CD 5026 Lomme Small Linear Chandelier
Lomme Small Linear Chandelier
Item # CD 5026
Product Information:
- This is a small linear chandelier for indoor use.
- It should be installed in accordance with all applicable, local
installation codes. - Inspect the item and contents carefully before
installation. - If any damage or defect is found, do not install.
- Retain all packaging material until installation is complete
and approved. - Tools required (not included): Phillips Screwdriver, Slotted
Screwdriver, Wire Cutters, Wire Strippers. - Product dimensions: Not specified in the manual.
- Product weight: Not specified in the manual.
Product Usage Instructions:
- Carefully remove all parts from the box. Place on a clean, soft
surface. - Remove mounting plate (B) from canopy (F) by removing collar
ring (G). - Install mounting plate (B) to the junction box and secure with
mounting screws (D). - Connect supply ground wire (usually green or bare copper)
around the mounting plate screw (D). - Connect driver (C) input neutral wire (white) to the supply
neutral wire (usually white) using wire nut (A). - Connect driver (C) input hot wire (black) to the supply hot
wire (usually black) using wire nut (A). CAUTION: Do not reverse
the hot and neutral connections. - Connect fixture neutral wire (black) to driver (C) output wire
(black) using wire nut (A). - Connect fixture hot wire (red) to driver (C) output wire (red)
using wire nut (A). CAUTION: Do not reverse the hot and neutral
connections. - Make sure all wire connections are tight, then carefully tuck
into the junction box. - Insert driver (C) into mounting plate bracket.
- Install canopy (F) to mounting plate (B) and secure with collar
ring (G). - Thread glass shades (L) to fixture (K). NOTE: Do not
over-tighten otherwise shade could become damaged. - Remove protective covers (M) from rods (N) carefully, then
install to glass shades (L).
Care Instructions:
Clean only with a soft dry cloth or feather duster. Do not use
abrasive or chemical agents.
ASSEMBLY INSTRUCTIONS
P Q
Diagram 1
A B
C D A E
F G H
I
J
K
L
M N
Lomme Small Linear Chandelier
Item # CD 5026
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Wire Cutters
Wire Strippers
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (B) from canopy (F) by removing collar
ring (G). 3. Install mounting plate (B) to the junction box and secure with mounting
screws (D). 4. Connect supply ground wire (usually green or bare copper) around the
green grounding screw (see diagram 1). Tighten. NOTE: It is imperative that the fixture is grounded. 5. Feed electrical wire through bottom rod (J) and connect to fixture (K). Repeat for middle rod (I), connecting to bottom rod (J). 6. Continue feeding wire through collar ring (G), canopy (F) and top rod (H). 7. Holding fixture upright, slide collar ring (G) and canopy (F) down and rest on fixture (K). Then connect top rod (H) to middle rod (I). NOTE: Slide components down slowly to avoid damages. 8. Hang fixture swivel ball (E) to the center of mounting plate (B) and secure with set screw (P) using provided wrench (Q). See diagram 1. 9. Cut excess wire, being sure to leave enough to reach the junction box. Separate wire and strip insulation on each 5/8″.
M
LI ST ED
US
ASSEMBLY INSTRUCTIONS
P Q
Diagram 1
A B
C D A E
F G H
I
J
K
L
M N
Lomme Small Linear Chandelier
Item # CD 5026
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
10. Connect driver (C) input neutral wire (white) to the supply neutral wire (usually white) using wire nut (A).
11. Connect driver (C) input hot wire (black) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
12. Connect fixture neutral wire (black) to driver (C) output wire (black) using wire nut (A).
13. Connect fixture hot wire (red) to driver (C) output wire (red) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
14. Make sure all wire connections are tight, then carefully tuck into the junction box.
15. Insert driver (C) into mounting plate bracket. 16. Install canopy (F) to mounting plate (B) and secure with collar ring (G). 17. Thread glass shades (L) to fixture (K).
NOTE: Do not over-tighten otherwise shade could become damaged. 18. Remove protective covers (M) from rods (N) carefully, then install
to glass shades (L).
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
M
LI ST ED
US
