RE15 Electronic Low Voltage Relay
Product Information:
- Product Name: RE253C Electronic Low Voltage
Relay - Product Description: 25 A @ 120 V, 208 V, 240
V, 277 V or 347 V - Dimensions: 4.10 in. x 4.10 in. x 2.10
in.
- Product Name: RE253T Electronic Low Voltage
Relay (with Transformer) - Product Description: 25 A @ 208 V, 240 V, 277
V or 347 V - Dimensions: 4.10 in. x 4.10 in. x 2.10
in.
- Product Name: RE306C Electronic Low Voltage
Relay - Product Description: 30 A @ 120 V-600 V
- Dimensions: 4.76 in. x 4.70 in. x 3 in.
- Product Name: RE153 Electronic Low Voltage
Relay - Product Description: 15 A @ 120 V-347 V
- Dimensions: 3.31 in. x 2.17 in. x 0.89
in.
- Product Name: RE156 Electronic Low Voltage
Relay - Product Description: 6 A @ 120 V-600 V
- Dimensions: 3.31 in. x 2.17 in. x 0.89
in.
- Product Name: RE153T Electronic Low Voltage
Relay (with Transformer) - Product Description: 15 A @ 208 V-347 V
- Dimensions: 3.31 in. x 2.17 in. x 1.5 in.
Product Usage Instructions:
Note: The use of the same thermostat with multiple
relays is not recommended.
- Ensure proper installation of the relay according to the
provided installation instructions. - Connect the appropriate voltage source to the relay.
- Refer to the specific product manual for detailed wiring
instructions. - Once the relay is properly wired, it is ready for use.
- Refer to the user manual for any additional usage instructions
or troubleshooting tips.
RE25 RE30
ELECTRONIC RELAY LOW VOLTAGE
CONTROL
· pulsed signal (PWM) or all or nothing (on/off) at 24 Vac, 3-32 Vdc signal
· with a transformer (RE253T) · compatible with the STE241, T822K1018U and T87K1007U
thermostats · two additional relays without transformers can be added
to the same control circuit as a relay with a transformer · installing more than four relays without transformers to
the same thermostat is not recommended
INSTALLATION
· the relay must be installed in an external junction box
WARRANTY
· three years
RE253C
RE253T
NTY
PRODUCT
DESCRIPTION
RE253C ELECTRONIC LOW VOLTAGE RELAY [25 A @ 120 V, 208 V, 240 V, 277 V OR 347 V] RE253T ELECTRONIC LOW VOLTAGE RELAY [25 A @ 208 V, 240 V, 277 V OR 347 V] (W/TRANSFORMER)
RE306C ELECTRONIC LOW VOLTAGE RELAY [30 A @ 120 V-600 V]
Dimensions: RE253: 4.10 in. x 4.10 in. x 2.10 in. / RE306C: 4.76 in. x 4.70 in. x 3 in.
RE306C
YEAR WARRA
RE15
ELECTRONIC RELAY LOW VOLTAGE SMALLER-SIZED
CONTROL
· pulsed signal (PWM) or all or nothing (on/off) at 24 Vac, 3-32 Vdc signal
· with a transformer (RE153T) · compatible with the STE241, T822K1018U and T87K1007U
thermostats · two additional relays without transformers can be added
to the same control circuit as a relay with a transformer · installing more than four relays without transformers
to the same thermostat is not recommended
INSTALLATION
· the relays must be installed inside the junction box of the heating unit
WARRANTY
· three years
RE153T
RE156
RE153
PRODUCT
DESCRIPTION
RE153 RE156 RE153T
ELECTRONIC LOW VOLTAGE RELAY [15 A @ 120 V-347 V] ELECTRONIC LOW VOLTAGE RELAY [6 A @ 120 V-600 V] ELECTRONIC LOW VOLTAGE RELAY [15 A @ 208 V-347 V] (W/TRANSFORMER)
Dimensions: RE153 and RE156: 3.31 in. x 2.17 in. x 0.89 in. / RE153T: 3.31 in. x 2.17 in. x 1.5 in.
YEAR WARRA
FC_RE25-RE30-RE15_US_210520
