SBD-140PMW SBD Pole Mount
Product Information
The product is a pole mount for SBD-140PMW and SBD-180PMW
cameras. It comes with a conduit pipe of size 3/4 (M25) and
requires a steel strap that needs to be purchased separately. The
package includes steel straps (2EA), screws (4EA), and cap
holes.
Installation Precautions
- Ensure that the installation place can endure at least 4 times
the total weight of the Back Box, Camera, and Pole Mount. - When installing the product outdoors, use interlocking devices
made of stainless steel.
Installation Instructions
- Choose a suitable location for installation.
- Ensure that the installation place can endure at least 4 times
the total weight of the Back Box, Camera, and Pole Mount. - If installing the product outdoors, use interlocking devices
made of stainless steel. - Attach the steel strap to the pole using screws (4EA).
- Place the cap hole on the steel strap.
- Attach the conduit pipe to the cap hole.
- Attach the camera to the mounting hole by camera size and
tighten using a TR30 screwdriver.
Note: The mounting hole size varies based on the camera model.
For SBD-140PMW, use mounting holes 1-1 ~ 1-5, and for SBD-180PMW,
use mounting holes 2-1 ~ 2-5. Use a TR30 screwdriver to tighten the
screws. Additionally, use PT01-005975B for conduit pipe
attachment.
Package
Pole Mount
SBD-140PMW SBD-180PMW
Installation Precautions
` Make sure that the installation place can endure at least 4 times of the total weight of the Back Box, Camera and Pole Mount.
` When installing the product outdoors, use interlocking devices made of stainless steel.
Installation
Ø50~150 mm (Ø2~6 in)
Ø100~410 mm (Ø4~16 in)
Conduit Pipe 3/4″(M25)
Steel Strap needs to be purchased separately.
Mounting Hole by Camera Size
Ø110~120 (mm)
SBD-140PMW Ø125 (mm)
1-1 ~ 1-5 2-1 ~ 2-5
Ø130~140 (mm)
SBD-180PMW Ø147~180 (mm)
4x
Steel Strap (2EA)
Screws (4EA)
Cap Hole
1-1
1-2
1-3
1-4
1-5
TR30
2-1
2-2
2-3
2-4
2-5
TR30
3/4″ (M25)
PT01-005975B
