MOUNT-KB05-4D Clamp On Keyboard Tray with Pencil Drawer
Product Information:
The Clamp-on Keyboard Tray with Pencil Drawer is an ergonomic
accessory designed to provide a comfortable typing experience. The
tray is made of durable materials and can be easily attached to any
desktop surface up to 1.5 inches thick. It comes with a pencil
drawer, slider brackets, clamps, pads, screws, and other hardware
necessary for assembly. The product has a weight capacity of 11lbs
(5kg) and should not be exceeded to avoid serious injury.
Product Usage Instructions:
- Assemble Slider Brackets (C) to Clamps (E) using M4x7mm Screws
(S-A). Tighten with a Phillips screwdriver. - Assemble the slider brackets with clamps to Keyboard Tray (A)
using M5x12mm Screws (S-B), and tighten with a Phillips
screwdriver. The clamps must be on the opposite end from the center
cable guide. - Slide Pencil Drawer (B) back into the open ends of Drawer
Sliders (F) until they are latched together. - Mount assembled Pencil Drawer (B) to the underside of Keyboard
Tray (A) using ST5x12mm Screws (S-C) with a Phillips
screwdriver. - Place Pads (D) on the underside of Clamp (E). Place the
assembled keyboard mount on the edge of the desk and tighten Clamps
(E). NOTE: To ensure keyboard tray is level, do not over-tighten
Clamps (E).
If any parts are received damaged or defective during assembly,
please contact VIVO’s customer support team at [email protected] or
call 309-278-5303. The support team is available Monday – Friday
from 7:00am-7:00pm CST and can offer immediate assistance with
rapid response times.
Clamp-on Keyboard Tray with Pencil Drawer
Instruction Manual
SKU: MOUNT-KB05-4D
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-kb05-4d
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
www.vivo-us.com Chat live with an agent!
309-278-5303
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or inappropriate use.
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x1) Keyboard Tray
B (x1) Pencil Drawer
C (x2) Slider Bracket
D (x2) Pad
E (x2) Clamp
F (x2) Drawer Slider
S-A (x6)
S-B (x8)
S-C (x4)
M4x7mm Screw M5x12mm Screw ST5x12mm Screw
TOOLS NEEDED
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED
Phillips Screwdriver
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
11lbs (5kg)
ASSEMBLY STEPS
STEP 1
Assemble Slider Brackets (C) to Clamps (E) using M4x7mm Screws (S-A). Tighten with a Phillips screwdriver.
ALLATION
EG
Left
Right
C
F
S-AA A
2
STEP 2
Assemble the slider brackets with clamps to Keyboard Tray (A) using M5x12mm Screws (S-B), and tighten with a Phillips screwdriver. The clamps must be on the opposite end from the center cable guide.
SB-B
Right
E A
B Left
STEP 3
Slide Pencil Drawer (B) back into the open ends of Drawer Sliders (F) until they are latched together.
F B
STEP 4
Mount assembled Pencil Drawer (B) to the underside of Keyboard Tray (A) using ST5x12mm Screws (S-C) with a Phillips screwdriver.
A
B
S-C
STEP 5
Place Pads (D) on the underside of Clamp (E). Place the assembled keyboard mount on the edge of the desk and tighten Clamps (E). NOTE: To ensure keyboard tray is level, do not over-tighten Clamps (E).
Desktop D
E
3
Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us
LAST UPDATED: 04/15/2022 REV1
Open Monday – Friday 7:00am – 7:00pm CST, our dedicated support team can offer immediate assistance with rapid response times. If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
