Dometic Ea1400 Optimus Electric Steering System For Boats User Manual

EA1400 Optimus Electric Steering System for Boats

Product Information: Optimus Electric Steering System for Bass
Boats

The Optimus Electric Steering system is a high-performance
steering system designed specifically for BASS boats. It eliminates
all hydraulic components from the installation, providing immediate
response and control. The system is compatible with Mercury,
Yamaha, and Suzuki engines and offers reduced maintenance as it
does not require any hydraulic parts. With the Optimus Electric
Steering system, you can give your BASS boat a new life by
experiencing fast steering response, high precision control, and
improved safety.

The electric actuator steering parameters are pre-set to ensure
the highest performance steering. The system consists of an
electric actuator and electronic helm that work together to provide
a comfortable and controlled steering experience while you enjoy
your favorite activity – fishing.

Features:

1. Easy Installation: The system includes a customer installable
   molded harness, making installation hassle-free.
2. Worry-Free Compatibility: A select number of GPSMAP MFD’s are
   compatible with Optimus EPS, ensuring seamless integration with
   your existing navigation system.
3. Durable Design: The system features ultra corrosion-resistant
   shafts, ensuring longevity and durability.

Note: The CANtrak color display is required unless a compatible
Garmin screen is fitted. Please refer to the Garmin website for the
current models that are compatible with Optimus Electric Steering
System.

Please visit optimusbom.com
to develop the parts list specifically designed for BASS boats.
Kindly note that this system is intended for use only on BASS boats
and should not be used on other types of boats. For more
information, please contact your Dometic representative.

For reference purposes only, please visit dometic.com.

Product Usage Instructions:

1. Ensure that the Optimus Electric Steering System is compatible
   with your BASS boat and engine (Mercury, Yamaha, or Suzuki).
2. If required, purchase the CANtrak color display or a compatible
   Garmin screen for integration with the system.
3. Visit optimusbom.com to
   develop a parts list specifically designed for your BASS boat. This
   will ensure proper installation and compatibility.
4. Follow the user manual provided with the Optimus Electric
   Steering System for step-by-step installation instructions.
5. Connect the electric actuator and electronic helm as instructed
   in the user manual.
6. Ensure that all connections are secure and properly
   tightened.
7. If using a compatible Garmin screen, refer to the Garmin
   website for further instructions on integration with the Optimus
   Electric Steering System.
8. Test the steering system to ensure proper functionality and
   steering response.
9. If any issues arise during installation or usage, contact your
   Dometic representative for assistance.

OPTIMUS ELECTRIC STEERING SYSTEM FOR BASS BOATS

The Optimus Electric Steering system has been tuned to specifically enhance the steering capability of your BASS boat, removing all hydraulic components from the installation

HIGH PERFORMANCE IMMEDIATE RESPONSE & CONTROL

ENGINE AGNOSTIC MERCURY, YAMAHA, SUZUKI

REDUCED MAINTENANCE NO HYDRAULIC PARTS

GIVE YOUR BASS BOAT SOME NEW LIFE

Dometic has developed a version of the electric actuator with input from BASS boat builders to provide the fast steering response, high precision control and safety required to get to your fishing hole as quickly as possible. The fatigue you may get from the traditional hydraulic steering is now gone with Optimus Electric Steering.

The electric actuator steering parameters have been already set to give the highest performance steering. The electric actuator and electronic helm work together to provide the feel of control and comfort experienced when your on the water doing your favorite activity, fishing.
Features
· Very low free play at steering wheel ­ helps control chime walk · Steering response time and speed is much quicker with little effort · Symmetric helm feel when turning to port or starboard · Faster steering response with no load dependent variation · Higher precision control which means no steering creep · Higher position holding power against back driving load · Programmed helm resistance for high speed steering wheel stability · Number of turns default set to 3.5 no variation due to load · The electric steering system removes all hydraulic steering fluid from
the boat · Simpler & Faster installation with fewer splash well perforations · Compact roller screw technology · NMMA, ABYC, CE, ISO and SAE electrical & environmental requirements

· Available 180 degree bulkhead harness

1. Easy Installation Customer installable molded harness

2. Worry-Free Compatibility
A select number of GPSMAP MFD’s are compatible with Optimus EPS

3. Durable Design Ultra corrosion-resistant shafts

The CANtrak color display is required unless the following Garmin screen is fitted

· GPSMAP® 74xx/7600 · GPSMAP® 7×2/9×2 & 12×2 · GPSMAP® 10×2/12×2(Keyed) · GPSMAP® 8400/8600

· GPSMAP® 7×2/9×2/12×2 Plus · GPSMAP® 8700 Black Box · Yamaha CL7

Please refer to the Garmin website for current MFD models that are compatible with Optimus
Please visit Optimusbom.com to develop the parts list for your BASS boat. This has been designed specifically for BASS boats and should not be used on other types of boats. Please contact your Dometic representative for information.

dometic.com

FOR REFERENCE
ONLY
