TOB 5197 Extra Large Two Tier Chandelier
Product Information
Product Name: Bryant Extra Large Two Tier
Chandelier
Item Number: TOB 5197
Features: LED lights, two-tier design, mounting
plate, canopy, collar ring, threaded rod, fixture body, wire nut,
finial, light bulbs, shades (packaged separately)
Notice: This light fixture should be installed in
accordance with all applicable, local installation codes, and by a
person familiar with the construction and operation of it, as well
as the hazards involved. Inspect item and contents carefully. If
any damage or defect is found, do not install. Retain all packaging
material until installation is complete and approved.
Usage Instructions
- Carefully remove all parts from the box. Place on a clean, soft
surface. - Remove mounting plate (B) from canopy (E) by removing collar
ring (F). - Install mounting plate (B) to junction box and secure with
mounting screws (C). - Thread rod (I) to fixture body (J).
- Feed fixture wires through threaded rod (O) and rod (H), then
connect fixture neutral wire (white) to the supply neutral wire
(usually white) using wire nut (A). - Connect fixture hot wire (black) to the supply hot wire
(usually black) using wire nut (A). CAUTION: Do
not reverse the hot and neutral connections. - Make sure all wire connections are tight, then carefully tuck
into the junction box. - Install canopy (E) to mounting plate (B) and secure with collar
ring (F). - Thread finial (K) to the bottom of fixture body (J).
- Install light bulbs into sockets.
- Clip shades (L) onto light bulbs. NOTE: If
shade has additional packaging, carefully cut off from interior of
shade to avoid damages.
Care Instructions: Clean only with a soft dry
cloth or feather duster. Do not use abrasive or chemical
agents.
ASSEMBLY INSTRUCTIONS
B
C
A
D
E
F Diagram 1
G
M
P2
G N
P1
H
O
I J
K
L (Packaged separately) Bulbs not included
Bryant Extra Large Two Tier Chandelier
Item # TOB 5197
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Slip Joint Pliers
Wire Strippers
Wire Cutters
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (B) from canopy (E) by removing collar
ring (F). 3. Install mounting plate (B) to junction box and secure with mounting
screws (C). 4. Thread rod (I) to fixture body (J). 5. Feed fixture wires through threaded rod (O) and rod (H), then connect
to rod (I) and secure with coupling (P1). Repeat for threaded rod (N) and rod (G), connecting to coupling (P1) and secure with coupling (P2). 6. Continue feeding fixture wires through threaded rod (M) ,rod (G), collar ring (F) and canopy (E). 7. Holding fixture upright, slide collar ring (F), canopy (E) down rods and rest on top of rod (I). Then connect threaded rod (M) and rod (G) to coupling (P2). NOTE: Slide components down slowly to avoid damages. 8. Hang fixture swivel ball (D) to center of mounting plate (B). 9. Cut excess wires, being sure to leave enough to reach the junction box. Separate wires, and strip insulation on each 5/8″. 10. Wrap fixture ground wire (bare copper) around the green grounding screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (A). NOTE: It is imperative that the fixture is grounded.
LED
ASSEMBLY INSTRUCTIONS
B
C
A
D
E
F Diagram 1
G
M
P2
G N
P1
H
O
I J
L (Packaged separately)
Bryant Extra Large Two Tier Chandelier
Item # TOB 5197
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
11. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (A).
12. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (A). CAUTION: Do not reverse the hot and neutral connections.
13. Make sure all wire connections are tight, then carefully tuck into the junction box.
14. Install canopy (E) to mounting plate (B) and secure with collar ring (F).
15. Thread finial (K) to the bottom of fixture body (J). 16. Install light bulbs into sockets. 17. Clip shades (L) onto light bulbs.
NOTE: If shade has additional packaging, carefully cut off from interior of shade to avoid damages.
Bulbs not included
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
K
LED
