TOB 5198 Bryant Grande Two Tier Chandelier
Product Information:
- Product Name: Bryant Grande Two Tier Chandelier
- Item Number: TOB 5198
- Bulbs: Not included (Packaged separately)
Product Usage Instructions:
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Remove the mounting plate (B) from the canopy (E) by removing
the collar ring (F). - Install the mounting plate (B) to the junction box and secure
it with the provided mounting screws (C). - Thread the rod (I) to the fixture body (J).
- Feed the fixture wires through the threaded rod (O) and rod
(H), then connect them. - Connect the fixture neutral wire (white) to the supply neutral
wire (usually white) using the wire nut (A). - Connect the fixture hot wire (black) to the supply hot wire
(usually black) using the wire nut (A). CAUTION:
Do not reverse the hot and neutral connections. - Make sure all wire connections are tight, then carefully tuck
them into the junction box. - Install the canopy (E) to the mounting plate (B) and secure it
with the collar ring (F). - Thread the finial (K) to the bottom of the fixture body
(J). - Install light bulbs into the sockets.
- Clip the shades (L) onto the light bulbs.
NOTE: If a shade has additional packaging,
carefully cut it off from the interior to avoid damages.
Care Instructions:
Clean the chandelier only with a soft dry cloth or feather
duster. Do not use abrasive or chemical agents.
ASSEMBLY INSTRUCTIONS
B
C
A
D
E
F
G
Diagram 1
M
P2
G N
P1
H
O
I J
K
Bryant Grande Two Tier Chandelier
Item # TOB 5198
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Slip Joint Pliers
Wire Strippers
Wire Cutters
L (Packaged separately) Bulbs not included
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (B) from canopy (E) by removing collar
ring (F). 3. Install mounting plate (B) to junction box and secure with mounting
screws (C). 4. Thread rod (I) to fixture body (J). 5. Feed fixture wires through threaded rod (O) and rod (H), then connect
to rod (I) and secure with coupling (P1). Repeat for threaded rod (N) and rod (G), connecting to coupling (P1) and secure with coupling (P2). 6. Continue feeding fixture wires through threaded rod (M) ,rod (G), collar ring (F) and canopy (E). 7. Holding fixture upright, slide collar ring (F), canopy (E) down rods and rest on top of rod (I). Then connect threaded rod (M) and rod (G) to coupling (P2). NOTE: Slide components down slowly to avoid damages. 8. Hang fixture swivel ball (D) to center of mounting plate (B). 9. Cut excess wires, being sure to leave enough to reach the junction box. Separate wires, and strip insulation on each 5/8″. 10. Wrap fixture ground wire (bare copper) around the green grounding screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (A). NOTE: It is imperative that the fixture is grounded.
LED
ASSEMBLY INSTRUCTIONS
B
C
A
D
E
F
G
Diagram 1
M
P2
G N
P1
H
O
I J
K
Bryant Grande Two Tier Chandelier
Item # TOB 5198
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
L (Packaged separately) Bulbs not included
11. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (A).
12. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
13. Make sure all wire connections are tight, then carefully tuck into the junction box.
14. Install canopy (E) to mounting plate (B) and secure with collar ring (F).
15. Thread finial (K) to the bottom of fixture body (J). 16. Install light bulbs into sockets. 17. Clip shades (L) onto light bulbs.
NOTE: If shade has additional packaging, carefully cut off from interior of shade to avoid damages.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
LED
