using the
top-hole position of the Post (A), use
AA
screw (AA) and screw it in place to
the wall joist.
NOTE: Make sure it is NOT fully tightened in place and allows for swinging side to side.
Hardware Used
AA ST5 x 40 mm
x 1
2. With only the top-screw in place, rotate the Post (A) 90-degree in the desired
2
direction. Place a level on the top of the
A
Post (A), that has been rotated
90-degree. Note: Make sure it is level
and that the bottom hole of the Post (A)
is on-center with the new joist. Mark the
spot on the new joist using the bottom
hole of the Post (A). Drill a small pilot
hole (1/8 in) in this location.
3. Tighten the screws (AA) for each hole on both Posts (A).
3
A Hardware Used
AA
AA ST5 x 40 mm
x 9
6
Lowes.com
ASSEMBLY INSTRUCTIONS
4. Place Left Brackets (C) onto the Post (A) as the installation procedure by
4
A
D
the picture showing. Using the Hammer hit the Brackets (C) down,
C
ensure the hook touching tighten to
the Post (A) as shown, same to the
Right Brackets (D).
NOTE: You can adjust the Bracket distance as needed.
5. Place Shelf (B) onto the Brackets (C & D) as the installation procedure by the
5
D
picture showing. Secure the Shelf (B) to the Brackets (C & D) using Bolt (BB) and Washer (CC) tighten by a Phillips
C B
Screwdriver.
Hardware Used
CC
BB M6 x 10 mm
x 4
BB
CC 14×1.0mm
x 4
6. Same to the other shelf as above process.
6
Hardware Used
BB M6 x 10 mm
x 4
CC 14×1.0mm
x 4
7
Lowes.com
ASSEMBLY INSTRUCTIONS
7. Place K Steel Rail (E) onto the Post (A) using the Hammer hit the K Steel Rail
7
(E) down, ensure the Rail touching
tighten to the Post (A) as shown.
NOTE: You can adjust the Rail distance as needed.
8. Place 6-in Post Hook (F) onto the Post (A) using the Hammer hit the 6-in Post
8
Hook (F) down, ensure the Hook
touching tighten to the Post (A) as
shown.
NOTE: The hook height can be adjusted as needed.
A E
A F
9. Place 4-in K Rail Hook (G), 6-in Double-head K Rail Hook (H) and
9
6-in Single-head K Rail Hook (I)
onto the K Steel Rail (E), ensure
the Hook touching tighten to the K
Steel Rail (E) as shown.
E G H I
8
Lowes.com
ASSEMBLY INSTRUCTIONS
10. Same to the other Shelf System Set as above process.
10
Hardware Used
AA ST5 x 40 mm
x 10
BB M6 x 10 mm
x 8
CC 14×1.0mm
x 8
NOTE: Before installation, lay tools and components on a table or flat surface.
IMPORTANT: Using extreme caution, test the unit immediately after proper installation with a light load to double check unit is secured to the wall joint.
OPERATING INSTRUCTIONS
The Shelves are hardly to be placed onto the Brackets. Mounting Post distance is more than 32-in. Re-locate post distance mounting post distance to be 32-in as required. Follow extreme caution when loading and unloading items from the KOBALT 20 PC Modular Wall Organizer. Weight load capacity is up to 150-lb per shelf evenly distributed; 150-lb per feet for K Steel Rail; 50-lb for 6-in Post Hook, 25-lb for 4-in K Rail Hook, 25-lb for 6-in Double-head K Rail Hook and 5-lb for 6-in Single-head K Rail Hook.
CARE AND MAINTENANCE
On an annual basis, it is recommended to double check all connections and re-tighten all nuts and bolts. Clean with water and a paper or cloth towel as needed.
TROUBLESHOOTING
If you have any questions regarding the product, please call customer service at 888-3KOBALT (888-356-2258), 8 a.m. – 8 p.m., EST, Monday – Sunday. You could also contact us at [email protected].
PROBLEM
The Shelf are hardly to be placed onto the Brackets.
POSSIBLE CAUSE
Mounting Post distance is more than 32-in.
CORRECTIVE ACTION
Re-locate post distance mounting post distance to be 32-in as required.
9
Lowes.com
WARRANTY
You should never have a problem with your Kobalt Tools. However, if you do, return the item to the place of purchase for a free replacement. No questions asked. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. The warranty excludes the screws.
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 888-3KOBALT (888-356-2258), 8 a.m. 8 p.m., EST, Monday – Sunday. You could also contact us at [email protected].
PART
A
DESCRIPTION
Post
PART#
PIC
5105949-A
B
Shelf
5105949-B
C
Left Bracket
5105949-C
D
Right Bracket
5105949-D
E
K Steel Rail
5105949-E
F
6 in. Post Hook
5105949-F
G
4 in. K Rail Hook
5105949-G
H
6 in. Double-head K Rail Hook
5105949-H
I
6 in. Single-head K Rail Hook
5105949-I
AA
Screw ST5x40mm
5105949-HAWR
BB
Bolt M6x10mm
5105949-HAWR
CC
Washer 14×1.0mm
5105949-HAWR
Printed in China 10
