Pima Dpp310 Pet Immune Pir Detector Instruction Manual (+ PDF)

The PIMA DPP310 is guaranteed against defects in material or
faulty workmanship for a period of 10 years from the date of
purchase. Disclaimer: PIMA will not accept any liability based on a
claim that the DPP310 failed to perform correctly as it is a
component part of an installation and not a complete intruder alarm
system.

Ordering Information:

CAT. P/N	Description
5010155	DPP310 PET immune PIR Detector

Standards and Approvals:

Security PD 6662:2017
EN 50131-2-2:2021 Grade 2, Class II
EMC Immunity: EN 50130-4:2011
Radiated Immunity: 80MHz to 2.7GHz
Electrostatic Discharge: +/- 8kV
Conducted Immunity: 0.15MHz to 100MHz
Fast Transient Immunity: 2kV
Conducted & Radiated Emissions: EN 55032:2015

Regulatory:

RoHS Directive: 2011/65/EU Compliant: PIMA declares that
this product complies with and conforms to RoHS legislation that it
does not contain more than the agreed levels of: Lead (Pb), Cadmium
(Cd), Mercury (Hg), Hexavalent chromium (Cr6+), Polybrominated
biphenyls (PBB), Polybrominated diphenyl ethers (PBDE)

FORCE Settings:

Note the jumper settings for Installation with FORCE.

For Double Pole Wiring:

A-Zone
T-Zone

For EOL Wiring:

EOL Zone

Mounting Instructions:

Mount the detector at a height between 2.0m and 2.2m for optimal
performance. It is recommended to mount it at 2.0m for maximum
detection range, especially at high temperatures.

If mounting without a bracket, seal all holes and use No. 6
countersunk screws.

Contact Information:

PIMA Electronic Systems Ltd.
5, Hatzoref St., Holon 5885633, Israel
Tel: +972.3.6506411
Email: [email protected]
Website: http://www.pima-alarms.com

View Fullscreen

DPP310
Instruction Manual
Pet Friendly PIR Detector www.pima-alarms.com
Key Features
· 35kg Pet Friendly · 15 Metre Range · Grade 2 · Multi Height Optics · 2.0m – 2.2m Mounting Height · Selectable EOL Resistors · Slide to Fit Front Cover · Remote LED Control · Sealed Optics · True Creep Zones · Digital Pulse Count · Temperature Compensation · Advanced Signal Processing · RFI Immunity up to 2.7GHz · Optional Tamper Proof Bracket Patent Pending

1 Location
Mounting Height
2.2m Max
2.0m
Recommended

Location Warning

Note: For maximum detection range, especially at high temperatures, mount at 2.0m.
3 Detector Setup
Note the jumper settings for Installation with FORCE.

For Double Pole Wiring

A-Zone

T-Zone

12V 0V ·ALARM TAMPER· LED
For EOL Wiring
EOL Zone

Coverage Pattern (m) 15m

12 0

8 10 12 14 16

8 6

4 2

0 2 4

6 8

0246

8 10 12 14 16

15m

2.0m

0 2 4 6 8 10 12

15m

2 Mounting
without bracket
Seal all holes

Use No. 6 countersunk screws
LED On

RemOff
LED

LED = NC/ 12V
LED = 0V

12V 0V ·ALARM TAMPER· LED

Alarm Resistor
O/C 1K0 2K2 4K7 5K6 6K8

Tamper Resistor
O/C 1K0 2K2 4K7 5K6

Do Not Touch

Pulse Count 1
Pulse

2
Pulse

Specification

Description Pyro Electric Sensor Max Pet Weight Range Optics Detection Areas
Mounting Height
Supply Voltage Quiescent Current
Alarm (LED enabled) Alarm (LED disabled) LED Control = 0V LED Control = 12V / NC Pulse Count
Start-up Time Alarm Time Target Speed Dimensions (whd) mm Housing Material
Operating Temperature Storage Temperature Maximum Humidity Product Weight Packed Weight Maintenance

Passive Infrared Detector Dual Element 35kg 15m Multi Height Spherical 68
2.0m – 2.2m
9 – 15VDC (12V nominal) 10mA
15mA 7mA LED Enabled LED Disabled Digital
60 seconds > 2 seconds 0.3m/s – 3.0m/s 60 x 97 x 40 2.5mm ASA
-20°C to +55°C -35°C to 60°C 95% non-condensing 80g 95g Annual Installer Check

Warranty
The PIMA DPP310 is guaranteed against defects in material or faulty workmanship for a period of 10 years from the date of purchase. Disclaimer: PIMA will not accept any liability based on a claim that the DPP310 failed to perform correctly as it is a component part of an installation and not a complete intruder alarm system.

Ordering Information

CAT. P/N Description

5010155 DPP310 PET immune PIR Detector

Standards and Approvals

Security PD 6662:2017 EN 50131-2-2:2021 Grade 2, Class II

EMC / False Alarm Immunity

EMC Immunity:

EN 50130-4:2011

Radiated Immunity:

80MHz to 2.7GHz

Electrostatic Discharge:

+/- 8kV

Conducted Immunity:

0.15MHz to 100MHz

Fast Transient Immunity:

2kV

Conducted & Radiated Emissions: EN 55032:2015

Hereby, PIMA Ltd declares that the DPP310 conforms to: European Union (EU) Electro-Magnetic Compatibility (EMC) Directive 2014/30/EU and EN 50130-4:2011+A1:2014 EMC Environment: Residential / Commercial / Light Industrial / Industrial

EU & UK Registered Design

Regulatory
WEEE Directive: 2012/19/EU Compliant: This symbol indicates that according to local laws and regulations, this product should not be disposed of as municipal/household waste. Instead, it should be disposed of at the appropriate collection points designated for the recycling of electrical and electronic equipment, or returned to PIMA upon purchase of new replacement products. This will help to conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.
RoHS Directive: 2011/65/EU Compliant: PIMA declares that this product complies with and conforms to RoHS legislation that it does not contain more than the agreed levels of: Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Cr6+), Polybrominated biphenyls (PBB), Polybrominated diphenyl ethers (PBDE)

FORCE Settings
Set the FORCE Alarm System as follows: · Two EOL resistors · Resistor values 100 (=10K)

Designed and Manufactured in the United Kingdom
PIMA Electronic Systems Ltd. 5, Hatzoref St., Holon 5885633, Israel
Tel: +972.3.6506411 Email: [email protected]
http://www.pima-alarms.com 4410565 Rev A (Dec 2022)

INS002-PIMA-ENGLISH
