Hanwha Vision Sbd-140kmb Corner Mount Pole Mount Instruction Manual

Product Information:

• Product Name: Corner Mount Pole Mount
• Model Numbers: SBD-140KMB, SBD-140PMB
• Installation Precautions:
  • Ensure that the installation place can endure at least 4 times
    the total weight of the Corner/Pole Mount and Camera.
  • Corner Mount (SBD-140KMB) requires M4 Screws for
    installation.
• Package Contents:
  • SBD-140KMB Corner Mount
  • SBD-140PMB Corner Mount
  • 4x SCREW
• Optional Accessory:
  • POLE MOUNT
  • 4x SCREW
  • STEEL STRAP (SBP-060S/150S)

Product Usage Instructions:

1. Corner Mount Installation:
   1. Identify the suitable location for installation.
   2. Ensure that the chosen installation place can support a weight
      at least 4 times the combined weight of the Corner Mount and
      Camera.
   3. Using M4 Screws, securely attach the Corner Mount (SBD-140KMB)
      to the desired corner.
   4. Make sure the Corner Mount is firmly fixed and stable before
      proceeding.
2. Pole Mount Installation:
   1. Identify the suitable location for installation on a pole.
   2. Ensure that the chosen installation place can support a weight
      at least 4 times the combined weight of the Pole Mount and
      Camera.
   3. Securely attach the Pole Mount to the pole using the provided
      SCREWS.
   4. If required, use the STEEL STRAP (SBP-060S/150S) for additional
      stability.
   5. Ensure that the Pole Mount is firmly fixed and stable before
      proceeding.
