CD 5018 Brindille Extra Large Two Tier Chandelier
Product Information:
Product Name: Brindille Extra Large Two Tier Chandelier
Item Number: CD 5018
Product Description: The Brindille Extra Large Two Tier
Chandelier is a stylish and contemporary lighting fixture. It is
designed to be installed in accordance with local installation
codes. The chandelier comes with a mounting plate, canopy, rods,
collar ring, swivel ball, set screw, wire nut, and glass shades.
The fixture requires proper grounding and careful wire connections
for safe and effective operation.
Product Usage Instructions:
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Separate the mounting plate (B) from the canopy (H) by removing
the collar ring (I). - Install the mounting plate (B) to the junction box using the
provided mounting screws (C). - Feed the electrical wires through the bottom rod (K) and
connect them to the fixture (L). Repeat this step for the middle
rod (J), connecting it to the bottom rod (K). - Continue feeding the wires through the collar ring (I), canopy
(H), and top rod (G). - Hold the fixture upright and slide the collar ring (I) and
canopy (H) down to rest on the fixture (L). Connect the top rod (G)
to the middle rod (J). - Hang the fixture swivel ball (F) to the center of the mounting
plate (B) and secure it with the provided set screw (D) using the
provided wrench (E). Refer to diagram 1 for guidance. - Cut any excess wire, leaving enough to reach the junction box.
Separate the wires and strip insulation on each end. - Connect the supply ground wire (usually green or bare copper)
around the green grounding screw. Tighten securely. It is important
to ensure proper grounding. - Connect the driver input neutral wire (white) to the supply
neutral wire N (usually white) using a wire nut (A). - Connect the driver input hot wire (black) to the supply hot
wire (usually black) using a wire nut (A). Take caution not to
reverse the hot and neutral connections. - Connect the fixture neutral wire (black) to the driver output
wire (black) using a wire nut (A). - Connect the fixture hot wire (red) to the driver output wire
(red) using a wire nut (A). Take caution not to reverse the hot and
neutral connections. - Ensure all wire connections are tight, then carefully tuck them
into the junction box. - Insert the driver into the mounting plate (B) bracket.
- Install the canopy (H) to the mounting plate (B) and secure it
with the collar ring (I). - Thread the glass shades (N) onto the light sources (M). Be
careful not to over-tighten, as it could damage the shades. - Adjust the light sources (M) to your desired angle. They can be
rotated left or right and directed upwards or downwards.
Note: It is important to follow all applicable
local installation codes and have someone familiar with
construction and operation install the chandelier. Inspect the item
and contents carefully before installation. If any damage or defect
is found, do not install and retain all packaging material until
installation is complete and approved.
ASSEMBLY INSTRUCTIONS
A
B
D
C
E
Diagram 2
A
F
G
H
DE
I
J Diagram 1
K L
Brindille Extra Large Two Tier Chandelier
Item # CD 5018
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Wire Cutters
Wire Strippers
1. Carefully remove all parts from the box. Place on a clean, soft surface.
2. Remove mounting plate (B) from canopy (H) by removing collar
ring (I).
3. Install mounting plate (B) to the junction box and secure with
mounting screws (C).
4. Feed electrical wires through bottom rod (K) and connect to fixture (L).
Repeat for middle rod (J), connecting to bottom rod (K).
5. Continue feeding wires through collar ring (I), canopy (H) and top
rod (G).
6. Holding fixture upright, slide collar ring (I) and canopy (H) down and
rest on fixture (L). Then connect top rod (G) to middle rod (J).
NOTE: Slide components down slowly to avoid damages.
7. Hang fixture swivel ball (F) to center of mounting plate (B) and secure
with set screw (D) using provided wrench (E). See diagram 1.
8. Cut excess wire, being sure to leave enough to reach the junction box. Separate wires
and strip insulation on each 5/8″.
9. Connect supply ground wire (usually green or bare copper) around the
green grounding screw (see diagram 2). Tighten.
M
NOTE: It is imperative that the fixture is grounded.
10. Connect driver input neutral wire (white) to the supply neutral wire N
(usually white) using wire nut (A).
M
LI ST ED
US
ASSEMBLY INSTRUCTIONS
A
B
D
C
E
Diagram 2
A
F
G
H
DE
I
J Diagram 1
K L
Brindille Extra Large Two Tier Chandelier Item # CD 5018
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
11. Connect driver input hot wire (black) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
12. Connect fixture neutral wire (black) to driver output wire (black) using wire nut (A).
13. Connect fixture hot wire (red) to driver output wire (red) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
14. Make sure all wire connections are tight, then carefully tuck into the junction box.
15. Insert driver into mounting plate (B) bracket. 16. Install canopy (H) to mounting plate (B) and secure with collar ring (I). 17. Thread glass shades (N) to light sources (M).
NOTE: Do not over-tighten otherwise shade could become damaged. 18. Adjust light sources (M) to desired angle.
NOTE: The light source can be rotated left or right and directed upwards or downwards.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
M
N
M
LI ST ED
US
